TE Connectivity AMP Connectors 928247-7 Equivalent & Substitute Parts

Part Overview

The TE Connectivity AMP Connectors 928247-7 is a 7-position rectangular connector receptacle housing designed for applications requiring crimp-terminated female socket contacts with a 5.00mm pitch. This connector operates across an industrial temperature range of -40°C to 110°C and features a latch lock fastening mechanism suitable for free-hanging in-line mounting configurations. The part is actively manufactured and RoHS3 compliant, making it suitable for modern electronic assemblies. Substitute parts are identified when equivalent electrical and mechanical parameters are maintained across the connector housing specifications, allowing for component interchangeability in production and field applications.

Substiute Parts

928247-7

TE Connectivity AMP ConnectorsIn Stock: 1016928247-7 Datasheet

Current PartRFQ

3-928247-7

TE Connectivity AMP ConnectorsIn Stock: 7233-928247-7 Datasheet

Parametric EquivalentRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of rectangular connector housings is determined by strict equivalence across electrical and mechanical parameters. The primary substitution criteria for the 928247-7 are:

Critical Matching Parameters:

• Connector type (Receptacle)
• Contact type (Female Socket)
• Number of positions (7)
• Pitch specification (0.197" / 5.00mm)
• Number of rows (1)
• Mounting type (Free Hanging In-Line)
• Contact termination method (Crimp)
• Fastening mechanism (Latch Lock)
• Operating temperature range (-40°C ~ 110°C)
• Insulation material family (Polyamide/Nylon)

The substitute part 3-928247-7 maintains all critical electrical and mechanical parameters with the main part. The only variation is the housing color (Natural versus Gray), which does not affect electrical performance, mechanical fit, or thermal characteristics. Both parts share the same base product number (928247) and are manufactured by TE Connectivity AMP Connectors, confirming design compatibility.

Parameter Comparison

Engineering Selection Recommendations

Both the 928247-7 and 3-928247-7 are active products manufactured by TE Connectivity AMP Connectors and maintain full compliance with RoHS directives. The 928247-7 carries RoHS3 certification, while the 3-928247-7 carries RoHS compliance designation. Both parts are classified as REACH Unaffected or Vendor Undefined, indicating no regulatory restrictions on their use in applicable markets.

Selection between these parts should be based on application-specific requirements:

928247-7 (Gray Housing): Suitable for applications where housing color coding is required for visual identification or where gray coloration aligns with existing assembly standards. Current inventory: 931 pieces.

3-928247-7 (Natural Housing): Suitable for applications where natural housing color is preferred or where color-coding schemes do not require gray designation. Current inventory: 625 pieces.

Both parts are electrically and mechanically interchangeable. The choice between them does not affect connector performance, mating characteristics, or thermal operation within the specified -40°C to 110°C range. Contacts are not included with either housing and must be sourced separately.

Frequently Asked Questions (FAQ)

Q: Are the 928247-7 and 3-928247-7 electrically interchangeable?

A: Yes. Both parts are 7-position receptacle housings with identical electrical specifications, including female socket contact type, 5.00mm pitch, crimp termination, and latch lock fastening. They operate across the same temperature range (-40°C to 110°C) and carry equivalent moisture sensitivity ratings.

Q: What is the difference between these two parts?

A: The primary difference is housing color. The 928247-7 features a gray housing, while the 3-928247-7 features a natural (undyed) housing. All electrical and mechanical parameters are equivalent.

Q: Can I use the 3-928247-7 as a direct replacement for the 928247-7 in existing designs?

A: Yes, provided that housing color is not a functional or identification requirement in your application. The connector housings are mechanically and electrically identical in all other respects.

Q: Do these housings include contacts?

A: No. Both the 928247-7 and 3-928247-7 are housings only. Contacts must be sourced separately and installed using the crimp termination method.

Q: What is the pitch specification, and why is it important?

A: The pitch is 0.197 inches (5.00mm), which is the center-to-center distance between adjacent contact positions. This specification determines mating compatibility with corresponding plug connectors and must be matched exactly for proper connection.

Q: Are both parts RoHS compliant?

A: Yes. The 928247-7 is RoHS3 compliant, and the 3-928247-7 is RoHS compliant. Both meet regulatory requirements for lead-free and restricted substance compliance.

Q: What mounting configuration do these connectors support?

A: Both parts are designed for free-hanging in-line mounting, meaning they are mounted directly to cable assemblies without requiring a panel or backplate mounting surface.

Q: What is the operating temperature range?

A: Both connectors operate across -40°C to 110°C, making them suitable for industrial and automotive applications requiring extended temperature performance.
