A-TB500-OP16 Terminal Block Header Equivalent & Substitute Parts

Part Overview

The A-TB500-OP16 is a 16-position terminal block header manufactured by Assmann WSW Components, designed for vertical through-hole mounting with 5.00mm pitch spacing. This component is classified as a male pin, unshrouded header suitable for solder termination applications. The part maintains active product status with 1066 units in current inventory stock.

Terminal block headers of this specification are essential in applications requiring reliable electrical interconnection with standardized pitch geometry. Equivalent and substitute parts are identified to support procurement flexibility, inventory management, and supply chain continuity when the primary part becomes unavailable or when design requirements necessitate alternative sourcing options.

Substiute Parts

A-TB500-OP16

Assmann WSW ComponentsIn Stock: 1138A-TB500-OP16 Datasheet

Current PartRFQ

1933325

Phoenix ContactIn Stock: 17771933325 Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the A-TB500-OP16 is determined by strict alignment of the following critical parameters:

• 16-position configuration with single-level layout
• 5.00mm (0.197") pitch spacing
• Vertical orientation with through-hole mounting
• Male pin, unshrouded header type
• Solder termination capability
• Contact tail length of 0.138" (4.60mm)
• Insulation height of 0.079" (2.00mm)
• UL94 V-0 flammability rating
• ROHS3 compliance status

The Phoenix Contact 1933325 satisfies all mandatory substitution criteria. This part maintains identical mechanical and electrical interface geometry, ensuring direct compatibility in applications designed for the A-TB500-OP16 footprint and electrical specifications.

Parameter Comparison

Engineering Selection Recommendations

Both the A-TB500-OP16 and the Phoenix Contact 1933325 maintain active product status and full ROHS3 compliance. The substitute part 1933325 demonstrates equivalent or superior electrical performance characteristics, with UL current rating of 16 A compared to the primary part's 10 A specification, and IEC current rating of 12 A at 400 V. Both components carry UL94 V-0 flammability certification and MSL 1 moisture sensitivity classification.

Selection between these parts should be based on availability, lead time requirements, and procurement cost considerations. The mechanical and electrical interface compatibility is assured through identical pitch, position count, mounting geometry, and termination specifications. No design modifications are required when substituting the 1933325 for the A-TB500-OP16 in applications operating within the specified electrical and thermal parameters.
