Amphenol ICC 75160-156-36 Equivalent & Substitute Parts
Part Overview
The Amphenol ICC 75160-156-36 is a vertical through-hole rectangular connector header with 36 positions at 0.100" (2.54mm) pitch. This BERGSTIK® series component features unshrouded, board-to-board configuration with male pins, phosphor bronze contacts finished in gold, and thermoplastic insulation rated UL94 V-0. The part is classified as obsolete, making equivalent and substitute parts necessary for ongoing design support and procurement.
Substiute Parts
Key Parameters
| Parameter | Value |
|---|---|
| Manufacturer Part Number | 75160-156-36 |
| Manufacturer | Amphenol ICC (FCI) |
| Connector Type | Header |
| Contact Type | Male Pin |
| Number of Positions | 36 |
| Pitch - Mating | 0.100" (2.54mm) |
| Number of Rows | 1 |
| Mounting Type | Through Hole |
| Termination | Solder |
| Shrouding | Unshrouded |
| Contact Material | Phosphor Bronze |
| Contact Finish - Mating | Gold, GXT™ |
| Insulation Material | Thermoplastic |
| Operating Temperature | -65°C ~ 130°C |
| Current Rating | 5A |
| Voltage Rating | 110V |
| Material Flammability Rating | UL94 V-0 |
| RoHS Status | RoHS non-compliant |
| Product Status | Obsolete |
Substitute Part Grouping Explanation
Substitution for the 75160-156-36 is determined by strict alignment of the following critical parameters:
Primary Matching Criteria:
- Number of Positions: 36
- Pitch - Mating: 0.100" (2.54mm)
- Number of Rows: 1
- Connector Type: Header
- Contact Type: Male Pin
- Mounting Type: Through Hole
- Termination: Solder
- Shrouding: Unshrouded
Secondary Compatibility Parameters:
- Contact Material: Phosphor Bronze (preferred for electrical performance consistency)
- Contact Shape: Square (mechanical fit compatibility)
- Insulation Material: Thermoplastic or equivalent polymer
- Material Flammability Rating: UL94 V-0
- Fastening Type: Push-Pull
Substitute parts are grouped into two categories: direct functional equivalents from active manufacturers (Sullins Connector Solutions, Samtec Inc., Mill-Max Manufacturing Corp.) and parts with minor parameter variations that maintain electrical and mechanical compatibility within the specified operating envelope.
Parameter Comparison
| Parameter | 75160-156-36 (Main) | 800-10-036-10-002000 | PBC36SAAN | PBC36SABN | PEC36SAAN | PEC36SABN | PGC36SAAN | TSW-136-07-G-S | TSW-136-07-L-S | TSW-136-07-S-S |
|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | Amphenol ICC | Mill-Max | Sullins | Sullins | Sullins | Sullins | Sullins | Samtec | Samtec | Samtec |
| Number of Positions | 36 | 36 | 36 | 36 | 36 | 36 | 36 | 36 | 36 | 36 |
| Pitch - Mating | 0.100" | 0.100" | 0.100" | 0.100" | 0.100" | 0.100" | 0.100" | 0.100" | 0.100" | 0.100" |
| Number of Rows | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Connector Type | Header | Header | Header, Breakaway | Header, Breakaway | Header, Breakaway | Header, Breakaway | Header | Header | Header | Header |
| Contact Type | Male Pin | Male Pin | Male Pin | Male Pin | Male Pin | Male Pin | Male Pin | Male Pin | Male Pin | Male Pin |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Termination | Solder | Solder | Solder | Solder | Solder | Solder | Solder | Solder | Solder | Solder |
| Shrouding | Unshrouded | Unshrouded | Unshrouded | Unshrouded | Unshrouded | Unshrouded | Unshrouded | Unshrouded | Unshrouded | Unshrouded |
| Contact Material | Phosphor Bronze | Brass Alloy | Phosphor Bronze | Phosphor Bronze | Phosphor Bronze | Phosphor Bronze | Copper Alloy | Phosphor Bronze | Phosphor Bronze | Phosphor Bronze |
| Contact Finish - Mating | Gold, GXT™ | Gold | Gold | Gold | Tin | Tin | Gold | Gold | Gold | Gold |
| Contact Length - Mating | 0.225" | 0.142" | 0.230" | 0.230" | 0.230" | 0.230" | 0.230" | 0.230" | 0.230" | 0.230" |
| Contact Length - Post | 0.120" | 0.118" | 0.120" | 0.230" | 0.120" | 0.230" | 0.120" | 0.100" | 0.100" | 0.100" |
| Insulation Height | 0.100" | 0.110" | 0.100" | 0.100" | 0.100" | 0.100" | 0.100" | 0.100" | 0.100" | 0.100" |
| Contact Shape | Square | Circular | Square | Square | Square | Square | Square | Square | Square | Square |
| Insulation Material | Thermoplastic | Polycyclohexylenedimethylene Terephthalate (PCT) | Polybutylene Terephthalate (PBT) | Polybutylene Terephthalate (PBT) | Polybutylene Terephthalate (PBT) | Polybutylene Terephthalate (PBT) | Thermoplastic, Polyester | Polybutylene Terephthalate (PBT) | Polybutylene Terephthalate (PBT) | Polybutylene Terephthalate (PBT) |
| Operating Temperature | -65°C ~ 130°C | Not specified | -65°C ~ 125°C | -65°C ~ 125°C | -65°C ~ 125°C | -65°C ~ 125°C | Not specified | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Current Rating | 5A | Not specified | 3A | 3A | 3A | 3A | 3A | Not specified | Not specified | Not specified |
| Voltage Rating | 110V | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified |
| Material Flammability Rating | UL94 V-0 | Not specified | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Product Status | Obsolete | Active | Active | Active | Active | Active | Active | Active | Active | Active |
Engineering Selection Recommendations
All substitute parts listed are active products from established manufacturers with ROHS3 compliance, addressing the obsolescence of the original 75160-156-36 component.
Primary Substitutes (Highest Compatibility):
PBC36SAAN and PEC36SAAN from Sullins Connector Solutions provide the closest electrical and mechanical alignment. Both maintain 36-position, 2.54mm pitch configuration with phosphor bronze contacts, square contact geometry, and UL94 V-0 insulation rating. PBC36SAAN features gold mating finish matching the original specification, while PEC36SAAN uses tin finish. Contact post length of 0.120" matches the original 75160-156-36 specification.
TSW-136-07-G-S from Samtec Inc. offers phosphor bronze contacts with gold finish and maintains all critical pitch and position parameters. Operating temperature range of -55°C ~ 125°C covers the majority of the original -65°C ~ 130°C specification.
Secondary Substitutes (Functional Equivalents):
PBC36SABN and PEC36SABN provide extended contact post length (0.230") for applications requiring deeper board penetration. Both maintain core electrical specifications and UL94 V-0 rating.
PGC36SAAN from Sullins uses copper alloy contacts with gold finish, providing an alternative material composition while maintaining 36-position, 2.54mm pitch configuration and UL94 V-0 compliance.
800-10-036-10-002000 from Mill-Max Manufacturing Corp. features brass alloy contacts with circular geometry rather than square, representing a mechanical variation suitable for applications where contact shape flexibility exists.
TSW-136-07-L-S and TSW-136-07-S-S from Samtec provide tin and mixed finish options respectively, with identical pitch, position, and temperature specifications to TSW-136-07-G-S.
Frequently Asked Questions (FAQ)
Q: Can I directly replace the 75160-156-36 with any of these substitute parts?
A: Direct replacement depends on your specific application requirements. All listed substitutes maintain the critical 36-position, 0.100" (2.54mm) pitch, through-hole solder termination, and unshrouded configuration. However, verify contact post length requirements: the original part and most substitutes use 0.120" posts, while PBC36SABN and PEC36SABN use 0.230" posts. Additionally, confirm your application can accommodate the lower current rating (3A) of Sullins parts compared to the original 5A specification.
Q: What is the difference between gold and tin contact finishes?
A: Contact finish affects corrosion resistance and solderability. Gold finish (PBC36SAAN, PGC36SAAN, TSW-136-07-G-S, TSW-136-07-S-S) provides superior corrosion resistance and is preferred for long-term reliability in harsh environments. Tin finish (PEC36SAAN, TSW-136-07-L-S) offers cost advantages and adequate performance in standard applications. Both finishes are compatible with standard PCB assembly processes.
Q: Are these parts RoHS compliant?
A: Yes. All substitute parts listed are ROHS3 compliant, whereas the original 75160-156-36 is RoHS non-compliant. This compliance upgrade is beneficial for new designs and applications subject to RoHS regulations.
Q: What is the significance of contact material differences?
A: The original part uses phosphor bronze contacts. Most substitutes (PBC36SAAN, PBC36SABN, PEC36SAAN, PEC36SABN, TSW series) maintain phosphor bronze for electrical performance consistency. PGC36SAAN uses copper alloy, and 800-10-036-10-002000 uses brass alloy. Phosphor bronze is preferred for spring characteristics and electrical conductivity; alternative materials are acceptable where application requirements permit.
Q: How do operating temperature ranges compare?
A: The original 75160-156-36 operates from -65°C to 130°C. Sullins parts (PBC and PEC series) operate -65°C to 125°C, covering most applications. Samtec TSW series operates -55°C to 125°C, suitable for standard industrial and commercial applications. For applications requiring the full -65°C lower limit, Sullins parts are preferred.
Q: What is the difference between standard and breakaway connector types?
A: Breakaway connectors (PBC36SAAN, PBC36SABN, PEC36SAAN, PEC36SABN) allow individual pins to be separated from the header after assembly, providing design flexibility. Standard headers (PGC36SAAN, TSW series, 800-10-036-10-002000) maintain rigid 36-position configuration. Select based on your assembly and application requirements.
Q: Can I use the 75869-304LF as a substitute?
A: No. The 75869-304LF is a 20-position, 2-row connector with different pitch spacing (0.100" row spacing) and shrouded configuration. It does not meet the 36-position, single-row, unshrouded requirements of the 75160-156-36.
