Amphenol ICC 76314-222 Equivalent & Substitute Parts

Part Overview

The Amphenol ICC 76314-222 is a 44-position receptacle connector with 0.100" (2.54mm) pitch, designed for through-hole PCB mounting with gold-plated mating contacts. This BergCon® series connector features push-pull fastening and solder termination for board-to-board or cable applications. The part is classified as obsolete, necessitating identification of active equivalent alternatives that maintain electrical and mechanical compatibility while meeting current RoHS and compliance requirements.

Key Parameters

Parameter	Value
Connector Type	Receptacle
Contact Type	Female Socket
Number of Positions	44
Pitch - Mating	0.100" (2.54mm)
Number of Rows	2
Row Spacing - Mating	0.100" (2.54mm)
Mounting Type	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Insulation Material	Thermoplastic, Polyester, Glass Filled
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS non-compliant
Product Status	Obsolete

Substitute Part Grouping Explanation

Substitution for the 76314-222 is determined by strict alignment of the following critical parameters:

Connector Type & Contact Configuration: Receptacle with female socket contacts
Position Count & Pitch: 44 positions at 0.100" (2.54mm) mating pitch
Row Configuration: 2 rows with 0.100" (2.54mm) row spacing
Mounting & Termination: Through-hole PCB mounting with solder termination
Fastening Mechanism: Push-pull fastening system
Mating Contact Finish: Gold plating on mating surfaces
Insulation Material & Flammability: UL94 V-0 rated thermoplastic or polyester glass-filled insulation

Substitute parts are grouped into two categories:

Category A - Direct Electrical & Mechanical Equivalents (Molex C-Grid Series) Parts 0015445144, 0015445844, and 0015446844 maintain identical position count, pitch, row configuration, and push-pull fastening. These Molex receptacles are active products with RoHS3 compliance and equivalent through-hole solder termination.

Category B - Functional Equivalents (Preci-Dip 416 & 803 Series) Parts 416-83-244-41-007101, 416-83-244-41-012101, 416-87-244-41-007101, 416-87-244-41-012101, and 803-83-044-10-005101 provide 44-position socket connectivity at 0.100" pitch with gold mating contact finish, UL94 V-0 insulation, and push-pull fastening. These are active products with RoHS3 compliance.

Parameter Comparison

Part Number	Manufacturer	Connector Type	Positions	Pitch (mm)	Rows	Contact Finish - Mating	Mounting	Termination	Fastening	Flammability	RoHS Status	Product Status
76314-222	Amphenol ICC	Receptacle	44	2.54	2	Gold	Through Hole	Solder	Push-Pull	UL94 V-0	Non-compliant	Obsolete
0015445144	Molex	Receptacle	44	2.54	2	Gold	Through Hole	Solder	Push-Pull	UL94 V-0	ROHS3 Compliant	Active
0015445844	Molex	Receptacle	44	2.54	2	Gold	Through Hole	Solder	Push-Pull	UL94 V-0	ROHS3 Compliant	Active
0015446844	Molex	Receptacle	44	2.54	2	Tin	Through Hole	Solder	Push-Pull	UL94 V-0	ROHS3 Compliant	Active
0901512144	Molex	Receptacle	44	2.54	2	Tin	Through Hole	Solder	Push-Pull	Not specified	ROHS3 Compliant	Active
416-83-244-41-007101	Preci-Dip	Socket	44	2.54	2	Gold	Through Hole	Solder	Push-Pull	UL94 V-0	ROHS3 Compliant	Active
416-83-244-41-012101	Preci-Dip	Socket	44	2.54	2	Gold	Through Hole	Solder	Push-Pull	UL94 V-0	ROHS3 Compliant	Active
416-87-244-41-007101	Preci-Dip	Socket	44	2.54	2	Gold	Through Hole	Solder	Push-Pull	UL94 V-0	ROHS3 Compliant	Active
416-87-244-41-012101	Preci-Dip	Socket	44	2.54	2	Gold	Through Hole	Solder	Push-Pull	UL94 V-0	ROHS3 Compliant	Active
803-83-044-10-005101	Preci-Dip	Socket	44	2.54	2	Gold	Through Hole	Solder	Push-Pull	UL94 V-0	ROHS3 Compliant	Active

Engineering Selection Recommendations

Primary Recommendation: Molex 0015445144

The Molex 0015445144 provides the closest functional match to the 76314-222. Both are 44-position receptacles with identical 0.100" pitch, 2-row configuration, push-pull fastening, and gold mating contact finish. The Molex part is an active product with ROHS3 compliance, addressing the obsolescence and regulatory status of the original part. Current rating of 2.5A and 500VAC voltage rating are specified for the Molex alternative.

Secondary Recommendation: Molex 0015445844

The Molex 0015445844 maintains identical mechanical and electrical specifications to 0015445144, with the distinction of reduced gold contact finish thickness (15.0µin vs. 30.0µin). This part is active and ROHS3 compliant, suitable for applications where contact finish thickness variation is acceptable.

Alternative for Tin Finish Requirement: Molex 0015446844 or 0901512144

If tin mating contact finish is required instead of gold, Molex 0015446844 (C-Grid 71850 series) or 0901512144 (C-Grid III 90151 series) provide 44-position receptacles with tin plating, push-pull fastening, and through-hole solder termination. Both are active, ROHS3-compliant products. The 0901512144 operates across -55°C to 105°C with 3A current rating and 350V voltage rating.

Preci-Dip Socket Alternatives: 416 and 803 Series

The Preci-Dip 416 and 803 series socket connectors (416-83-244-41-007101, 416-83-244-41-012101, 416-87-244-41-007101, 416-87-244-41-012101, 803-83-044-10-005101) are active, ROHS3-compliant products with 44-position gold-plated socket contacts at 0.100" pitch. These parts maintain push-pull fastening and UL94 V-0 insulation. Differences in insulation height and contact length post are provided in the detailed specifications. These are suitable where socket-type female contacts are functionally equivalent to receptacle contacts in the application.

Frequently Asked Questions (FAQ)

Q: Can the Molex 0015445144 directly replace the Amphenol ICC 76314-222?

A: Yes. Both parts share identical position count (44), mating pitch (0.100"), row configuration (2 rows at 0.100" spacing), connector type (receptacle), contact type (female socket), mounting method (through-hole), termination (solder), fastening (push-pull), and mating contact finish (gold). The Molex part is an active product with current RoHS3 compliance, whereas the original is obsolete and RoHS non-compliant.

Q: What is the difference between the Molex C-Grid 71850 series and C-Grid III 90151 series?

A: Both series provide 44-position receptacles at 0.100" pitch with push-pull fastening and solder termination. The C-Grid 71850 series (0015445144, 0015445844, 0015446844) specifies 2.5A current rating and 500VAC voltage rating with operating temperature -40°C to 125°C (or -40°C to 105°C for tin finish). The C-Grid III 90151 series (0901512144) specifies 3A current rating, 350V voltage rating, and operating temperature -55°C to 105°C. Selection depends on application voltage and current requirements.

Q: Why are there Preci-Dip socket connectors listed as substitutes when the original part is a receptacle?

A: Preci-Dip 416 and 803 series parts are socket connectors (female contacts) that maintain the same 44-position, 0.100" pitch, 2-row configuration, push-pull fastening, and gold mating contact finish as the original receptacle. In applications where the mating interface is with male pins or headers, socket and receptacle connectors are functionally equivalent. These parts are active, ROHS3-compliant alternatives.

Q: What is the significance of contact finish thickness differences among the Molex alternatives?

A: The Molex 0015445144 specifies 30.0µin (0.76µm) gold mating contact finish thickness, while 0015445844 specifies 15.0µin (0.38µm). Both thicknesses provide gold plating for corrosion resistance and electrical conductivity. Thicker plating may offer extended service life in high-cycle mating applications, while thinner plating reduces material cost. Selection depends on application durability requirements.

Q: Are the Preci-Dip 416-83 and 416-87 series interchangeable?

A: The 416-83 and 416-87 series differ in contact finish thickness specification. The 416-83 series specifies 29.5µin (0.75µm) gold finish, while 416-87 series specifies flash gold finish. Both maintain identical position count, pitch, row spacing, push-pull fastening, and UL94 V-0 insulation. The choice between them depends on contact finish thickness requirements for the application.

Q: What packaging options are available for these substitute parts?

A: Molex C-Grid series parts are supplied in trays. Molex C-Grid III 90151 series is supplied in tubes. Preci-Dip 416 and 803 series are supplied in bulk packaging. Packaging selection should align with assembly process requirements and inventory management practices.

Q: Do all substitute parts meet UL94 V-0 flammability requirements?

A: All Molex C-Grid 71850 series parts (0015445144, 0015445844, 0015446844) and all Preci-Dip 416 and 803 series parts specify UL94 V-0 material flammability rating. The Molex C-Grid III 90151 series (0901512144) does not specify flammability rating in the provided data. Verification of flammability compliance is required for applications with specific safety standards.
