3M 94767 Equivalent & Substitute Parts Reference

Part Overview

The 3M 94767 is a red insulated spade terminal connector designed for 18-22 AWG wire gauges with a #10 stud connection. This component is classified as obsolete, necessitating identification of active equivalent parts for ongoing procurement and system maintenance. The terminal features a crimp termination method, tin contact finish, and copper ETP contact material, making it suitable for standard electrical interconnection applications requiring reliable mechanical and electrical performance.

Substiute Parts

94767

3MIn Stock: 101094767 Datasheet

Current PartRFQ

MVU18-10FX-BOTTLE

3MIn Stock: 1116MVU18-10FX-BOTTLE Datasheet

DirectRFQ

PV18-10F-CY

Panduit CorpIn Stock: 1244PV18-10F-CY Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the 3M 94767 is determined by strict equivalence across the following critical parameters: wire gauge range (18-22 AWG), stud size (#10), termination method (crimp), insulation type (insulated vinyl), color (red), contact material (copper), contact finish (tin), and mounting configuration (free hanging in-line). Both identified substitute parts satisfy these core electrical and mechanical requirements, enabling direct functional replacement in applications originally specified for the 94767.

Parameter Comparison

Engineering Selection Recommendations

The 3M MVU18-10FX-BOTTLE serves as the primary equivalent substitute, maintaining identical electrical and mechanical specifications while offering active product status and continued manufacturer support. This part is sourced from the same manufacturer (3M) and represents the direct evolution within the Scotchlok™ series.

The Panduit PV18-10F-CY provides an alternative cross-manufacturer substitute meeting all critical functional parameters. This option is designated as manufacturer-recommended and maintains active status with ROHS3 compliance certification. Minor dimensional variations exist (width 0.350" versus 0.340", overall length 0.930" versus 0.900") within acceptable engineering tolerances for standard spade terminal applications.

Both substitutes are RoHS and REACH compliant, ensuring regulatory alignment for current procurement requirements.

Frequently Asked Questions (FAQ)

Q: Can the 3M MVU18-10FX-BOTTLE directly replace the 3M 94767 in existing designs?

A: Yes. The MVU18-10FX-BOTTLE maintains identical wire gauge (18-22 AWG), stud size (#10), termination method (crimp), insulation type (vinyl), color (red), contact material (copper ETP), and contact finish (tin). Functional equivalence is confirmed across all critical parameters.

Q: What is the primary difference between the two substitute options?

A: The 3M MVU18-10FX-BOTTLE is a same-manufacturer substitute within the Scotchlok™ series. The Panduit PV18-10F-CY is a cross-manufacturer alternative from the Pan-Term® series. Both meet functional requirements; selection depends on supply chain preference and existing inventory management protocols.

Q: Are there dimensional differences between the 94767 and the Panduit substitute?

A: Minor dimensional variations exist. The Panduit PV18-10F-CY has a width of 0.350" (versus 0.340") and overall length of 0.930" (versus 0.900"). These variations remain within standard engineering tolerances for free-hanging spade terminal applications and do not affect electrical performance or mechanical compatibility with #10 studs.

Q: What packaging considerations apply to these substitutes?

A: The 3M 94767 is supplied in standard packaging. The 3M MVU18-10FX-BOTTLE is packaged in bulk (100-piece containers). The Panduit PV18-10F-CY is also supplied in bulk packaging. Verify packaging requirements against procurement specifications before ordering.

Q: Are both substitutes compliant with current regulatory standards?

A: Yes. Both the 3M MVU18-10FX-BOTTLE and Panduit PV18-10F-CY are RoHS compliant and REACH unaffected. The Panduit option carries ROHS3 certification, representing the latest regulatory compliance standard.
