Amphenol ICC 76308-214 Equivalent & Substitute Parts

Part Overview

The Amphenol ICC 76308-214 is a 14-position receptacle connector with 0.100" (2.54mm) pitch, gold-plated mating contacts, and through-hole solder termination. This connector is part of the BergCon® series and is classified as obsolete. Due to its obsolete status, equivalent and substitute parts from active manufacturers are necessary to maintain design continuity and ensure long-term component availability for new production and field replacements.

Key Parameters

Parameter	Value
Manufacturer Part Number	76308-214
Manufacturer	Amphenol ICC (FCI)
Connector Type	Receptacle
Contact Type	Female Socket
Number of Positions	14
Pitch - Mating	0.100" (2.54mm)
Mounting Type	Through Hole
Termination	Solder
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	39.4µin (1.00µm)
Insulation Height	0.335" (8.51mm)
Contact Length - Post	0.135" (3.43mm)
Insulation Material	Thermoplastic, Polyester, Glass Filled
Contact Material	Brass
Product Status	Obsolete
RoHS Status	RoHS non-compliant

Substitute Part Grouping Explanation

Substitution for the 76308-214 is based on the following critical parameters that must align for functional compatibility:

Primary Matching Criteria:

Connector type: Receptacle with female socket contacts
Number of positions: 14
Pitch - mating: 0.100" (2.54mm)
Mounting type: Through hole
Termination: Solder
Contact finish - mating: Gold
Fastening type: Push-Pull
Style: Board to Board

Secondary Compatibility Factors:

Insulation height tolerance (0.335" ± acceptable variation)
Contact length - post (0.114" to 0.135" range acceptable)
Operating temperature range (-55°C to 125°C minimum)
Material flammability rating (UL94 V-0 preferred)
Contact material (Brass, Phosphor Bronze, or Beryllium Copper acceptable)

Substitute parts are grouped into two categories: direct Molex equivalents from the C-Grid 90147 series and alternative socket connectors from Preci-Dip and Samtec that meet all critical electrical and mechanical parameters.

Parameter Comparison

Parameter	76308-214 (Main)	0901471214 (Molex)	0901471314 (Molex)	316-83-114-41-007101 (Preci-Dip)	316-87-114-41-012101 (Preci-Dip)	801-87-014-10-005101 (Preci-Dip)	ESS-114-G-23 (Samtec)
Connector Type	Receptacle	Receptacle	Receptacle	Socket	Socket	Socket	Elevated Socket
Contact Type	Female Socket	Female Socket	Female Socket	Female Socket	Female Socket	Female Socket	Female Socket
Number of Positions	14	14	14	14	14	14	14
Pitch - Mating	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)
Mounting Type	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole
Termination	Solder	Solder	Solder	Solder	Solder	Solder	Solder
Contact Finish - Mating	Gold	Gold	Gold	Gold	Gold	Gold	Gold
Insulation Height	0.335" (8.51mm)	0.335" (8.51mm)	0.335" (8.51mm)	0.394" (10.00mm)	0.354" (9.00mm)	0.335" (8.51mm)	0.300" (7.62mm)
Contact Length - Post	0.135" (3.43mm)	0.114" (2.90mm)	0.114" (2.90mm)	0.126" (3.20mm)	0.126" (3.20mm)	0.118" (3.00mm)	0.123" (3.12mm)
Contact Material	Brass	Phosphor Bronze	Phosphor Bronze	Beryllium Copper	Beryllium Copper	Beryllium Copper	Beryllium Copper
Operating Temperature	Not specified	-55°C ~ 105°C	-55°C ~ 105°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C
Current Rating	Not specified	3A	3A	3A	3A	3A	Not specified
Voltage Rating	Not specified	350V	350V	Not specified	Not specified	Not specified	Not specified
Material Flammability Rating	UL94 V-0	Not specified	Not specified	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0
RoHS Status	RoHS non-compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant
Product Status	Obsolete	Active	Active	Active	Active	Active	Active

Engineering Selection Recommendations

Molex C-Grid 90147 Series (0901471214 and 0901471314): These parts provide the closest functional equivalence to the 76308-214. Both are 14-position receptacles with 0.100" pitch, gold-plated mating contacts, and solder termination. The primary differences are contact material (Phosphor Bronze vs. Brass) and contact post length (0.114" vs. 0.135"). Both parts are ROHS3 compliant and active products with 350V voltage rating and 3A current rating per contact. Operating temperature range is -55°C to 105°C. These are recommended as primary substitutes for new designs and production applications.

Preci-Dip 316 Series (316-83-114-41-007101, 316-83-114-41-012101, 316-87-114-41-007101, 316-87-114-41-012101): These socket connectors meet all critical electrical and mechanical parameters. Key differences include higher insulation height (0.394" or 0.354" vs. 0.335"), Beryllium Copper contact material, and extended operating temperature range (-55°C to 125°C). All are ROHS3 compliant and UL94 V-0 rated. The 316-87 variants feature flash gold plating on mating contacts. These parts are suitable for applications requiring higher temperature performance.

Preci-Dip 801 Series (801-87-014-10-005101): This elevated socket connector maintains the 0.335" insulation height matching the original part. It features Beryllium Copper contacts, flash gold plating, and extended operating temperature range (-55°C to 125°C). ROHS3 compliant and UL94 V-0 rated. Suitable for applications requiring compact form factor with elevated socket design.

Samtec ESS Series (ESS-114-G-23): This elevated socket connector provides the lowest insulation height (0.300") among substitutes. Features Beryllium Copper contacts with gold plating on both mating and post surfaces. ROHS3 compliant and UL94 V-0 rated with extended operating temperature range (-55°C to 125°C). Recommended for space-constrained applications.

All substitute parts are active products from established manufacturers with ROHS3 compliance, ensuring long-term availability and regulatory compliance for new production.

Frequently Asked Questions (FAQ)

Q: Can I directly replace the 76308-214 with any of these substitute parts?

A: Yes, all listed substitute parts are mechanically and electrically compatible. They share the same 14-position configuration, 0.100" (2.54mm) pitch, through-hole solder termination, and gold-plated mating contacts. The primary design consideration is insulation height variation (0.300" to 0.394") and contact post length differences, which may affect PCB layout spacing. Verify your PCB design accommodates these dimensional variations before implementation.

Q: What is the difference between Receptacle and Socket connector types?

A: The 76308-214 is classified as a Receptacle connector. Substitute parts include both Receptacle types (Molex 0901471214 and 0901471314) and Socket types (Preci-Dip 316 and 801 series, Samtec ESS series). Both types accept male pin headers and are functionally equivalent for board-to-board connections. Socket connectors typically feature circular contact geometry, while receptacles may use square contacts.

Q: Why do some substitutes have different contact materials?

A: The original 76308-214 uses Brass contacts, while substitutes use Phosphor Bronze or Beryllium Copper. All three materials provide equivalent electrical conductivity and mechanical durability for this application. Beryllium Copper offers superior spring characteristics and contact retention. Material selection does not affect functional compatibility.

Q: Are all substitute parts RoHS compliant?

A: Yes, all listed substitute parts are ROHS3 compliant. The original 76308-214 is RoHS non-compliant. If your application requires RoHS compliance, any of the substitute parts will satisfy regulatory requirements.

Q: What is the significance of contact finish thickness differences?

A: Contact finish thickness (measured in microinches or micrometers) affects contact durability and mating cycles. The 76308-214 specifies 39.4µin (1.00µm) gold plating on mating contacts. Molex substitutes provide 15.0µin to 30.0µin, while Preci-Dip and Samtec provide 10.0µin to 29.5µin or flash plating. All thicknesses are within acceptable ranges for standard board-to-board applications. Flash plating (Preci-Dip 316-87 and 801-87 series) provides minimal but sufficient coverage for non-corrosive environments.

Q: Which substitute should I choose for high-temperature applications?

A: Preci-Dip (316 and 801 series) and Samtec (ESS-114-G-23) offer extended operating temperature range of -55°C to 125°C, compared to Molex parts rated -55°C to 105°C. If your application requires operation above 105°C, select Preci-Dip or Samtec substitutes.

Q: What is an elevated socket connector?

A: Elevated socket connectors (Preci-Dip 801 series and Samtec ESS series) feature a raised insulation body that provides additional clearance above the PCB surface. This design accommodates components or traces beneath the connector footprint. Standard socket connectors (Preci-Dip 316 series) have lower insulation height. Select elevated variants only if your PCB layout requires this feature.

Q: Are there packaging differences between substitutes?

A: Yes. Molex parts are supplied in Tube packaging, while Preci-Dip and Samtec parts are supplied in Bulk packaging. Tube packaging provides individual part protection, while Bulk packaging is more economical for high-volume orders. Packaging does not affect connector performance or compatibility.

Q: Can I mix different substitute parts in the same assembly?

A: Yes, all substitute parts are mechanically and electrically interchangeable. However, for consistency and simplified inventory management, it is recommended to standardize on a single substitute part number per design.
