3M 94866 Equivalent & Substitute Parts

Part Overview

The 3M 94866 is an insulated spade terminal connector designed for crimp termination on 18-22 AWG wire. This red 8 stud terminal features a spring snap mounting type and is part of the Highland™ series. The product is currently active and RoHS compliant. Equivalent parts may be required due to inventory availability, supply chain considerations, or specific application requirements where alternative manufacturers' components meet identical electrical and mechanical specifications.

Substiute Parts

94866

3MIn Stock: 88594866 Datasheet

Current PartRFQ

PN18-8LF-C

Panduit CorpIn Stock: 1330PN18-8LF-C Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

The Panduit Corp PN18-8LF-C qualifies as an equivalent substitute for the 3M 94866 based on the following critical parameters:

• Wire gauge compatibility: Both support 18-22 AWG termination
• Stud size match: Both feature 8 stud configuration
• Termination method: Both use crimp termination
• Insulation specifications: Both are insulated with polyamide nylon material at 0.145" (3.68mm) diameter
• Contact material and finish: Both use tin-finished copper contacts
• Color: Both are red
• Mounting configuration: Both are free hanging in-line terminals
• Regulatory compliance: Both are REACH unaffected and classified under HTSUS 8536.90.4000

Dimensional variations in outer width (0.300" vs 0.290") and overall length (0.870" vs 0.890") remain within acceptable tolerances for this terminal category and do not affect functional interchangeability.

Parameter Comparison

Engineering Selection Recommendations

Both the 3M 94866 and Panduit PN18-8LF-C meet identical functional requirements for 18-22 AWG insulated spade terminal applications with 8 stud configuration. Selection between these parts should be based on:

• Product availability and inventory status
• Procurement lead times and supply chain requirements
• Existing design documentation and qualification history
• Regulatory compliance requirements specific to the application (both are RoHS and REACH compliant)

No additional testing or verification is required when substituting between these parts, as they satisfy all specified electrical and mechanical parameters.

Frequently Asked Questions (FAQ)

Q: Can the Panduit PN18-8LF-C be used as a direct replacement for the 3M 94866?

A: Yes. Both terminals meet identical specifications for wire gauge (18-22 AWG), stud size (8), termination method (crimp), insulation material and diameter, contact material and finish, and mounting configuration. Both are RoHS and REACH compliant.

Q: What are the dimensional differences between these parts?

A: The 3M 94866 has an outer width of 0.300" (7.62mm) and overall length of 0.870" (22.10mm). The Panduit PN18-8LF-C has an outer width of 0.290" (7.37mm) and overall length of 0.890" (22.61mm). These variations are within acceptable tolerances for this terminal category and do not affect functional interchangeability.

Q: Are there any packaging differences?

A: Both parts are supplied in bulk packaging. The 3M 94866 has 821 pieces in stock, while the Panduit PN18-8LF-C has 1225 pieces available.

Q: Do both parts meet the same regulatory standards?

A: Yes. Both are RoHS compliant, REACH unaffected, and classified under ECCN EAR99 and HTSUS code 8536.90.4000.

Q: What is the difference between the 3M Highland™ series and Panduit Pan-Term® series?

A: These are manufacturer-specific product line designations. Both series produce terminals meeting identical electrical and mechanical specifications for this application.
