TE Connectivity AMP Connectors 8-53222-3 Equivalent & Substitute Parts

Part Overview

The TE Connectivity AMP Connectors 8-53222-3 is a 3-way splice terminal connector designed for crimp termination of 14-16 AWG wire gauges. This component features partial insulation with a serrated mating area and is manufactured in blue. The part is classified as obsolete, making identification of active equivalent alternatives necessary for ongoing procurement and system maintenance.

Substiute Parts

8-53222-3

TE Connectivity AMP ConnectorsIn Stock: 8548-53222-3 Datasheet

Current PartRFQ

53222-1

TE Connectivity AMP ConnectorsIn Stock: 199853222-1 Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the obsolete 8-53222-3 is based on electrical and mechanical parameter equivalence within the PIDG series. The substitute part 53222-1 maintains identical specifications across all critical parameters: terminal type (3-way splice), wire gauge range (14-16 AWG), termination method (crimp), insulation classification (partial insulation), mating area design (serrated), color (blue), and wire entry count (3). Both parts share the same base product number (53222) and are manufactured by TE Connectivity AMP Connectors.

The primary distinction between these parts is product status: 8-53222-3 is obsolete while 53222-1 is active. Additionally, 53222-1 carries RoHS Compliant certification, whereas the original part's RoHS status is not applicable.

Parameter Comparison

Engineering Selection Recommendations

The substitute part 53222-1 is the direct equivalent for the obsolete 8-53222-3. All electrical and mechanical parameters are identical, ensuring functional compatibility in applications requiring 3-way splice terminals for 14-16 AWG crimp connections.

The active product status of 53222-1 ensures ongoing availability and supply chain continuity. The RoHS Compliant certification of 53222-1 provides compliance advantage for applications subject to RoHS regulations, whereas the original part's RoHS status is not applicable.

Both parts share identical moisture sensitivity levels (MSL 1 - Unlimited), export classifications (ECCN EAR99), and tariff codes (HTSUS 8536.90.4000), confirming their equivalence for regulatory and logistics purposes.

Frequently Asked Questions (FAQ)

Q: Can 53222-1 be used as a direct replacement for 8-53222-3?

A: Yes. The substitute part 53222-1 maintains identical specifications for terminal type, wire gauge, termination method, insulation, color, and mating area design. All critical electrical and mechanical parameters are equivalent.

Q: What is the primary reason for substitution?

A: The original part 8-53222-3 is classified as obsolete. The substitute 53222-1 is an active product from the same manufacturer and series, ensuring continued availability and procurement reliability.

Q: Are there packaging differences between these parts?

A: The original part 8-53222-3 packaging is not specified in the available data. The substitute part 53222-1 is supplied in bulk packaging.

Q: Does the RoHS Compliant status of 53222-1 affect compatibility?

A: No. RoHS compliance is an environmental and regulatory attribute that does not affect electrical or mechanical compatibility. The RoHS Compliant certification of 53222-1 provides additional compliance benefit for regulated applications.

Q: Are the moisture sensitivity levels identical?

A: Yes. Both parts carry MSL 1 (Unlimited), indicating identical moisture handling and storage requirements.

Q: What wire gauges are supported by these connectors?

A: Both parts support 14-16 AWG wire gauges for crimp termination applications.
