Equivalent & Substitute Parts for AEE02A48-M

Part Overview

The AEE02A48-M, manufactured by ARTESYN / Advanced Energy, is an isolated DC-DC converter module designed to provide a regulated 5V output at up to 2A from a 36V to 75V input range. With a power output of 10W, a voltage isolation rating of 4.2 kV, and various protection features, it supports ITE (Commercial) and Medical applications. This part is classified as Obsolete, necessitating the identification of equivalent or substitute models for continued design and replacement purposes.

Substiute Parts

AEE02A48-M

ARTESYN / Advanced EnergyIn Stock: 893AEE02A48-M Datasheet

Current PartRFQ

AEE03A48-M

ARTESYN / Advanced EnergyIn Stock: 1115AEE03A48-M Datasheet

MFR RecommendedRFQ

SLW05C-05

MEAN WELL USA Inc.In Stock: 1044SLW05C-05 Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitute parts are grouped based on strict adherence to the following explicitly provided parameters:

• Input voltage range (36V to 75V or as close as possible)
• Output voltage (5V)
• Output current (as close as possible or higher)
• Power rating (as close as possible or higher)
• Isolated module type
• Mounting type (Through Hole)
• Package/case dimensions
• Voltage isolation rating
• Applications compatibility (ITE, Medical or relevant)
• Compliance (RoHS and MSL)
• Protection features (as specified)

Parameter Comparison

Engineering Selection Recommendations

Selection should be based on product lifecycle status and compliance. The AEE02A48-M is classified as Obsolete. Both AEE03A48-M and SLW05C-05 are Active with RoHS and MSL 1 (Unlimited) compliance, making them permissible substitutes under the provided parameters.

Frequently Asked Questions (FAQ)

Q1: What criteria are used for qualifying substitute DC-DC converter modules?
Substitutes are qualified based on matching input voltage range, output voltage, output current or power ratings, type (isolated module), voltage isolation, mounting type, package size, application compatibility, protection features, and compliance status (RoHS and MSL).

Q2: Are package dimensions and mounting types consistent among these substitutes?
All listed parts use a through-hole 5-DIP module format with closely aligned dimensions, ensuring comparable mechanical fit.

Q3: How does the output specification affect substitutability?
The substitutes offer either higher or lower output current and power. Selection is limited to parameters provided. Ensure the application's load requirements do not exceed the substitute's capabilities.

Q4: Are there differences in device features or protection?
Protection features such as OCP and SCP are present on all models. OTP and OVP are not listed for all variants and should be compared directly when feature compatibility is critical.

Q5: Can these modules be used interchangeably in ITE or Medical applications?
The main part and AEE03A48-M are specified for ITE (Commercial) and Medical; SLW05C-05 is specified for ITE (Commercial) only. The application must match the provided application compatibility.

Q6: What significance does the product status carry in selection?
Product status determines ongoing availability. Preference is given to Active parts (AEE03A48-M, SLW05C-05) due to the Obsolete status of the AEE02A48-M.

Q7: Are compliance and MSL ratings equivalent?
All listed parts are RoHS compliant with an MSL rating of 1 (Unlimited), indicating no moisture sensitivity limitations during assembly.
