TE Connectivity AMP Connectors 745854-5 D-Sub Backshell Equivalent & Substitute Parts

Part Overview

The TE Connectivity AMP Connectors 745854-5 is a 9 Position Two Piece Backshell Connector with 180° cable exit and shielding, designed for D-Sub connector applications. This component functions as an accessory backshell assembly for AMPLIMITE series connectors, providing mechanical strain relief and electromagnetic shielding for round cable configurations.

The 745854-5 carries an Obsolete product status, necessitating identification of functionally equivalent alternatives for ongoing procurement and system maintenance. Active substitute components are available that maintain identical electrical and mechanical specifications while offering current product availability and updated compliance certifications.

Substiute Parts

745854-5

TE Connectivity AMP ConnectorsIn Stock: 972745854-5 Datasheet

Current PartRFQ

5745854-5

TE Connectivity AMP ConnectorsIn Stock: 10125745854-5 Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the 745854-5 is determined by strict equivalence across all mechanical and electrical parameters. The substitute component must satisfy the following criteria:

Critical Substitution Parameters:

• Accessory Type: Two Piece Backshell (identical configuration)
• Number of Positions: 9 (exact match required)
• Compatible Shell Size: E (mechanical fit requirement)
• Compatible D-Sub Size: 9pos and HD15pos (connector compatibility)
• Cable Type: Round (cable interface specification)
• Cable Exit Angle: 180° (orientation requirement)
• Shielding: Shielded (electromagnetic performance)
• Primary Material: Plastic/Thermoplastic (material composition)
• Plating: Nickel over Copper (corrosion resistance and conductivity)
• Hardware: Assembly Hardware, Strain Relief (functional features)
• Mating Features: Mating Screws 4-40 (assembly specification)
• Color: Silver (aesthetic and material specification)
• Series: AMPLIMITE (product line compatibility)

The substitute part 5745854-5 meets all specified parameters without deviation, establishing direct functional and mechanical equivalence.

Parameter Comparison

Engineering Selection Recommendations

The substitute part 5745854-5 is the direct equivalent for the obsolete 745854-5. Selection of the substitute component is based on the following engineering factors:

Product Status: The 745854-5 is classified as Obsolete, limiting long-term procurement viability. The 5745854-5 maintains Active product status, ensuring continued availability and manufacturer support.

Compliance Certifications: The 5745854-5 carries RoHS Compliant certification, compared to the non-compliant status of the original part. This upgrade aligns with current regulatory requirements for electronic component procurement in regulated industries. The 5745854-5 also provides defined REACH Affected status, eliminating vendor uncertainty present in the original specification.

Functional Equivalence: All electrical and mechanical parameters remain identical between the two components. The 5745854-5 maintains the same connector interface specifications, shielding characteristics, material composition, and assembly hardware requirements as the 745854-5.

Packaging Consideration: The 5745854-5 is supplied in Bulk packaging, whereas the original part packaging is unspecified. Bulk packaging is standard for backshell components and does not affect functional performance or installation procedures.

For applications requiring the 9 Position Two Piece Backshell with 180° cable exit and shielding for AMPLIMITE series D-Sub connectors, the 5745854-5 provides direct substitution with enhanced compliance status and active product availability.
