ANT-916-SP RF Antenna 915MHz Chip Equivalent & Substitute Parts

Part Overview

The ANT-916-SP is an active, RoHS-compliant 915MHz ISM chip RF antenna manufactured by TE Connectivity Linx. This surface mount component is designed for wireless applications including LoRa, sensor networks, and SigFox systems operating in the 900MHz to 930MHz frequency band. The part is supplied in tube packaging with 724 units currently in stock.

Equivalent and substitute parts are identified based on matching electrical performance parameters, mechanical compatibility, and compliance certifications to ensure direct functional replacement in circuit designs.

Substiute Parts

ANT-916-SP

TE Connectivity LinxIn Stock: 824ANT-916-SP Datasheet

Current PartRFQ

ILA.01

Taoglas LimitedIn Stock: 5166ILA.01 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitute parts for the ANT-916-SP are qualified based on the following critical parameters:

• Frequency Compatibility: Center frequency of 915MHz with overlapping operational bandwidth
• Antenna Type: Chip antenna configuration
• Termination Method: Solder termination for PCB integration
• Mounting Configuration: Surface mount technology
• Electrical Performance: Gain and VSWR values within acceptable operating ranges
• Compliance: RoHS and REACH compliance status
• Mechanical Fit: Height and form factor suitable for surface mount assembly

The substitute part ILA.01 meets these criteria with compatible frequency range (902MHz – 928MHz), matching antenna type, solder termination, and surface mount configuration.

Parameter Comparison

Engineering Selection Recommendations

Both ANT-916-SP and ILA.01 are active products with current manufacturing status and full compliance certifications (RoHS and REACH). Selection between these parts is based on specific application requirements:

ANT-916-SP is appropriate for applications requiring higher gain performance (1.4dBi) and unlimited moisture sensitivity tolerance. The tube packaging format supports lower-volume production workflows.

ILA.01 is suitable for space-constrained designs due to its reduced height profile (0.50mm vs. 1.50mm) and provides documented return loss specification (-10dB). Tape & Reel packaging supports high-volume automated assembly. The MSL-3 rating requires controlled storage conditions (168-hour maximum exposure at 85°C/85% RH).

Both parts operate at 915MHz center frequency with overlapping bandwidth coverage and are suitable for ISM band applications including LoRa, sensor networks, and SigFox systems.

Frequently Asked Questions (FAQ)

Q: Can ILA.01 directly replace ANT-916-SP in existing designs?

A: Direct replacement is possible if the design accommodates the lower gain (1dBi vs. 1.4dBi), slightly higher VSWR (2 vs. 1.9), and reduced height profile (0.50mm vs. 1.50mm). PCB layout and antenna matching networks may require validation for optimal performance.

Q: What is the impact of the 0.4dBi gain difference between these parts?

A: Gain difference affects link budget and communication range. The ANT-916-SP provides 0.4dBi higher gain, which may be critical in range-limited applications. System-level performance testing is necessary to determine if the ILA.01 meets specific link budget requirements.

Q: Are there packaging considerations for high-volume production?

A: ANT-916-SP is supplied in tube packaging, suitable for manual or low-volume pick-and-place operations. ILA.01 is supplied in Tape & Reel format, optimized for automated high-volume assembly lines. Packaging selection should align with production volume and assembly equipment capabilities.

Q: What are the moisture sensitivity implications?

A: ANT-916-SP carries MSL-1 rating (unlimited shelf life at any humidity). ILA.01 carries MSL-3 rating, requiring storage at ≤30°C/85% RH with maximum 168-hour exposure before reflow soldering. MSL-3 components require controlled handling and may impact supply chain logistics for extended storage scenarios.

Q: Are both parts suitable for 915MHz ISM band applications?

A: Yes. Both parts are designed for 915MHz center frequency operation. ANT-916-SP covers 900–930MHz, while ILA.01 covers 902–928MHz. Both frequency ranges encompass standard 915MHz ISM band allocations used in LoRa, SigFox, and sensor network applications.
