76308-208LF Equivalent & Substitute Parts
Part Overview
The 76308-208LF is an 8-position receptacle connector manufactured by Amphenol ICC (FCI) in the BergCon® series. This through-hole connector features 0.100" (2.54mm) pitch, gold-plated mating contacts, and is designed for board-to-board or cable applications. The part is active in production with 670 units in stock. Substitute parts are identified when equivalent electrical and mechanical parameters align with the original specification, enabling direct replacement in applications where the core functional requirements remain constant.
Substiute Parts
Key Parameters
| Parameter | 76308-208LF |
|---|---|
| Connector Type | Receptacle |
| Number of Positions | 8 |
| Pitch - Mating | 0.100" (2.54mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Type | Female Socket |
| Contact Finish - Mating | Gold |
| Insulation Height | 0.335" (8.51mm) |
| Material Flammability Rating | UL94 V-0 |
| RoHS Status | RoHS Compliant |
| Moisture Sensitivity Level | 1 (Unlimited) |
Substitute Part Grouping Explanation
Substitution eligibility is determined by strict alignment of the following parameters:
- Connector Type: Receptacle or Header (board-mounted socket variants)
- Number of Positions: 8 positions
- Pitch - Mating: 0.100" (2.54mm)
- Mounting Type: Through Hole
- Termination: Solder
- Contact Type: Female Socket or Forked contact variants
- Insulation Height: 0.335" (8.51mm) or mechanically compatible alternatives
- Material Flammability Rating: UL94 V-0
- RoHS Status: RoHS3 Compliant or RoHS Compliant
- Moisture Sensitivity Level: 1 (Unlimited)
Substitute parts are grouped by contact finish (gold vs. tin), contact geometry (socket vs. forked), and insulation material. Parts with differing contact post lengths, voltage ratings, or operating temperature ranges are included when core mating parameters remain equivalent.
Parameter Comparison
| Part Number | Manufacturer | Connector Type | Positions | Pitch | Contact Finish - Mating | Insulation Height | UL94 Rating | RoHS Status | Inventory |
|---|---|---|---|---|---|---|---|---|---|
| 76308-208LF | Amphenol ICC (FCI) | Receptacle | 8 | 0.100" (2.54mm) | Gold | 0.335" (8.51mm) | UL94 V-0 | RoHS Compliant | 670 Pcs |
| 0901471108 | Molex | Receptacle | 8 | 0.100" (2.54mm) | Tin | 0.335" (8.51mm) | Not Specified | ROHS3 Compliant | 1336 Pcs |
| ESS-108-T-03 | Samtec Inc. | Elevated Socket | 8 | 0.100" (2.54mm) | Gold | 0.300" (7.62mm) | UL94 V-0 | ROHS3 Compliant | 1150 Pcs |
| PPPC081LFBN-RC | Sullins Connector Solutions | Header | 8 | 0.100" (2.54mm) | Gold | 0.335" (8.51mm) | UL94 V-0 | ROHS3 Compliant | 33430 Pcs |
| PPTC081LFBN-RC | Sullins Connector Solutions | Header | 8 | 0.100" (2.54mm) | Tin | 0.335" (8.51mm) | UL94 V-0 | ROHS3 Compliant | 33888 Pcs |
| SSQ-108-01-F-S | Samtec Inc. | Receptacle | 8 | 0.100" (2.54mm) | Gold | 0.335" (8.51mm) | UL94 V-0 | ROHS3 Compliant | 1083 Pcs |
| SSQ-108-01-SM-S | Samtec Inc. | Receptacle | 8 | 0.100" (2.54mm) | Gold | 0.335" (8.51mm) | UL94 V-0 | ROHS3 Compliant | 1029 Pcs |
| SSQ-108-03-F-S | Samtec Inc. | Receptacle | 8 | 0.100" (2.54mm) | Gold | 0.335" (8.51mm) | UL94 V-0 | ROHS3 Compliant | 2411 Pcs |
| SSQ-108-03-L-S | Samtec Inc. | Receptacle | 8 | 0.100" (2.54mm) | Gold | 0.335" (8.51mm) | UL94 V-0 | ROHS3 Compliant | 1164 Pcs |
| SSQ-108-04-F-S | Samtec Inc. | Receptacle | 8 | 0.100" (2.54mm) | Gold | 0.335" (8.51mm) | UL94 V-0 | ROHS3 Compliant | 810 Pcs |
| SSQ-108-04-G-S | Samtec Inc. | Receptacle | 8 | 0.100" (2.54mm) | Gold | 0.335" (8.51mm) | UL94 V-0 | ROHS3 Compliant | 1748 Pcs |
Engineering Selection Recommendations
Direct Receptacle Substitutes (Gold Finish)
SSQ-108-01-F-S, SSQ-108-01-SM-S, SSQ-108-03-F-S, SSQ-108-03-L-S, SSQ-108-04-F-S, and SSQ-108-04-G-S are receptacle connectors from Samtec Inc. with matching 8-position, 0.100" pitch, through-hole solder termination, and UL94 V-0 flammability rating. These parts differ in contact post length and contact finish thickness but maintain electrical and mechanical compatibility at the mating interface. All are ROHS3 Compliant with MSL 1 rating.
Tin-Finish Receptacle Substitute
0901471108 from Molex is a receptacle connector with equivalent 8-position, 0.100" pitch configuration and through-hole mounting. The primary difference is tin contact finish instead of gold. This part is ROHS3 Compliant and carries a 3A current rating and 350V voltage specification. Operating temperature range is -55°C to 105°C.
Header Connector Substitutes
PPPC081LFBN-RC and PPTC081LFBN-RC from Sullins Connector Solutions are header connectors (board-mounted male pins) rather than receptacles. These parts maintain 8-position, 0.100" pitch, 0.335" insulation height, and UL94 V-0 rating. PPPC081LFBN-RC features gold finish; PPTC081LFBN-RC features tin finish. Both are ROHS3 Compliant with 3A current rating and 250V voltage specification.
Elevated Socket Substitute
ESS-108-T-03 from Samtec Inc. is an elevated socket connector with 8 positions and 0.100" pitch. The insulation height is 0.300" (7.62mm), which differs from the 0.335" standard. This part features gold mating contact finish, UL94 V-0 rating, and ROHS3 compliance. Contact material is beryllium copper with liquid crystal polymer insulation.
Frequently Asked Questions (FAQ)
Q: Can SSQ-108-04-G-S replace 76308-208LF directly?
A: Yes. Both are 8-position receptacles with 0.100" pitch, through-hole solder termination, gold mating contact finish, 0.335" insulation height, and UL94 V-0 rating. The primary difference is contact post length (0.584" vs. 0.135") and contact finish thickness. Compatibility depends on PCB layout and mating component clearance.
Q: What is the difference between receptacle and header connector substitutes?
A: The 76308-208LF is a receptacle (female socket). Header connectors like PPPC081LFBN-RC are board-mounted male pins. These are not interchangeable as mating components; they are used in different circuit board configurations. Select based on your application's connector architecture.
Q: Can I use 0901471108 (tin finish) instead of the gold-finish original?
A: 0901471108 maintains the same 8-position, 0.100" pitch, and through-hole solder termination. The tin contact finish differs from gold. Compatibility depends on your application's electrical requirements and contact resistance specifications. Both are ROHS3 Compliant with MSL 1 rating.
Q: Why does ESS-108-T-03 have a different insulation height?
A: ESS-108-T-03 is an elevated socket design with 0.300" insulation height compared to the standard 0.335". This affects PCB stackup and mating clearance. Verify mechanical fit in your application before substitution.
Q: Are all substitute parts RoHS compliant?
A: Yes. The original 76308-208LF is RoHS Compliant. All listed substitutes are either RoHS Compliant or ROHS3 Compliant, meeting current regulatory requirements.
Q: What determines if a part can substitute for 76308-208LF?
A: Core substitution criteria are 8 positions, 0.100" (2.54mm) pitch, through-hole mounting, solder termination, female socket contact type, and 0.335" insulation height. Contact finish (gold vs. tin), contact geometry (socket vs. forked), and contact post length variations are allowed when mating interface compatibility is maintained.
