TE Connectivity AMP Connectors 767056-5 Equivalent & Substitute Parts

Part Overview

The TE Connectivity AMP Connectors 767056-5 is a 190 Position Connector Plug with outer shroud contacts designed for surface mount applications. This rectangular connector features palladium-nickel contact finish and is part of the MICTOR series. The part is classified as obsolete, making identification of equivalent and substitute components essential for ongoing production support, maintenance, and design continuity. Substitute parts maintain functional compatibility while offering improved product status and availability.

Substiute Parts

767056-5

TE Connectivity AMP ConnectorsIn Stock: 1117767056-5 Datasheet

Current PartRFQ

5767056-5

TE Connectivity AMP ConnectorsIn Stock: 10355767056-5 Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of rectangular connectors is determined by strict equivalence across electrical and mechanical parameters. The primary substitute for 767056-5 is identified based on the following critical parameters:

Substitution Criteria:

• Connector type and contact configuration (Plug, Outer Shroud Contacts)
• Position count and row configuration (190 positions, 2 rows)
• Contact pitch (0.025" / 0.64mm)
• Mounting technology (Surface Mount)
• Contact finish specification (Palladium-Nickel, 5.00µin thickness)
• Physical dimensions (Height above board, mated stacking heights)
• Series designation (MICTOR)
• Compliance certifications (RoHS, REACH, ECCN)

The substitute part 5767056-5 maintains complete electrical and mechanical compatibility with the original 767056-5 while offering active product status and improved availability.

Parameter Comparison

Engineering Selection Recommendations

Primary Substitute: 5767056-5

The part 5767056-5 is the direct equivalent substitute for 767056-5. Both components are manufactured by TE Connectivity AMP Connectors and maintain identical electrical and mechanical specifications across all critical parameters including connector type, position count, pitch, mounting technology, contact finish, and physical dimensions.

The substitute part offers the following advantages:

• Active Product Status: 5767056-5 maintains active product status, ensuring continued manufacturer support and availability, whereas 767056-5 is classified as obsolete.
• Enhanced Compliance: 5767056-5 is ROHS3 compliant, representing the current RoHS standard, compared to the original RoHS compliant designation.
• Regulatory Alignment: Both parts maintain EAR99 ECCN classification and identical HTSUS codes, ensuring consistent export and import compliance.
• Packaging Specification: 5767056-5 is supplied in tube packaging, providing standardized handling and storage.

No electrical or mechanical redesign is required when transitioning from 767056-5 to 5767056-5. The substitute part is suitable for direct replacement in all applications where the original component was specified.
