Amphenol ICC 89094-102 Backplane Connector Equivalent & Substitute Parts

Part Overview

The Amphenol ICC 89094-102 is a 120-position receptacle connector designed for board edge mounting applications. This connector features female sockets with press-fit termination and is part of the Metral® B series. The part is currently active in production with substantial inventory availability. Alternative part numbers and manufacturer equivalents are available to support procurement flexibility, supply chain continuity, and specific compliance requirements.

Substiute Parts

89094-102

Amphenol ICC (FCI)In Stock: 1033789094-102 Datasheet

Current PartRFQ

89094-102LF

Amphenol ICC (FCI)In Stock: 1029689094-102LF Datasheet

DirectRFQ

223008-4

TE Connectivity AMP ConnectorsIn Stock: 886223008-4 Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitute parts for the 89094-102 are classified based on strict electrical and mechanical parameter alignment:

Direct Manufacturer Equivalent (89094-102LF): This part maintains identical specifications across all critical parameters including connector type, position count, pitch, mounting configuration, termination method, contact finish, current rating, voltage rating, and operating temperature range. The primary distinction is packaging format (Tube) and RoHS compliance status (RoHS Compliant versus RoHS non-compliant). This part is functionally interchangeable for all applications.

Cross-Manufacturer Substitute (TE Connectivity 223008-4): This part shares the core mechanical and electrical architecture: 120-position receptacle configuration, 0.079" pitch, board edge mounting, press-fit termination, and identical contact finish specifications. However, this substitute operates within different electrical parameters (30V voltage rating versus 1000V) and an extended operating temperature range (-55°C ~ 125°C versus -55°C ~ 105°C). The connector style designation (Futurebus) and series classification (Z-PACK) differ from the Metral® B series. This part is suitable only for applications where the lower voltage rating and extended temperature capability are compatible with system requirements.

Parameter Comparison

Engineering Selection Recommendations

For Direct Substitution (89094-102LF): Select this part when RoHS compliance is required. The 89094-102LF maintains full electrical and mechanical compatibility with the 89094-102 while meeting RoHS Compliant status. Both parts are produced by Amphenol ICC within the Metral® B series and carry identical performance specifications. Inventory levels support both options.

For Cross-Manufacturer Substitution (223008-4): This TE Connectivity part is suitable only when system design specifications accommodate a 30V maximum voltage rating and extended operating temperature range to 125°C. The lower voltage rating represents a significant functional constraint and must be verified against application requirements before selection. The reduced inventory level (803 units) should be considered for supply chain planning. REACH Affected status requires compliance verification for regulated markets.

Primary Selection Criteria: Voltage rating compatibility is the determining factor for cross-manufacturer substitution. The 89094-102LF is the preferred alternative within the Amphenol ICC product line for all applications requiring RoHS compliance.

Frequently Asked Questions (FAQ)

Q: Can 89094-102LF be used as a direct replacement for 89094-102?

A: Yes. The 89094-102LF is a direct functional equivalent with identical electrical and mechanical specifications. The only differences are packaging format (Tube) and RoHS compliance status. Selection between these parts depends on compliance requirements and packaging preferences.

Q: What is the primary limitation of the TE Connectivity 223008-4 substitute?

A: The 223008-4 operates at a maximum voltage rating of 30V, compared to 1000V for the Amphenol ICC parts. This represents a significant electrical constraint and must be verified as compatible with your application before selection.

Q: Are all three parts mechanically interchangeable?

A: Yes, all three parts share identical mechanical specifications: 120-position configuration, 0.079" pitch, 5-row layout, board edge mounting, and right-angle orientation. Mechanical interchangeability is confirmed across all three options.

Q: Which part should be selected for new designs requiring RoHS compliance?

A: The 89094-102LF is the recommended selection for RoHS-compliant applications. It maintains full compatibility with the original 89094-102 specification while meeting RoHS Compliant status.

Q: What is the difference between the packaging options?

A: The 89094-102 is supplied in standard packaging, while the 89094-102LF is supplied in Tube packaging. Both contain identical connector components; packaging format is the only distinction.

Q: Can the TE Connectivity 223008-4 be used in high-voltage applications?

A: No. The 223008-4 is rated for 30V maximum, making it unsuitable for applications requiring the 1000V rating of the Amphenol ICC parts. Voltage rating compatibility must be confirmed before selection.
