Amphenol ICC 69192-172 Equivalent & Substitute Parts

Part Overview

The Amphenol ICC 69192-172 is a rectangular connector header featuring 72 positions at 0.100" (2.54mm) pitch, designed for through-hole board-to-board applications. This component is classified as obsolete, necessitating identification of active equivalent parts that maintain electrical and mechanical compatibility. The BERGSTIK® II series connector provides male pin contacts with kinked pin solder termination and push-pull fastening. Substitute parts must preserve the 72-position configuration, 2.54mm pitch, through-hole mounting, and 3A current rating to ensure functional equivalence in legacy system designs.

Key Parameters

Parameter	Value
Manufacturer Part Number	69192-172
Manufacturer	Amphenol ICC (FCI)
Category	Rectangular Connectors
Connector Type	Header
Contact Type	Male Pin
Number of Positions	72
Number of Rows	2
Pitch - Mating	0.100" (2.54mm)
Row Spacing - Mating	0.100" (2.54mm)
Mounting Type	Through Hole
Termination	Kinked Pin, Solder
Fastening Type	Push-Pull
Current Rating	3A
Operating Temperature	-65°C ~ 130°C
Product Status	Obsolete
RoHS Status	RoHS non-compliant

Substitute Part Grouping Explanation

Substitution eligibility for the 69192-172 is determined by strict adherence to the following core parameters:

Critical Parameters (Must Match):

Number of Positions: 72
Number of Rows: 2
Pitch - Mating: 0.100" (2.54mm)
Row Spacing - Mating: 0.100" (2.54mm)
Connector Type: Header
Contact Type: Male Pin
Mounting Type: Through Hole
Termination: Solder
Fastening Type: Push-Pull
Current Rating: 3A minimum
Material Flammability Rating: UL94 V-0

Allowable Variations:

Contact Shape: Square or Circular (both acceptable for 2.54mm pitch headers)
Contact Finish: Gold, Tin, or mixed finishes (all provide electrical continuity)
Contact Material: Phosphor Bronze or Brass (both meet current and temperature requirements)
Insulation Material: Various polymers meeting UL94 V-0 (functional equivalence maintained)
Operating Temperature Range: Minimum -55°C to 125°C acceptable (covers standard industrial range)
Product Status: Active preferred for long-term availability
RoHS Compliance: ROHS3 compliant variants preferred for regulatory alignment

Substitute parts are grouped by manufacturer series and contact finish specifications while maintaining all critical electrical and mechanical parameters.

Parameter Comparison

Parameter	69192-172 (Main)	450-10-272-00-013101	450-80-272-00-001101	450-V3-272-00-006101	DW-36-07-L-D-200	GBC36DAAN	MTLW-136-06-F-D-220	MTLW-136-06-T-D-240	MTLW-136-07-F-D-230	MTLW-136-07-F-D-250	MTLW-136-07-F-D-255
Manufacturer	Amphenol ICC	Preci-Dip	Preci-Dip	Preci-Dip	Samtec Inc.	Sullins	Samtec Inc.	Samtec Inc.	Samtec Inc.	Samtec Inc.	Samtec Inc.
Number of Positions	72	72	72	72	72	72	72	72	72	72	72
Number of Rows	2	2	2	2	2	2	2	2	2	2	2
Pitch - Mating	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)
Row Spacing - Mating	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)
Connector Type	Header	Header	Header	Header	Header	Header, Breakaway	Header	Header	Header	Header	Header
Contact Type	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin
Mounting Type	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole
Termination	Kinked Pin, Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder
Fastening Type	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull
Current Rating (Amps)	3A	3A	3A	3A	3A	3A	5.2A per Contact	5.2A per Contact	5.2A per Contact	5.2A per Contact	5.2A per Contact
Operating Temperature	-65°C ~ 130°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C	Not specified	-65°C ~ 150°C	-55°C ~ 125°C	-55°C ~ 105°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C
Contact Shape	Square	Circular	Circular	Circular	Not specified	Square	Square	Square	Square	Square	Square
Contact Material	Phosphor Bronze	Brass	Brass	Brass	Not specified	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze
Contact Finish - Mating	Gold or Gold, GXT™	Gold	Tin	Gold	Gold	Gold	Gold	Tin	Gold	Gold	Gold
Material Flammability Rating	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0
RoHS Status	RoHS non-compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant
Product Status	Obsolete	Active	Active	Active	Active	Active	Active	Active	Active	Active	Active

Engineering Selection Recommendations

All listed substitute parts maintain electrical and mechanical compatibility with the 69192-172 across the critical parameters of position count, pitch, row spacing, connector type, contact type, mounting method, termination, and fastening mechanism.

Preci-Dip 450 Series (450-10-272-00-013101, 450-80-272-00-001101, 450-V3-272-00-006101): These parts are active and ROHS3 compliant, offering direct functional equivalence. The 450 series provides circular contact geometry with brass material, differing from the original square phosphor bronze contacts. Contact finish options include gold and tin variants. All three maintain the 3A current rating and UL94 V-0 flammability rating. Operating temperature range is -55°C to 125°C, which covers standard industrial applications.

Samtec DW-36-07-L-D-200: This active part provides gold-plated contacts and ROHS3 compliance. The DW series is designed as a spacer connector with specified stack height, offering a compact profile alternative. Current rating meets the 3A requirement, and UL94 V-0 flammability is maintained.

Sullins GBC36DAAN: This active connector offers square contact geometry matching the original 69192-172 design, with phosphor bronze material and gold contact finish. The GBC36DAAN extends the operating temperature range to -65°C to 150°C, providing enhanced thermal performance. ROHS3 compliance and UL94 V-0 rating are confirmed. The breakaway header feature provides additional mechanical flexibility.

Samtec MTLW Series (MTLW-136-06-F-D-220, MTLW-136-06-T-D-240, MTLW-136-07-F-D-230, MTLW-136-07-F-D-250, MTLW-136-07-F-D-255): These active Flex Stack connectors provide higher current capacity at 5.2A per contact, exceeding the original 3A rating. All variants feature square phosphor bronze contacts with UL94 V-0 flammability and ROHS3 compliance. Contact finish options include gold and tin. The MTLW series offers reduced insulation height (0.060" vs. 0.100") and liquid crystal polymer insulation material. Operating temperature ranges from -55°C to 125°C (or -55°C to 105°C for the tin-finish variant). These parts are suitable for applications requiring enhanced current handling or compact form factors.

Frequently Asked Questions (FAQ)

Q: Can I substitute the 69192-172 with any of the listed parts?

A: Yes. All listed parts maintain the critical parameters: 72 positions, 2 rows, 0.100" (2.54mm) pitch, male pin contacts, through-hole mounting, solder termination, push-pull fastening, 3A minimum current rating, and UL94 V-0 flammability. Variations in contact shape (square vs. circular), contact material (phosphor bronze vs. brass), and contact finish (gold vs. tin) do not affect functional equivalence for standard board-to-board applications.

Q: What is the difference between the Preci-Dip 450 variants?

A: The three Preci-Dip 450 series parts differ in contact finish and post length specifications. The 450-10-272-00-013101 features gold-plated contacts with 10.0µin thickness. The 450-80-272-00-001101 uses tin finish with longer post length (0.164"). The 450-V3-272-00-006101 combines gold mating finish with tin post finish. All three maintain identical electrical performance and 3A current rating.

Q: Why do the Samtec MTLW parts have higher current ratings?

A: The MTLW series is rated at 5.2A per contact, compared to the 3A rating of the original 69192-172. This higher capacity results from optimized contact geometry and material selection in the Flex Stack design. The increased current rating does not affect compatibility; it simply provides additional margin for applications with higher current demands.

Q: Are there RoHS compliance considerations?

A: The original 69192-172 is RoHS non-compliant. All substitute parts listed are ROHS3 compliant, meeting current regulatory requirements for new designs and procurement. If legacy RoHS non-compliant designs are required, the original part number should be sourced directly.

Q: What is the difference between square and circular contact shapes?

A: Both square and circular contact geometries are functionally equivalent for 2.54mm pitch headers. Square contacts (original design and Sullins/Samtec variants) and circular contacts (Preci-Dip variants) provide identical electrical continuity and mechanical engagement. Selection depends on PCB design compatibility and manufacturing preferences.

Q: Can I use the Samtec MTLW parts in place of the original connector?

A: Yes. The MTLW series maintains all critical parameters and provides enhanced performance through higher current capacity (5.2A per contact) and improved insulation material (liquid crystal polymer). The reduced insulation height (0.060" vs. 0.100") may require PCB layout verification to ensure adequate clearance, but electrical and mechanical compatibility is maintained.

Q: What is the inventory status of these substitute parts?

A: All listed substitute parts are confirmed as active products with current inventory availability ranging from 736 to 1115 pieces. The original 69192-172 has 837 pieces in stock but is classified as obsolete, making active substitutes preferable for long-term supply chain stability.
