Amphenol ICC 89035-102 Backplane Connector Equivalent & Substitute Parts

Part Overview

The Amphenol ICC 89035-102 is a 24-position receptacle connector with female sockets designed for board edge mounting applications. This connector features through-hole, right-angle termination and is part of the Metral® series. The part is currently classified as obsolete, making identification of equivalent and substitute components essential for ongoing system support and procurement planning.

Substiute Parts

89035-102

Amphenol ICC (FCI)In Stock: 104289035-102 Datasheet

Current PartRFQ

89035-102LF

Amphenol ICC (FCI)In Stock: 317189035-102LF Datasheet

DirectRFQ

536507-1

TE Connectivity AMP ConnectorsIn Stock: 903536507-1 Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution for the 89035-102 is determined by the following critical parameters that must remain consistent:

• Number of positions: 24
• Pitch: 0.079" (2.00mm)
• Number of rows: 4
• Connector type: Receptacle, Female Sockets
• Mounting type: Board Edge, Through Hole, Right Angle
• Termination: Solder
• Contact finish: Gold
• Material flammability rating: UL94 V-0

The direct substitute 89035-102LF maintains all these parameters while offering improved compliance status. The TE Connectivity 536507-1 shares the core mechanical and electrical configuration but operates within different voltage and temperature specifications, requiring engineering evaluation for specific applications.

Parameter Comparison

Engineering Selection Recommendations

The 89035-102LF is the primary substitute for the obsolete 89035-102. Both parts are manufactured by Amphenol ICC and maintain identical electrical and mechanical specifications. The 89035-102LF offers the advantage of active product status and RoHS compliance, making it suitable for new designs and systems requiring regulatory compliance. Current inventory of 3144 units is available.

The TE Connectivity 536507-1 shares the same mechanical form factor and mounting configuration but operates at significantly lower voltage ratings (30V versus 1000V). This part is also obsolete and RoHS non-compliant. Selection of this alternative requires confirmation that the application voltage requirements do not exceed 30V and that the extended operating temperature range to 125°C is beneficial to the system design.

Frequently Asked Questions (FAQ)

Q: Can the 89035-102LF be used as a direct replacement for the 89035-102?

A: Yes. The 89035-102LF maintains all critical electrical and mechanical parameters including 24 positions, 2.00mm pitch, 4-row configuration, 1A current rating, and 1000V voltage rating. The primary differences are product status (active versus obsolete) and RoHS compliance status.

Q: What is the significance of the "LF" suffix in the 89035-102LF part number?

A: The "LF" designation indicates lead-free termination and RoHS compliance. This part meets current environmental and regulatory requirements for electronic components.

Q: Is the TE Connectivity 536507-1 compatible with applications designed for the 89035-102?

A: Mechanical and mounting compatibility exists. However, the 536507-1 operates at 30V maximum voltage compared to the 1000V rating of the 89035-102. Applications requiring the full 1000V rating cannot use this substitute. Confirmation of actual system voltage requirements is necessary before selection.

Q: What packaging differences exist between these parts?

A: The 89035-102 and 536507-1 have unspecified packaging. The 89035-102LF is supplied in tube packaging, which may affect procurement and handling procedures.

Q: Are there compliance considerations when selecting a substitute?

A: The 89035-102LF is RoHS compliant and REACH affected, making it suitable for applications with regulatory compliance requirements. The original 89035-102 and the TE Connectivity 536507-1 are both RoHS non-compliant. All three parts carry UL94 V-0 flammability ratings.
