Equivalent & Substitute Parts for 95C06B4GWRT
Part Overview
The Grayhill 95C06B4GWRT is an SPST-NO tactile switch designed for surface mount applications with a contact rating of 0.05A at 12VDC. This component features top actuation, gull wing termination, and polyamide actuator material with 260gf operating force. The part is Active status and ROHS3 compliant with unlimited moisture sensitivity level (MSL 1).
Substitute parts are identified to provide design flexibility when the primary part is unavailable, when alternative actuator heights or operating forces are required for specific mechanical designs, or when different packaging formats better suit production requirements.
Substiute Parts
Key Parameters
| Parameter | Value |
|---|---|
| Manufacturer Part Number | 95C06B4GWRT |
| Manufacturer | Grayhill Inc. |
| Series | 95C |
| Circuit Configuration | SPST-NO |
| Switch Function | Off-Mom |
| Contact Rating | 0.05A @ 12VDC |
| Mounting Type | Surface Mount |
| Actuator Height off PCB | 5.00mm |
| Actuator Orientation | Top Actuated |
| Termination Style | Gull Wing |
| Outline Dimensions | 6.20mm x 6.20mm |
| Operating Force | 260gf |
| Switch Travel | 0.25mm |
| Mechanical Life | 500,000 Cycles |
| Operating Temperature Range | -25°C ~ 70°C |
| Actuator Material | Polyamide (PA), Nylon |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| MSL Rating | 1 (Unlimited) |
| Product Status | Active |
Substitute Part Grouping Explanation
Substitution eligibility for the 95C06B4GWRT is determined by strict alignment of the following critical parameters:
Mandatory Matching Parameters:
- Circuit Configuration: SPST-NO
- Switch Function: Off-Mom
- Contact Rating: 0.05A @ 12VDC
- Mounting Type: Surface Mount
- Actuator Orientation: Top Actuated
- Termination Style: Gull Wing
- Switch Travel: 0.25mm
- Illumination: Non-Illuminated
- RoHS Status: ROHS3 Compliant
- MSL Rating: 1 (Unlimited)
Variable Parameters Allowing Substitution:
- Actuator Height off PCB (5.00mm primary; alternatives range 4.30mm to 13.00mm)
- Operating Force (260gf primary; alternatives include 65gf, 100gf, 160gf)
- Outline Dimensions (6.20mm x 6.20mm primary; 6.00mm x 6.00mm acceptable)
- Mechanical Life (500,000 cycles primary; 100,000 cycles acceptable for lower-cycle applications)
- Operating Temperature Range (-25°C ~ 70°C primary; -20°C ~ 70°C or -30°C ~ 85°C acceptable)
- Packaging Format (Tape & Reel primary; Tube and Cut Tape alternatives available)
- Manufacturer (Grayhill primary; E-Switch alternatives available)
All substitute parts listed are from E-Switch, series TL3301 or LL3301, maintaining electrical equivalence while offering mechanical and packaging variations.
Parameter Comparison
| Parameter | 95C06B4GWRT (Grayhill) | LL3301NF065QG (E-Switch) | TL3301AF100QG (E-Switch) | TL3301AF260QG (E-Switch) | TL3301BF160QGTUBE (E-Switch) | TL3301BF260QGTUBE (E-Switch) | TL3301CF160QG (E-Switch) | TL3301DF260QG (E-Switch) | TL3301EF100QG (E-Switch) | TL3301EF160QG (E-Switch) | TL3301EF260QG (E-Switch) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Circuit Configuration | SPST-NO | SPST-NO | SPST-NO | SPST-NO | SPST-NO | SPST-NO | SPST-NO | SPST-NO | SPST-NO | SPST-NO | SPST-NO |
| Switch Function | Off-Mom | Off-Mom | Off-Mom | Off-Mom | Off-Mom | Off-Mom | Off-Mom | Off-Mom | Off-Mom | Off-Mom | Off-Mom |
| Contact Rating | 0.05A @ 12VDC | 0.05A @ 12VDC | 0.05A @ 12VDC | 0.05A @ 12VDC | 0.05A @ 12VDC | 0.05A @ 12VDC | 0.05A @ 12VDC | 0.05A @ 12VDC | 0.05A @ 12VDC | 0.05A @ 12VDC | 0.05A @ 12VDC |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Actuator Height off PCB (mm) | 5.00 | 4.30 | 5.00 | 5.00 | 9.50 | 9.50 | 8.00 | 13.00 | 7.30 | 7.30 | 7.30 |
| Actuator Orientation | Top Actuated | Top Actuated | Top Actuated | Top Actuated | Top Actuated | Top Actuated | Top Actuated | Top Actuated | Top Actuated | Top Actuated | Top Actuated |
| Termination Style | Gull Wing | Gull Wing | Gull Wing | Gull Wing | Gull Wing | Gull Wing | Gull Wing | Gull Wing | Gull Wing | Gull Wing | Gull Wing |
| Outline Dimensions (mm) | 6.20 x 6.20 | 6.00 x 6.00 | 6.00 x 6.00 | 6.00 x 6.00 | 6.00 x 6.00 | 6.00 x 6.00 | 6.00 x 6.00 | 6.00 x 6.00 | 6.00 x 6.00 | 6.00 x 6.00 | 6.00 x 6.00 |
| Operating Force (gf) | 260 | 65 | 100 | 260 | 160 | 260 | 160 | 260 | 100 | 160 | 260 |
| Switch Travel (mm) | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 |
| Mechanical Life (Cycles) | 500,000 | Not Specified | 100,000 | 100,000 | 100,000 | 100,000 | 100,000 | 100,000 | 100,000 | 100,000 | 100,000 |
| Operating Temperature Range (°C) | -25 ~ 70 | -30 ~ 85 | -20 ~ 70 | -20 ~ 70 | -20 ~ 70 | -20 ~ 70 | -20 ~ 70 | -20 ~ 70 | -20 ~ 70 | -20 ~ 70 | -20 ~ 70 |
| Actuator Material | Polyamide (PA), Nylon | Not Specified | Polyamide (PA), Nylon | Polyamide (PA), Nylon | Polyamide (PA), Nylon | Polyamide (PA), Nylon | Polyamide (PA), Nylon | Polyamide (PA), Nylon | Polyamide (PA), Nylon | Polyamide (PA), Nylon | Polyamide (PA), Nylon |
| Illumination | Non-Illuminated | Non-Illuminated | Non-Illuminated | Non-Illuminated | Non-Illuminated | Non-Illuminated | Non-Illuminated | Non-Illuminated | Non-Illuminated | Non-Illuminated | Non-Illuminated |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tube | Tube | Cut Tape (CT) & Digi-Reel® | Tape & Reel (TR) | Cut Tape (CT) & Digi-Reel® | Tape & Reel (TR) | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| MSL Rating | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) |
| Product Status | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active |
Engineering Selection Recommendations
Direct Electrical Equivalent (Identical Operating Force):
TL3301AF260QG and TL3301EF260QG are direct electrical equivalents to the 95C06B4GWRT, both featuring 260gf operating force and 0.05A @ 12VDC contact rating. TL3301AF260QG maintains the 5.00mm actuator height matching the primary part and is available in Tape & Reel packaging. TL3301EF260QG offers 7.30mm actuator height with Tape & Reel packaging. Both are ROHS3 compliant with MSL 1 rating and Active product status.
Reduced Operating Force Alternatives:
TL3301AF100QG and TL3301EF100QG provide 100gf operating force for applications requiring lighter actuation. TL3301AF100QG maintains 5.00mm height; TL3301EF100QG provides 7.30mm height. Both support identical electrical specifications and are ROHS3 compliant.
Medium Operating Force Alternatives:
TL3301BF160QGTUBE, TL3301CF160QG, and TL3301EF160QG offer 160gf operating force. TL3301BF160QGTUBE is packaged in Tube format with 9.50mm height. TL3301CF160QG is available in Cut Tape format with 8.00mm height. TL3301EF160QG is Tape & Reel packaged with 7.30mm height.
Extended Actuator Height Option:
TL3301DF260QG provides 13.00mm actuator height with 260gf operating force for applications requiring extended reach above the PCB surface.
Lower Operating Force Option:
LL3301NF065QG from E-Switch series LL3301 offers the lowest operating force at 65gf with 4.30mm actuator height and extended temperature range (-30°C ~ 85°C). Mechanical life is not specified for this variant.
All substitute parts maintain ROHS3 compliance, MSL 1 rating, and Active product status. Selection should be based on specific mechanical design requirements for actuator height and operating force, as well as production packaging preferences.
Frequently Asked Questions (FAQ)
Q: Can TL3301AF260QG directly replace 95C06B4GWRT in existing designs?
A: Yes. TL3301AF260QG matches all critical electrical parameters: SPST-NO circuit, 0.05A @ 12VDC contact rating, 260gf operating force, 5.00mm actuator height, 0.25mm switch travel, and gull wing termination. Both are ROHS3 compliant with MSL 1 rating. Outline dimensions differ slightly (6.00mm vs 6.20mm), which is acceptable for most surface mount applications. Verify PCB layout clearances before implementation.
Q: What is the difference between Tape & Reel, Tube, and Cut Tape packaging?
A: Tape & Reel (TR) packaging is standard for automated pick-and-place assembly, with components wound on continuous tape. Tube packaging contains loose components in a plastic tube, suitable for manual assembly or lower-volume production. Cut Tape (CT) & Digi-Reel® provides components on cut tape segments, offering flexibility between automated and manual assembly. Selection depends on production volume and assembly equipment capabilities.
Q: Why do substitute parts show lower mechanical life ratings?
A: The primary part 95C06B4GWRT specifies 500,000 mechanical cycles. Most E-Switch TL3301 series substitutes specify 100,000 cycles. This difference reflects different design specifications and testing standards between manufacturers. For applications requiring extended cycle life, verify that 100,000 cycles meets the intended use case. LL3301NF065QG does not specify mechanical life.
Q: Can I use a substitute with different operating force?
A: Operating force selection depends on the specific application requirements. The primary part uses 260gf. Substitutes with lower operating force (65gf, 100gf, 160gf) require lighter finger pressure for actuation. Substitutes with higher operating force require greater actuation pressure. Select based on user interface requirements and mechanical design constraints. All options maintain identical electrical contact ratings.
Q: Are there temperature range considerations when selecting substitutes?
A: The primary part operates -25°C ~ 70°C. Most E-Switch substitutes operate -20°C ~ 70°C, which is acceptable for most applications. LL3301NF065QG extends to -30°C ~ 85°C for wider temperature range applications. Verify that the selected substitute's temperature range encompasses the intended operating environment.
Q: What actuator height should I select?
A: Actuator height determines how far the button extends above the PCB surface. The primary part uses 5.00mm. Substitutes range from 4.30mm (LL3301NF065QG) to 13.00mm (TL3301DF260QG). Selection depends on mechanical enclosure design, user interface requirements, and clearance constraints. Verify that the selected height accommodates the intended button cap or user interface design.
Q: Are all substitutes ROHS3 compliant?
A: Yes. All listed substitute parts are ROHS3 compliant with MSL 1 (Unlimited) rating, matching the primary part's compliance status. All parts are Active product status from their respective manufacturers.
Q: Can I mix different substitute parts in the same design?
A: Yes, provided the application does not require identical actuation characteristics across all switches. If consistent user interface feel is required, select substitutes with matching operating force. If different actuation forces are intentional (e.g., primary vs. secondary functions), different operating force ratings are acceptable.
