TE Connectivity 747150-9 D-Sub 9-Position Receptacle Equivalent & Substitute Parts
Part Overview
The TE Connectivity 747150-9 is a 9-position D-Sub receptacle connector with female sockets, vertical through-hole mounting, and solder termination. This connector is part of the AMPLIMITE HD-20 series and is classified as obsolete. Due to its obsolete status, equivalent and substitute parts from active product lines are necessary for ongoing design support, maintenance, and new production applications. The substitute parts listed maintain functional compatibility through matching electrical and mechanical parameters while offering active product status and improved compliance certifications.
Substiute Parts
Key Parameters
| Parameter | Specification |
|---|---|
| Connector Style | D-Sub |
| Connector Type | Receptacle, Female Sockets |
| Number of Positions | 9 |
| Number of Rows | 2 |
| Shell Size, Connector Layout | 1 (DE, E) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Current Rating (Amps) | 6A |
| Voltage Rating | 125V |
| Operating Temperature | -55°C ~ 105°C |
| Material Flammability Rating | UL94 V-0 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
Substitute Part Grouping Explanation
Substitution of the TE Connectivity 747150-9 is determined by strict equivalence across the following critical parameters:
Primary Equivalence Criteria:
- Connector style: D-Sub
- Connector type: Receptacle, Female Sockets
- Number of positions: 9
- Number of rows: 2
- Shell size and layout: 1 (DE, E)
- Mounting type: Through Hole
- Termination method: Solder
- Material flammability rating: UL94 V-0
- Moisture sensitivity level: 1 (Unlimited)
Secondary Compatibility Parameters:
- Current rating: 6A or higher
- Voltage rating: 125V or higher
- Operating temperature range: Must encompass -55°C to 105°C or broader
- Contact type: Signal
Substitute parts are grouped into three categories: TE Connectivity direct equivalents with different packaging, HARTING alternatives with comparable electrical performance, and variants with enhanced compliance certifications. All listed substitutes meet or exceed the electrical and mechanical requirements of the main part.
Parameter Comparison
| Part Number | Manufacturer | Product Status | Positions | Current Rating (A) | Voltage Rating (V) | Operating Temp (°C) | Contact Finish | Shell Material | RoHS Status | Packaging |
|---|---|---|---|---|---|---|---|---|---|---|
| 747150-9 | TE Connectivity | Obsolete | 9 | 6 | 125 | -55 ~ 105 | Gold (Flash) | Steel, Tin Plated | Non-compliant | Bulk |
| 747150-7 | TE Connectivity | Active | 9 | 6 | 125 | -55 ~ 105 | Gold (Flash) | Steel, Tin Plated | Non-compliant | Bulk |
| 747150-8 | TE Connectivity | Active | 9 | 6 | 125 | -55 ~ 105 | Gold (30.0µin) | Steel, Tin Plated | Non-compliant | Bulk |
| 5747150-9 | TE Connectivity | Active | 9 | 6 | 125 | -55 ~ 105 | Gold (Flash) | Steel, Tin Plated | Compliant | Tube |
| 09641127210 | HARTING | Active | 9 | 7.5 | 100 | -20 ~ 125 | Not specified | Steel | ROHS3 Compliant | Bulk |
| 09641127230 | HARTING | Active | 9 | 7.5 | 100 | -20 ~ 125 | Not specified | Steel | ROHS3 Compliant | Bulk |
| 09641127240 | HARTING | Active | 9 | 7.5 | 100 | -20 ~ 125 | Not specified | Steel | ROHS3 Compliant | Bulk |
| 09661116503 | HARTING | Active | 9 | 6.5 | Not specified | -55 ~ 125 | Not specified | Steel | ROHS3 Compliant | Bulk |
| 09661117503 | HARTING | Active | 9 | 6.5 | Not specified | -55 ~ 125 | Not specified | Steel | ROHS3 Compliant | Bulk |
| 09661156503 | HARTING | Active | 9 | 6.5 | Not specified | -55 ~ 125 | Gold | Steel | ROHS3 Compliant | Not specified |
| 09661157503 | HARTING | Active | 9 | 6.5 | Not specified | -55 ~ 125 | Gold | Steel | ROHS3 Compliant | Bulk |
Engineering Selection Recommendations
TE Connectivity Direct Equivalents (Recommended for Direct Replacement)
The TE Connectivity 747150-7 and 747150-8 are functionally identical to the 747150-9 within the AMPLIMITE HD-20 series. Both parts are active products with identical electrical specifications (6A, 125V, -55°C to 105°C). The 747150-7 maintains the same gold flash contact finish as the original part. The 747150-8 provides a thicker gold plating (30.0µin) for enhanced durability. Both remain RoHS non-compliant, matching the original part's compliance status.
The TE Connectivity 5747150-9 is the RoHS-compliant variant of the 747150-9. This part is active and provides identical electrical and mechanical specifications with the addition of RoHS compliance certification. The 5747150-9 is packaged in tube format rather than bulk, which may affect procurement workflows.
HARTING Alternatives (Cross-Manufacturer Substitutes)
HARTING D-Sub 9-position receptacles (09641127210, 09641127230, 09641127240, 09661116503, 09661117503, 09661156503, 09661157503) provide functional substitution with the following considerations:
The HARTING 09641127 series (210, 230, 240) offers 7.5A current rating and 100V voltage rating, both exceeding the 6A and 125V specifications of the 747150-9. These parts feature filter functionality and machined contact forms. Operating temperature range is -20°C to 125°C, which covers the upper requirement but does not extend to -55°C.
The HARTING 09661116503 and 09661117503 provide 6.5A current rating and -55°C to 125°C operating temperature, fully encompassing the original part's thermal range. These parts feature female screwlock mating-side flanges and stamped contact forms.
The HARTING 09661156503 and 09661157503 provide gold contact finish with 6.5A current rating and -55°C to 125°C operating temperature. These parts also feature female screwlock mating-side flanges and are constructed with glass-filled dielectric materials.
All HARTING alternatives are ROHS3 compliant and REACH unaffected, providing enhanced regulatory compliance compared to the original 747150-9.
Compliance and Certification Considerations
The original 747150-9 is RoHS non-compliant and has undefined REACH status. For applications requiring RoHS compliance, the TE Connectivity 5747150-9 is the direct equivalent. For applications requiring both RoHS and REACH compliance, HARTING alternatives provide ROHS3 compliance and REACH unaffected status.
All substitute parts maintain UL94 V-0 material flammability rating and MSL 1 (Unlimited) moisture sensitivity level, ensuring compatibility with existing design requirements.
Frequently Asked Questions (FAQ)
Q: Can the 747150-7 or 747150-8 be used as direct replacements for the obsolete 747150-9?
A: Yes. The 747150-7 and 747150-8 are active TE Connectivity products within the same AMPLIMITE HD-20 series with identical electrical specifications (9 positions, 6A, 125V, -55°C to 105°C) and mechanical configuration (D-Sub receptacle, female sockets, through-hole solder termination). Both parts are functionally equivalent to the 747150-9.
Q: What is the difference between 747150-7 and 747150-8?
A: The primary difference is contact finish thickness. The 747150-7 has gold flash plating, matching the original 747150-9. The 747150-8 has thicker gold plating at 30.0µin (0.76µm), providing enhanced contact durability and wear resistance. Both maintain identical electrical performance.
Q: Is the 5747150-9 compatible with the 747150-9?
A: Yes. The 5747150-9 is the RoHS-compliant variant of the 747150-9 with identical electrical and mechanical specifications. The primary difference is RoHS compliance certification and tube packaging instead of bulk. This part is suitable for applications requiring RoHS compliance.
Q: Can HARTING D-Sub connectors substitute for TE Connectivity 747150-9?
A: HARTING D-Sub 9-position receptacles provide functional substitution with the following qualifications: All HARTING alternatives maintain 9-position D-Sub receptacle configuration with female sockets, through-hole mounting, and solder termination. Current ratings (6.5A to 7.5A) and operating temperature ranges meet or exceed the 747150-9 specifications. However, HARTING parts feature different flange designs (unthreaded or female screwlock) and dielectric materials compared to the TE Connectivity housing/shell 4-40 flange. Mechanical fit and mating interface compatibility must be verified for specific applications.
Q: What are the key electrical parameters that determine substitution compatibility?
A: The critical electrical parameters are: 9-position count, 2-row configuration, 6A or higher current rating, 125V or higher voltage rating, and operating temperature range encompassing -55°C to 105°C. All listed substitute parts meet these minimum requirements.
Q: Do all substitute parts have the same packaging as the 747150-9?
A: No. The 747150-9 is supplied in bulk packaging. The 747150-7 and 747150-8 are also bulk packaged. The 5747150-9 is supplied in tube packaging. HARTING parts are supplied in bulk or unspecified packaging. Packaging differences may affect procurement, handling, and inventory management but do not affect electrical or mechanical compatibility.
Q: Are there compliance differences between the substitute parts?
A: Yes. The original 747150-9 is RoHS non-compliant with undefined REACH status. The TE Connectivity 5747150-9 is RoHS compliant. All HARTING alternatives are ROHS3 compliant and REACH unaffected. For applications requiring specific compliance certifications, part selection must align with regulatory requirements.
Q: What is the difference between flash gold plating and 30.0µin gold plating?
A: Flash gold plating is a very thin layer (typically 0.1 to 0.5µm) applied for corrosion protection and contact conductivity. The 30.0µin (0.76µm) plating on the 747150-8 is thicker, providing enhanced durability and extended contact life under repeated mating cycles. Both finishes meet electrical requirements; the thicker plating is beneficial for high-cycle applications.
Q: Can the 747150-9 be used interchangeably with HARTING 09661156503 or 09661157503?
A: Functional substitution is possible with mechanical verification. Both HARTING parts maintain 9-position D-Sub receptacle configuration, female sockets, through-hole solder termination, and gold contact finish. Current rating (6.5A) and operating temperature (-55°C to 125°C) exceed the 747150-9 specifications. However, the HARTING parts feature female screwlock mating-side flanges and glass-filled dielectric materials, which differ from the TE Connectivity housing/shell 4-40 flange design. Mating interface compatibility and mechanical fit must be confirmed for the specific application.
Q: Which substitute part is recommended for new designs?
A: For new designs requiring TE Connectivity compatibility, the 5747150-9 is recommended as it provides RoHS compliance and active product status. For applications requiring cross-manufacturer flexibility and enhanced compliance certifications, HARTING 09661156503 or 09661157503 provide ROHS3 compliance, REACH unaffected status, and extended operating temperature range (-55°C to 125°C).
