AT06-2S-SB01 Equivalent & Substitute Parts

Part Overview

The AT06-2S-SB01 is a 2-position rectangular connector plug housing manufactured by Amphenol Sine Systems Corp, part of the AT Series™ product line. This connector features female socket contacts, crimp termination, and latch lock fastening, with IP67 sealing capability and operating temperature range of -55°C to 125°C. The part is classified as obsolete, necessitating identification of active equivalent alternatives for new designs and ongoing applications. Substitute parts maintain functional compatibility while offering enhanced features and improved availability.

Substiute Parts

AT06-2S-SB01

Amphenol Sine Systems CorpIn Stock: 754AT06-2S-SB01 Datasheet

Current PartRFQ

AT06-2S-SR01GRY

Amphenol Sine Systems CorpIn Stock: 1629AT06-2S-SR01GRY Datasheet

MFR RecommendedRFQ

DT06-2S-E008

TE Connectivity Deutsch ConnectorsIn Stock: 11896DT06-2S-E008 Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the AT06-2S-SB01 is determined by equivalence across the following critical parameters: connector type (plug), contact type (female socket), number of positions (2), number of rows (1), mounting type (free hanging in-line), contact termination method (crimp), and fastening mechanism (latch lock). All substitute parts maintain these core specifications, ensuring mechanical and electrical compatibility with mating connectors and circuit board layouts designed for the original part.

The AT06-2S-SR01GRY represents a manufacturer-recommended upgrade within the Amphenol product family, offering enhanced sealing ratings (IP68, IP69K versus IP67) and additional features including strain relief and protective cap. The DT06-2S-E008 provides cross-manufacturer equivalence from TE Connectivity Deutsch Connectors, maintaining all functional parameters while offering alternative sourcing and availability.

Parameter Comparison

Engineering Selection Recommendations

The AT06-2S-SB01 is classified as obsolete and should be replaced in new designs. The AT06-2S-SR01GRY is the manufacturer-recommended direct upgrade, offering enhanced environmental protection through improved sealing ratings (IP68, IP69K) and additional protective features including strain relief and integrated cap. This part maintains full compatibility with existing designs while providing superior performance characteristics and active product status with established supply chain availability.

The DT06-2S-E008 from TE Connectivity Deutsch Connectors provides an alternative cross-manufacturer solution with equivalent functional parameters and active product status. This option is suitable for applications requiring dual-source qualification or where TE Connectivity components are preferred within the supply chain. Both substitute parts maintain ROHS3 compliance and REACH unaffected status, meeting current regulatory requirements.

Frequently Asked Questions (FAQ)

Q: Can the AT06-2S-SR01GRY directly replace the AT06-2S-SB01 in existing assemblies?

A: Yes. The AT06-2S-SR01GRY maintains all core functional parameters including connector type, contact type, number of positions, mounting configuration, contact termination method, and fastening mechanism. The part is mechanically and electrically compatible with mating connectors and circuit board layouts designed for the AT06-2S-SB01.

Q: What are the differences between the AT06-2S-SR01GRY and DT06-2S-E008?

A: Both parts maintain equivalent core specifications for connector type, contact configuration, and mounting. The AT06-2S-SR01GRY is an Amphenol product with IP68 and IP69K sealing ratings and includes strain relief and protective cap features. The DT06-2S-E008 is a TE Connectivity Deutsch product with IP68 and IP6K9K sealing ratings and includes a shrink boot adapter. Selection depends on manufacturer preference, supply chain requirements, and specific environmental protection needs.

Q: Are there packaging differences between these parts?

A: Yes. The AT06-2S-SB01 packaging information is not specified. The AT06-2S-SR01GRY is supplied in box packaging, while the DT06-2S-E008 is supplied in bulk packaging. Packaging selection should align with procurement and inventory management requirements.

Q: Do all substitute parts require contacts to be purchased separately?

A: Yes. All three parts—AT06-2S-SB01, AT06-2S-SR01GRY, and DT06-2S-E008—are connector housings supplied without contacts. Contacts must be procured separately and are compatible with the crimp termination method specified for each part.

Q: What is the operating temperature range for these connectors?

A: All three parts operate across the temperature range of -55°C to 125°C, ensuring compatibility across standard industrial and automotive applications.

Q: Are these parts compliant with current regulatory standards?

A: Yes. All three parts are ROHS3 compliant and REACH unaffected, meeting current environmental and regulatory requirements for electronic component manufacturing and distribution.
