Amphenol ICC 76314-204 Rectangular Connector Equivalent & Substitute Parts

Part Overview

The Amphenol ICC 76314-204 is an 8-position receptacle connector with 0.100" (2.54mm) pitch, designed for through-hole PCB mounting with gold-plated mating contacts. This component is classified as obsolete, making equivalent and substitute parts necessary for ongoing design support and production continuity. The BergCon® series connector features push-pull fastening, solder termination, and UL94 V-0 flammability rating suitable for board-to-board and cable applications.

Key Parameters

Parameter	Value
Connector Type	Receptacle
Contact Type	Female Socket
Number of Positions	8
Pitch - Mating	0.100" (2.54mm)
Number of Rows	2
Row Spacing - Mating	0.100" (2.54mm)
Mounting Type	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Material Flammability Rating	UL94 V-0
Product Status	Obsolete
RoHS Status	RoHS non-compliant

Substitute Part Grouping Explanation

Substitution for the 76314-204 is determined by strict alignment of electrical and mechanical parameters. The critical substitution criteria are:

Primary Matching Parameters:

Connector type: Receptacle
Contact type: Female socket
Number of positions: 8
Pitch - mating: 0.100" (2.54mm)
Number of rows: 2
Row spacing - mating: 0.100" (2.54mm)
Mounting type: Through hole
Termination: Solder
Fastening type: Push-pull
Material flammability rating: UL94 V-0

Substitute parts are grouped into two categories:

Category 1: Direct Amphenol ICC Substitutes The 76314-204LF represents the active production equivalent within the same BergCon® series, differing only in RoHS compliance status (RoHS Compliant vs. non-compliant) and packaging format.

Category 2: Cross-Manufacturer Substitutes Molex C-Grid 71850 series (0015445108, 0015445808, 0015446808) and C-Grid III 90151 series (0901512108, 0901512308) connectors meet all core mechanical and electrical parameters. Preci-Dip 416 series socket connectors (416-83-208-41-007101, 416-83-208-41-012101, 416-87-208-41-007101, 416-87-208-41-012101) provide functional equivalence with variations in contact material and finish specifications.

Parameter Comparison

Parameter	76314-204	76314-204LF	0015445108	0015445808	0015446808	0901512108	0901512308	416-83-208-41-007101	416-87-208-41-007101
Manufacturer	Amphenol ICC	Amphenol ICC	Molex	Molex	Molex	Molex	Molex	Preci-Dip	Preci-Dip
Connector Type	Receptacle	Receptacle	Receptacle	Receptacle	Receptacle	Receptacle	Receptacle	Socket	Socket
Contact Type	Female Socket	Female Socket	Female Socket	Female Socket	Female Socket	Female Socket	Female Socket	Female Socket	Female Socket
Number of Positions	8	8	8	8	8	8	8	8	8
Pitch - Mating	0.100"	0.100"	0.100"	0.100"	0.100"	0.100"	0.100"	0.100"	0.100"
Number of Rows	2	2	2	2	2	2	2	2	2
Row Spacing - Mating	0.100"	0.100"	0.100"	0.100"	0.100"	0.100"	0.100"	0.100"	0.100"
Mounting Type	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole
Termination	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder
Fastening Type	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull
Contact Finish - Mating	Gold	Gold	Gold	Gold	Tin	Tin	Gold	Gold	Gold
Material Flammability Rating	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	—	—	UL94 V-0	UL94 V-0
Product Status	Obsolete	Active	Active	Active	Active	Active	Active	Active	Active
RoHS Status	Non-compliant	Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant

Engineering Selection Recommendations

For Direct Replacement (Preferred): The 76314-204LF is the recommended substitute. It maintains identical mechanical and electrical specifications while offering active product status and RoHS compliance. This part is suitable for new designs and production continuity without design modification.

For Cross-Manufacturer Substitution: Molex C-Grid 71850 series parts (0015445108, 0015445808) provide functional equivalence with ROHS3 compliance and active product status. The 0015445108 (gold mating finish) and 0015445808 (gold mating finish, 0.38µm thickness) are direct functional alternatives. The 0015446808 variant uses tin mating finish and operates at reduced temperature range (-40°C to 105°C versus -40°C to 125°C), requiring thermal evaluation for applications exceeding 105°C.

Molex C-Grid III 90151 series (0901512108, 0901512308) offer extended temperature operation (-55°C to 105°C) and higher current rating (3A versus unspecified for original), with active product status and ROHS3 compliance. Material flammability rating is not specified for this series.

Preci-Dip 416 series socket connectors (416-83-208-41-007101, 416-87-208-41-007101) meet core mechanical parameters with beryllium copper contacts and ROHS3 compliance. These parts feature circular contact geometry versus square contacts in the original, and higher insulation height (0.394" or 0.354" versus 0.335"), requiring PCB layout verification.

Compliance Considerations: All substitute parts except the original 76314-204 are RoHS compliant, supporting modern supply chain requirements. The 76314-204LF is the only substitute maintaining identical specifications with improved compliance status.

Frequently Asked Questions (FAQ)

Q: Can the 76314-204LF be used as a direct drop-in replacement for the 76314-204? A: Yes. The 76314-204LF maintains identical mechanical and electrical specifications, including connector type, position count, pitch, mounting method, and fastening type. The primary difference is RoHS compliance status and active product availability.

Q: What are the key differences between Molex C-Grid 71850 and C-Grid III 90151 series? A: Both series meet the core 8-position, 0.100" pitch, through-hole solder requirements. C-Grid III 90151 offers extended temperature range (-55°C to 105°C) and higher current rating (3A). C-Grid 71850 operates at -40°C to 125°C (or -40°C to 105°C for tin finish variant) with 2.5A current rating. Material flammability rating is specified for C-Grid 71850 (UL94 V-0) but not documented for C-Grid III 90151.

Q: Are Preci-Dip 416 series connectors fully compatible with the original 76314-204? A: Preci-Dip 416 series meet all core mechanical and electrical parameters. However, they feature circular contact geometry (versus square in the original), higher insulation height, and different contact material (beryllium copper versus brass). PCB layout and mating interface compatibility must be verified before implementation.

Q: Which substitute part has the best compliance profile? A: All substitute parts listed are ROHS3 compliant with active product status. The 76314-204LF is the preferred choice for compliance and availability, as it maintains identical specifications to the original while offering modern regulatory support.

Q: Can tin-finish variants (0015446808, 0901512108) replace gold-finish originals? A: Tin-finish parts meet mechanical and electrical requirements but operate at reduced maximum temperature (-40°C to 105°C versus -40°C to 125°C for gold-finish variants). Application thermal requirements must be evaluated. Contact finish selection may also affect corrosion resistance in specific environments.

Q: What packaging formats are available for these substitutes? A: Amphenol ICC 76314-204LF is supplied in bulk packaging. Molex C-Grid 71850 series are supplied in tray packaging. Molex C-Grid III 90151 series are supplied in tube packaging. Preci-Dip 416 series are supplied in bulk packaging. Packaging selection affects handling, storage, and assembly processes.
