Amphenol ICC 71918-260 Equivalent & Substitute Parts

Part Overview

The Amphenol ICC 71918-260 is a rectangular connector header with vertical orientation, 60 positions, and 2.54mm pitch designed for through-hole mounting. This component is classified as obsolete, making equivalent and substitute parts necessary for ongoing design support and production continuity. The part features shrouded 4-wall construction with solder termination and latch lock/eject hook fastening, suitable for board-to-cable/wire applications in industrial and commercial electronics.

Key Parameters

Parameter	Value
Manufacturer Part Number	71918-260
Manufacturer	Amphenol ICC (FCI)
Connector Type	Header
Contact Type	Male Pin
Number of Positions	60
Number of Rows	2
Pitch - Mating	0.100" (2.54mm)
Mounting Type	Through Hole
Orientation	Vertical
Shrouding	Shrouded - 4 Wall
Termination	Solder
Contact Finish - Mating	Gold, GXT™
Contact Material	Phosphor Bronze
Insulation Material	Thermoplastic, Glass Filled
Material Flammability Rating	UL94 V-0
Product Status	Obsolete
RoHS Status	RoHS non-compliant

Substitute Part Grouping Explanation

Substitute parts for the 71918-260 are grouped based on the following critical parameters that determine functional compatibility:

Primary Substitution Criteria:

Connector type (Header)
Contact type (Male Pin)
Number of positions (60)
Number of rows (2)
Pitch - mating (0.100" / 2.54mm)
Shrouding (Shrouded - 4 Wall)
Termination (Solder)
Mounting type (Through Hole)

Grouping Categories:

Group 1: Direct Amphenol ICC Equivalents (Same Orientation - Vertical)

71918-260LF: Active product status, RoHS compliant, identical electrical and mechanical specifications with tin post finish

Group 2: Amphenol ICC Right-Angle Variant

71922-160LF: Right-angle mounting orientation, otherwise matching core specifications

Group 3: HARTING SEK Series Vertical Equivalents

09185606904: Vertical orientation, copper alloy contacts, operating temperature -55°C ~ 125°C
09185606912: Vertical orientation, extended post length (0.177"), copper alloy contacts, operating temperature -55°C ~ 125°C

Group 4: HARTING SEK Series Right-Angle Variants

09185606921, 09185606923, 09185607323: Right-angle mounting with varying fastening types and post lengths

Group 5: Position Count Variants

09185645913, 09185645914: 64-position headers (not direct substitutes due to position count difference)

Parameter Comparison

Parameter	71918-260 (Main)	71918-260LF	71922-160LF	09185606904	09185606912
Manufacturer	Amphenol ICC	Amphenol ICC	Amphenol ICC	HARTING	HARTING
Connector Type	Header	Header	Header	Header	Header
Contact Type	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin
Number of Positions	60	60	60	60	60
Number of Rows	2	2	2	2	2
Pitch - Mating	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)
Mounting Type	Through Hole	Through Hole	Through Hole, Right Angle	Through Hole	Through Hole
Shrouding	Shrouded - 4 Wall	Shrouded - 4 Wall	Shrouded - 4 Wall	Shrouded - 4 Wall	Shrouded - 4 Wall
Termination	Solder	Solder	Solder	Solder	Solder
Contact Finish - Mating	Gold, GXT™	Gold, GXT™	Gold, GXT™	Gold	Gold
Contact Material	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Copper Alloy	Copper Alloy
Insulation Material	Thermoplastic, Glass Filled	Thermoplastic, Glass Filled	Thermoplastic, Glass Filled	Polybutylene Terephthalate (PBT), Glass Filled	Polybutylene Terephthalate (PBT), Glass Filled
Material Flammability Rating	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0
Product Status	Obsolete	Active	Active	Active	Active
RoHS Status	RoHS non-compliant	RoHS Compliant	RoHS Compliant	ROHS3 Compliant	ROHS3 Compliant
Operating Temperature	Not specified	Not specified	Not specified	-55°C ~ 125°C	-55°C ~ 125°C

Engineering Selection Recommendations

For Direct Replacement (Vertical Orientation, Same Footprint):

The 71918-260LF is the primary recommended substitute. It maintains identical electrical and mechanical specifications to the 71918-260 while offering active product status and RoHS compliance. The transition from phosphor bronze to phosphor bronze contact material and the addition of tin post finish (78.7µin / 2.00µm) provides improved environmental protection. This part is suitable for new designs and production continuity without PCB layout modifications.

For Right-Angle Mounting Applications:

The 71922-160LF provides equivalent electrical specifications with right-angle orientation. This variant is appropriate when vertical space is constrained or when cable routing requires perpendicular connector orientation. RoHS compliance and active status make this suitable for modern applications.

For Extended Operating Temperature Range:

HARTING SEK series parts (09185606904, 09185606912) offer specified operating temperature ranges of -55°C ~ 125°C, compared to unspecified ratings for Amphenol ICC parts. These are suitable for applications requiring documented thermal performance. The copper alloy contact material and PBT insulation material provide alternative material specifications while maintaining core electrical and mechanical compatibility.

For Legacy System Support:

When RoHS non-compliance is acceptable or required for legacy system compatibility, the 71918-260 remains available with 941 pieces in stock. However, for new production, RoHS-compliant alternatives are recommended.

Frequently Asked Questions (FAQ)

Q: Can the 71918-260LF be used as a direct replacement for the 71918-260?

A: Yes. The 71918-260LF is a direct equivalent with identical pitch (0.100" / 2.54mm), position count (60), row configuration (2), shrouding (4-wall), and mounting type (through-hole vertical). The primary differences are active product status and RoHS compliance. No PCB layout changes are required.

Q: What is the difference between the 71918-260LF and 71922-160LF?

A: The 71922-160LF features right-angle mounting orientation instead of vertical. Both maintain 60 positions, 2.54mm pitch, and 4-wall shrouding. Selection depends on PCB layout requirements and available mounting space.

Q: Are HARTING SEK series parts (09185606904, 09185606912) compatible with the 71918-260?

A: Yes, for electrical and mechanical compatibility. Both maintain 60 positions, 2.54mm pitch, 2-row configuration, and 4-wall shrouding. HARTING parts offer specified operating temperature ranges (-55°C ~ 125°C) and use copper alloy contacts with PBT insulation instead of phosphor bronze and thermoplastic. These differences do not affect pin-to-pin compatibility but may impact thermal and environmental performance characteristics.

Q: Why are 09185645913 and 09185645914 listed as substitutes if they have 64 positions?

A: These parts are listed as cross-reference options but are not direct substitutes due to the 64-position configuration versus the 60-position requirement. They are relevant only for applications where position count can be modified.

Q: What packaging options are available for substitute parts?

A: The 71918-260LF is supplied in tube packaging. HARTING SEK series parts are supplied in bulk packaging. Packaging selection may affect procurement logistics and handling requirements.

Q: Is the 71918-260 still available for purchase?

A: The 71918-260 is classified as obsolete but remains available with 941 pieces in stock. For new designs and long-term production support, the active-status 71918-260LF is recommended.
