Würth Elektronik 7499011002 RJ45 Modular Connector - Equivalent & Substitute Parts

Part Overview

The Würth Elektronik 7499011002 is a 1-port RJ45 through-hole modular connector designed for 10/100 Base-T Ethernet applications with AutoMDIX functionality. This connector features a 90° right-angle orientation, shielded design with EMI finger protection, and gold-plated tin contacts. The part is currently listed as obsolete, necessitating identification of active equivalent alternatives to maintain design continuity and ensure supply chain availability for new production runs and field replacements.

Substiute Parts

7499011002

Würth ElektronikIn Stock: 9807499011002 Datasheet

Current PartRFQ

7499011002A

Würth ElektronikIn Stock: 8567499011002A Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

The substitute part 7499011002A is classified as a direct equivalent based on the following critical parameters that determine functional interchangeability:

• Connector Type: RJ45 (identical)
• Number of Ports: 1 (identical)
• Mounting Type: Through Hole (identical)
• Orientation: 90° Angle (Right) (identical)
• Applications: 10/100 Base-T, AutoMDIX (identical)
• Height Above Board: 0.541" (13.75mm) (identical)
• Shielding: Shielded, EMI Finger (identical)
• Contact Material and Finish: Tin with Gold plating (identical)
• Operating Temperature Range: 0°C ~ 70°C (identical)
• RoHS Status: ROHS3 Compliant (identical)
• Series: WE-RJ45 LAN (identical)

The primary distinction between the main part and its substitute is product status and packaging configuration. The 7499011002A is currently active in production with tube packaging, whereas the 7499011002 is obsolete with standard packaging.

Parameter Comparison

Engineering Selection Recommendations

The 7499011002A is the direct active equivalent for the obsolete 7499011002. Both parts maintain identical electrical and mechanical specifications, including connector type, port configuration, mounting method, orientation, shielding characteristics, and contact materials. Both parts satisfy ROHS3 compliance and REACH regulatory requirements.

The transition from 7499011002 to 7499011002A is recommended for new designs and production continuity. The substitute part is currently in active production status with established supply chain availability. Packaging differences (tube versus standard) do not affect functional performance and should be evaluated based on assembly process requirements and volume considerations.

Frequently Asked Questions (FAQ)

Q: Can 7499011002A be used as a direct replacement for 7499011002 in existing designs?

A: Yes. The 7499011002A is a direct functional equivalent with identical electrical and mechanical parameters. All critical specifications including connector type, port count, mounting configuration, orientation, shielding, contact materials, and operating temperature range are identical.

Q: What is the primary reason for substitution?

A: The 7499011002 is obsolete. The 7499011002A is the active production equivalent from Würth Elektronik within the WE-RJ45 LAN series, ensuring continued supply availability and design support.

Q: Are there packaging considerations when switching from 7499011002 to 7499011002A?

A: The main part uses standard packaging while the substitute uses tube packaging. This difference does not affect electrical or mechanical performance. Assembly process compatibility should be evaluated based on your specific pick-and-place or manual assembly requirements.

Q: Do both parts meet the same regulatory and compliance standards?

A: Yes. Both 7499011002 and 7499011002A are ROHS3 compliant and REACH unaffected. Both maintain MSL 1 (unlimited) moisture sensitivity level classification.

Q: Are the contact specifications identical between the two parts?

A: Yes. Both parts feature tin contact material with gold plating at 30.0µin (0.76µm) thickness, ensuring equivalent electrical performance and reliability in 10/100 Base-T Ethernet applications.
