AXE280124A Equivalent & Substitute Parts

Part Overview

The AXE280124A is an 80-position rectangular connector header manufactured by Panasonic Electric Works, designed for surface mount applications with outer shroud contacts and gold plating. This component is classified as obsolete, making identification of functionally equivalent alternatives essential for ongoing production and maintenance applications. The AXE680124A serves as the direct substitute, offering identical electrical and mechanical specifications while maintaining active product status.

Substiute Parts

AXE280124A

Panasonic Electric WorksIn Stock: 925AXE280124A Datasheet

Current PartRFQ

AXE680124A

Panasonic Electric WorksIn Stock: 1629AXE680124A Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

The AXE680124A qualifies as a direct substitute for the AXE280124A based on matching electrical and mechanical parameters. Substitution is valid when the following criteria are met:

• 80-position connector configuration
• 0.016" (0.40mm) pitch spacing
• 2-row arrangement
• Surface mount technology
• Header with outer shroud contacts
• Gold contact finish
• 0.8mm mated stacking height
• 0.026" (0.65mm height above board
• Solder retention feature
• RoHS compliance
• MSL 1 rating

The primary distinction between these parts is product status: AXE280124A is obsolete while AXE680124A maintains active status, making the latter the recommended selection for new designs and replenishment.

Parameter Comparison

Engineering Selection Recommendations

The AXE680124A is the appropriate selection for applications currently specified with AXE280124A. Both components meet identical electrical and mechanical requirements, with all critical parameters aligned. The AXE680124A maintains active product status and RoHS compliance, ensuring long-term availability and regulatory conformance. For new designs and component replenishment, AXE680124A should be specified to avoid obsolescence constraints.

Frequently Asked Questions (FAQ)

Q: Can AXE680124A be used as a direct replacement for AXE280124A?

A: Yes. Both components share identical electrical and mechanical specifications, including 80-position configuration, 0.40mm pitch, 2-row arrangement, surface mount technology, and gold contact finish. The primary difference is product status, with AXE680124A maintaining active availability.

Q: What is the difference between the A4US and A4S series designations?

A: The series designation reflects internal Panasonic product line classification. Both AXE280124A (A4US series) and AXE680124A (A4S series) meet the same functional and dimensional requirements for 80-position connector headers.

Q: Are there packaging differences between these parts?

A: AXE280124A packaging is not specified in available data. AXE680124A is supplied in strip packaging. Packaging format does not affect electrical or mechanical compatibility.

Q: Why is AXE280124A classified as obsolete?

A: Obsolescence reflects Panasonic's product lifecycle management. AXE680124A provides equivalent functionality and should be used for all new applications and inventory replenishment.

Q: Do both parts meet RoHS compliance requirements?

A: Yes. Both AXE280124A and AXE680124A are RoHS compliant with MSL 1 rating, suitable for unrestricted moisture exposure conditions.
