75R-2213T Neon Panel Indicator - Equivalent & Substitute Parts

Part Overview

The 75R-2213T is a 125V amber neon panel indicator manufactured by Visual Communications Company (VCC), designed for quick-connect terminal applications with a 0.187" (4.7mm) connection. This component features a round domed lens and round panel cutout configuration suitable for panel-mount installations.

The 75R-2213T is classified as Obsolete. Locating equivalent substitute parts is necessary for ongoing maintenance, repair, and production support of legacy equipment utilizing this neon indicator specification.

Substiute Parts

75R-2213T

Visual Communications Company - VCCIn Stock: 100175R-2213T Datasheet

Current PartRFQ

1050QA3

Visual Communications Company - VCCIn Stock: 8971050QA3 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the 75R-2213T is determined by the following critical parameters:

Voltage Compatibility: The substitute part must operate within or encompass the 125V specification. The 1050QA3 operates at 105V ~ 125V, which includes the 125V requirement.

Termination Interface: Both parts utilize Quick Connect - 0.187" (4.7mm) termination, ensuring mechanical and electrical compatibility at the connection point.

Lens Color and Style: Both parts feature amber lens color with round domed top configuration, maintaining visual consistency and optical performance in panel applications.

Panel Cutout Compatibility: The 75R-2213T requires a 0.38" (9.65mm) round cutout, while the 1050QA3 requires a 0.50" (12.70mm) round cutout. This dimensional difference must be evaluated during installation planning.

Regulatory Compliance: Both parts maintain ROHS3 compliance and MSL 1 rating, ensuring equivalent environmental and handling standards.

Parameter Comparison

Engineering Selection Recommendations

Primary Consideration - Panel Cutout Dimensions:

The 1050QA3 substitute requires a 0.50" (12.70mm) panel cutout compared to the 75R-2213T specification of 0.38" (9.65mm). This 0.12" (3.05mm) dimensional increase necessitates panel modification or mechanical adaptation during installation. Direct drop-in replacement without panel modification is not possible.

Voltage and Electrical Compatibility:

The 1050QA3 voltage range of 105V ~ 125V encompasses the 125V operating point of the 75R-2213T, providing electrical compatibility within the specified operating envelope.

Regulatory and Compliance Status:

Both parts maintain ROHS3 compliance and identical MSL ratings, ensuring equivalent environmental and manufacturing standards. No compliance barriers exist for substitution.

Product Status Implications:

The 75R-2213T is classified as Obsolete, while the 1050QA3 is classified as Not For New Designs. Both components represent legacy technology. Inventory availability should be confirmed prior to procurement decisions.

Frequently Asked Questions (FAQ)

Q: Can the 1050QA3 be used as a direct replacement for the 75R-2213T without panel modification?

A: No. The 1050QA3 requires a 0.50" (12.70mm) panel cutout, while the 75R-2213T specification calls for 0.38" (9.65mm). Panel drilling or mechanical adaptation is required for installation.

Q: Are the electrical specifications compatible between these two parts?

A: Yes. The 1050QA3 operates at 105V ~ 125V, which includes the 125V rating of the 75R-2213T. Both parts are neon indicators with identical termination interfaces (Quick Connect - 0.187").

Q: What is the difference in product status between these parts?

A: The 75R-2213T is classified as Obsolete, indicating it is no longer manufactured. The 1050QA3 is classified as Not For New Designs, indicating limited availability and no recommendation for new product development. Both represent legacy components.

Q: Do both parts meet the same regulatory requirements?

A: Yes. Both the 75R-2213T and 1050QA3 are ROHS3 compliant with MSL 1 (Unlimited) ratings, ensuring equivalent environmental and moisture sensitivity standards.

Q: What packaging is available for the 1050QA3?

A: The 1050QA3 is supplied in Bag packaging. The 75R-2213T packaging specification was not provided in the available documentation.

Q: Are there any feature differences between these indicators?

A: The 75R-2213T is specified as oil resistant. The 1050QA3 feature set was not detailed in the available documentation. Oil resistance requirements should be evaluated for specific application environments.
