3M 953230-2000-AR-PR Equivalent & Substitute Parts

Part Overview

The 3M 953230-2000-AR-PR is a 30-position rectangular receptacle connector with 0.079" (2.00mm) pitch, designed for surface mount board-to-board applications. This connector features gold-plated mating contacts, push-pull fastening, and operates across -40°C to 105°C. The part is classified as obsolete, making equivalent substitute parts necessary for ongoing production and maintenance applications.

Key Parameters

Parameter	Value
Manufacturer Part Number	953230-2000-AR-PR
Manufacturer	3M
Category	Rectangular Connectors
Connector Type	Receptacle, Bottom or Top Entry
Number of Positions	30
Pitch - Mating	0.079" (2.00mm)
Number of Rows	2
Row Spacing - Mating	0.079" (2.00mm)
Mounting Type	Surface Mount
Contact Finish - Mating	Gold
Fastening Type	Push-Pull
Operating Temperature	-40°C ~ 105°C
Current Rating	1A
Voltage Rating	1000VDC
Material Flammability Rating	UL94 V-0
Product Status	Obsolete

Substitute Part Grouping Explanation

Substitution eligibility for the 3M 953230-2000-AR-PR is determined by the following critical parameters:

30-position configuration with 2-row layout
0.079" (2.00mm) mating pitch and row spacing
Surface mount termination with solder connection
Receptacle connector type with female socket contacts
Push-pull fastening mechanism
Gold contact finish on mating surfaces
Board-to-board connectivity style
UL94 V-0 flammability rating

The substitute parts listed below maintain these core electrical and mechanical specifications, ensuring functional compatibility within the connector interface.

Parameter Comparison

Parameter	3M 953230-2000-AR-PR	Molex 0872633093	Molex 0873813017	Molex 0873813018
Manufacturer	3M	Molex	Molex	Molex
Series	953	Milli-Grid 87263	Milli-Grid 87381	Milli-Grid 87381
Connector Type	Receptacle, Bottom or Top Entry	Receptacle, Bottom Entry	Receptacle	Receptacle
Number of Positions	30	30	30	30
Pitch - Mating	0.079" (2.00mm)	0.079" (2.00mm)	0.079" (2.00mm)	0.079" (2.00mm)
Number of Rows	2	2	2	2
Row Spacing - Mating	0.079" (2.00mm)	0.079" (2.00mm)	0.079" (2.00mm)	0.079" (2.00mm)
Mounting Type	Surface Mount	Surface Mount	Surface Mount	Surface Mount
Termination	Solder	Solder	Solder	Solder
Fastening Type	Push-Pull	Push-Pull	Push-Pull	Push-Pull
Contact Finish - Mating	Gold	Gold	Gold	Gold
Contact Type	Female Socket	Female Socket	Female Socket	Female Socket
Style	Board to Board	Board to Board or Cable	Board to Board	Board to Board
Operating Temperature	-40°C ~ 105°C	-55°C ~ 105°C	-55°C ~ 105°C	-55°C ~ 105°C
Current Rating (Amps)	1A	1A	1.9A	1.9A
Voltage Rating	1000VDC	125VAC	125V	125V
Material Flammability Rating	UL94 V-0	UL94 V-0	-	-
Product Status	Obsolete	Active	Active	Active
Insulation Height	0.169" (4.30mm)	0.110" (2.79mm)	0.157" (4.00mm)	0.157" (4.00mm)
Contact Finish Thickness - Mating	Flash	15.0µin (0.38µm)	30.0µin (0.76µm)	15.0µin (0.38µm)
Moisture Sensitivity Level (MSL)	1 (Unlimited)	1 (Unlimited)	1 (Unlimited)	1 (Unlimited)
ECCN	EAR99	EAR99	EAR99	EAR99
HTSUS	8536.69.4040	8536.69.4040	8536.69.4040	8536.69.4040

Engineering Selection Recommendations

All three Molex substitute parts maintain the core mechanical and electrical interface specifications required for direct substitution with the 3M 953230-2000-AR-PR. The following considerations apply:

Molex 0872633093 is an active product in the Milli-Grid 87263 series with ROHS3 compliance and REACH unaffected status. This part supports both board-to-board and cable applications, offering expanded design flexibility. The reduced insulation height (0.110" vs. 0.169") may require PCB layout verification for clearance compatibility.

Molex 0873813017 and Molex 0873813018 are active products in the Milli-Grid 87381 series with ROHS3 compliance and REACH unaffected status. Both parts feature increased current rating (1.9A vs. 1A) and extended insulation height (0.157" vs. 0.169"), providing improved thermal performance and mechanical robustness. The primary difference between these two parts is the contact finish thickness on mating surfaces: 0873813017 provides 30.0µin (0.76µm) while 0873813018 provides 15.0µin (0.38µm).

All substitute parts are classified as MSL 1 (Unlimited) and carry identical export classification (EAR99) and tariff codes (8536.69.4040) as the original part.

Frequently Asked Questions (FAQ)

Q: Can Molex 0872633093 be used as a direct replacement for the 3M 953230-2000-AR-PR?

A: Yes. Both parts share identical mating pitch (0.079"), position count (30), row configuration (2), surface mount termination, push-pull fastening, and gold contact finish. The primary design consideration is the reduced insulation height of the Molex part (0.110" vs. 0.169"), which requires verification that PCB layout and component clearances remain compatible.

Q: What is the difference between Molex 0873813017 and 0873813018?

A: Both parts are functionally equivalent 30-position receptacles with identical electrical and mechanical specifications. The distinction is the contact finish thickness on mating surfaces: 0873813017 provides 30.0µin (0.76µm) while 0873813018 provides 15.0µin (0.38µm). Selection depends on application-specific contact wear and durability requirements.

Q: Are the Molex substitutes compliant with the same standards as the original 3M part?

A: The Molex 0872633093, 0873813017, and 0873813018 all carry ROHS3 compliance and REACH unaffected status. The original 3M part does not specify these certifications. All parts share identical MSL rating (1 - Unlimited), ECCN classification (EAR99), and HTSUS code (8536.69.4040).

Q: What is the voltage rating difference between the original and substitute parts?

A: The 3M 953230-2000-AR-PR is rated for 1000VDC, while the Molex substitutes are rated for 125VAC or 125V. Application voltage requirements must be verified to ensure the substitute part meets system specifications.

Q: Can the Molex 0872633093 be used in cable applications?

A: Yes. The Molex 0872633093 supports both board-to-board and cable connectivity styles, whereas the original 3M part and the other Molex substitutes (0873813017, 0873813018) are specified for board-to-board applications only.

Q: What packaging options are available for these substitute parts?

A: The Molex 0872633093 packaging is not specified in the available data. The Molex 0873813017 and 0873813018 are supplied in Tube packaging. The original 3M part is supplied in Cut Tape (CT) packaging.
