Amphenol ICC 76314-213 26-Position 0.100" Rectangular Receptacle Connector

Part Overview

The Amphenol ICC 76314-213 is a 26-position receptacle connector with 0.100" (2.54mm) pitch, designed for through-hole PCB mounting with gold-plated mating contacts. This BergCon® series component is classified as obsolete, making equivalent and substitute parts necessary for ongoing system support and new designs requiring compatible connectivity.

The connector features a push-pull fastening mechanism, dual-row configuration, and solder termination. Its gold contact finish and thermoplastic polyester insulation material support applications requiring reliable board-to-board or cable connections.

Key Parameters

Parameter	Value
Connector Type	Receptacle
Contact Type	Female Socket
Number of Positions	26
Pitch - Mating	0.100" (2.54mm)
Number of Rows	2
Row Spacing - Mating	0.100" (2.54mm)
Mounting Type	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Insulation Material	Thermoplastic, Polyester, Glass Filled
Contact Material	Brass
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS non-compliant
Product Status	Obsolete

Substitute Part Grouping Explanation

Substitution for the 76314-213 is determined by strict alignment of the following electrical and mechanical parameters:

Critical Matching Parameters:

Connector type: Receptacle with female socket contacts
Position count: 26 positions
Pitch: 0.100" (2.54mm) mating pitch with 0.100" row spacing
Mounting: Through-hole solder termination
Fastening: Push-pull mechanism
Contact finish: Gold-plated mating surface
Insulation material: Thermoplastic or polyester-based glass-filled composition
Contact shape: Square
Flammability: UL94 V-0 rated

Substitute parts are grouped into two categories based on product status and compliance:

Category A - Active Status, RoHS Compliant: Molex C-Grid 71850 series (0015445126, 0015445826, 0015446826) and Molex C-Grid III 90151 series (0901512126, 0901512226, 0901512326) provide direct functional equivalence with modern compliance certifications.

Category B - Active Status, RoHS Non-Compliant: TE Connectivity AMPMODU Mod II and Mod IV series (1-146762-6, 1-147424-3, 1-534206-3) maintain electrical and mechanical compatibility while offering active product support.

Parameter Comparison

Parameter	76314-213	0015445126	0015445826	0015446826	0901512126	0901512226	0901512326	1-146762-6	1-147424-3	1-534206-3
Connector Type	Receptacle	Receptacle	Receptacle	Receptacle	Receptacle	Receptacle	Receptacle	Receptacle	Receptacle	Receptacle
Contact Type	Female Socket	Female Socket	Female Socket	Female Socket	Female Socket	Female Socket	Female Socket	Female Socket	Female Socket	Female Socket
Number of Positions	26	26	26	26	26	26	26	26	26	26
Pitch - Mating	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)
Number of Rows	2	2	2	2	2	2	2	2	2	2
Row Spacing - Mating	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)
Mounting Type	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole
Termination	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder
Fastening Type	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull
Contact Finish - Mating	Gold	Gold	Gold	Tin	Tin	Gold	Gold	Tin-Lead	Gold	Gold
Contact Material	Brass	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze
Insulation Material	Thermoplastic, Polyester, Glass Filled	Liquid Crystal Polymer (LCP), Glass Filled	Liquid Crystal Polymer (LCP), Glass Filled	Liquid Crystal Polymer (LCP), Glass Filled	Polyester, Glass Filled	Polyester, Glass Filled	Polyester, Glass Filled	Polyester, Glass Filled	Polyester, Glass Filled	Polyester, Glass Filled
Material Flammability Rating	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	—	—	—	—	—	—
RoHS Status	RoHS non-compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	RoHS non-compliant	RoHS non-compliant	RoHS non-compliant
Product Status	Obsolete	Active	Active	Active	Active	Active	Active	Active	Active	Active

Engineering Selection Recommendations

For RoHS3 Compliant Applications:

Molex C-Grid 71850 series parts (0015445126, 0015445826, 0015446826) are the primary substitutes. These connectors maintain full electrical and mechanical compatibility with the 76314-213 while meeting ROHS3 compliance requirements. The 0015445126 and 0015445826 variants feature gold mating contact finishes matching the original specification. The 0015446826 variant provides tin mating contacts with extended temperature range to -40°C, suitable for applications where contact finish material is not critical.

Molex C-Grid III 90151 series parts (0901512126, 0901512226, 0901512326) offer ROHS3 compliance with active product status. These connectors feature polyester glass-filled insulation and support higher current ratings (3A per contact) compared to the original part. The 0901512226 and 0901512326 variants provide gold mating contacts; 0901512126 provides tin mating contacts.

For Legacy or Non-Compliant Applications:

TE Connectivity AMPMODU Mod II and Mod IV series (1-146762-6, 1-147424-3, 1-534206-3) maintain RoHS non-compliant status consistent with the original 76314-213. These parts support applications where legacy compliance status is required or where existing inventory management practices do not mandate RoHS transition. All three variants are active products with established supply chains.

Contact Finish Considerations:

Gold-plated mating contacts (0015445126, 0015445826, 0901512226, 0901512326, 1-147424-3, 1-534206-3) provide direct functional equivalence to the original 76314-213 specification. Tin or tin-lead mating contacts (0015446826, 0901512126, 1-146762-6) are suitable for applications where contact finish material does not affect system performance.

Frequently Asked Questions (FAQ)

Q: Can I use a substitute part with tin mating contacts instead of gold?

A: Substitution is determined by connector type, position count, pitch, mounting method, and fastening mechanism. Contact finish material is a secondary parameter. Tin-plated variants (0015446826, 0901512126, 1-146762-6) are mechanically and electrically compatible with the 76314-213. Selection depends on application requirements for contact resistance, corrosion resistance, and environmental exposure.

Q: What is the difference between Molex C-Grid 71850 and C-Grid III 90151 series?

A: Both series maintain the critical parameters for substitution: 26 positions, 0.100" pitch, dual-row configuration, through-hole solder termination, and push-pull fastening. The C-Grid III 90151 series supports higher current ratings (3A per contact versus 2.5A) and extended temperature range (-55°C to 105°C). The C-Grid 71850 series operates at -40°C to 125°C with 2.5A current rating. Selection depends on thermal and current requirements of the application.

Q: Are TE Connectivity AMPMODU parts direct replacements?

A: TE Connectivity AMPMODU Mod II (1-534206-3) and Mod IV (1-146762-6, 1-147424-3) series maintain all critical substitution parameters: 26 positions, 0.100" pitch, dual-row configuration, through-hole solder termination, and push-pull fastening. These parts are mechanically and electrically compatible with the 76314-213. The primary difference is RoHS non-compliant status, matching the original part's compliance classification.

Q: What packaging options are available for substitute parts?

A: Molex C-Grid 71850 series parts are supplied in Tray packaging. Molex C-Grid III 90151 series parts are supplied in Tube packaging. TE Connectivity AMPMODU series parts are supplied in Tube packaging. Packaging selection does not affect connector functionality or compatibility; it addresses inventory management and handling requirements.

Q: Can I mix gold and tin contact finishes in the same connector assembly?

A: The 76314-213 is a receptacle connector (female socket). Mating compatibility depends on the header or plug connector used. Gold-plated receptacles (0015445126, 0015445826, 0901512226, 0901512326, 1-147424-3, 1-534206-3) mate with standard male pin headers. Tin-plated receptacles (0015446826, 0901512126, 1-146762-6) also mate with standard male pin headers. Contact finish compatibility is determined by the mating connector specification, not by mixing within a single receptacle.

Q: What is the current rating difference between substitute parts?

A: The original 76314-213 does not specify a current rating. Molex C-Grid 71850 series parts are rated at 2.5A per contact. Molex C-Grid III 90151 series parts are rated at 3A per contact. TE Connectivity AMPMODU series parts are rated at 2A per contact. Selection depends on application current requirements and thermal management considerations.

Q: Are all substitute parts UL94 V-0 rated?

A: Molex C-Grid 71850 series parts (0015445126, 0015445826, 0015446826) are UL94 V-0 rated. Molex C-Grid III 90151 series parts and TE Connectivity AMPMODU series parts do not specify flammability ratings in the provided data. For applications requiring UL94 V-0 certification, Molex C-Grid 71850 series parts are the appropriate selection.
