Amphenol ICC 69192-106 Rectangular Connector Header – Equivalent & Substitute Parts

Part Overview

The Amphenol ICC 69192-106 is a through-hole rectangular connector header from the BERGSTIK® II series, configured as a 6-position, 2-row male pin header with 0.100" (2.54mm) pitch. This component is classified as obsolete, making equivalent and substitute parts necessary for ongoing production and maintenance applications. The connector is designed for board-to-board connections with push-pull fastening and operates across a wide temperature range of -65°C to 130°C. Substitution is required to ensure design continuity and component availability.

Key Parameters

Parameter	Value
Manufacturer Part Number	69192-106
Manufacturer	Amphenol ICC (FCI)
Series	BERGSTIK® II
Product Status	Obsolete
Connector Type	Header
Contact Type	Male Pin
Pitch – Mating	0.100" (2.54mm)
Number of Positions	6
Number of Rows	2
Row Spacing – Mating	0.100" (2.54mm)
Mounting Type	Through Hole
Termination	Kinked Pin, Solder
Fastening Type	Push-Pull
Contact Shape	Square
Contact Finish – Mating	Gold or Gold, GXT™
Contact Material	Phosphor Bronze
Operating Temperature	-65°C ~ 130°C
Current Rating	3A
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS non-compliant
REACH Status	REACH Affected

Substitute Part Grouping Explanation

Substitution for the 69192-106 is determined by strict adherence to the following electrical and mechanical parameters:

Critical Matching Parameters:

Pitch – Mating: 0.100" (2.54mm) – exact match required
Number of Positions: 6 – exact match required
Number of Rows: 2 – exact match required
Row Spacing – Mating: 0.100" (2.54mm) – exact match required
Contact Type: Male Pin – exact match required
Mounting Type: Through Hole – exact match required
Fastening Type: Push-Pull – exact match required
Current Rating: 3A – minimum requirement

Acceptable Variation Parameters:

Contact Shape: Square or Circular (both accommodate standard mating interfaces)
Contact Finish – Mating: Gold finishes (including GXT™, standard gold, or tin) maintain electrical performance
Termination: Solder or Press-Fit/Solder combinations are functionally equivalent
Operating Temperature Range: Substitute must meet or exceed -65°C to 130°C minimum
Contact Material: Phosphor Bronze, Copper Alloy, or Brass Alloy are electrically equivalent
Insulation Material: Thermoplastic, LCP, or PCT are mechanically equivalent

Substitute parts are grouped into two categories: Active Status Parts (recommended for new designs) and Obsolete Status Parts (suitable for legacy system maintenance).

Parameter Comparison

Parameter	69192-106 (Main)	008261063210854	104350-3	146090-3	146256-3	450-10-206-00-001000	450-10-206-00-001101	450-10-206-00-006000	450-10-206-00-013101	450-80-206-00-001101	450-80-206-00-013101
Manufacturer	Amphenol ICC	KYOCERA AVX	TE Connectivity	TE Connectivity	TE Connectivity	Mill-Max	Preci-Dip	Mill-Max	Preci-Dip	Preci-Dip	Preci-Dip
Pitch – Mating	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)
Number of Positions	6	6	6	6	6	6	6	6	6	6	6
Number of Rows	2	2	2	2	2	2	2	2	2	2	2
Row Spacing – Mating	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)
Contact Type	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin
Mounting Type	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole
Fastening Type	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull
Contact Shape	Square	Square	Square	Square	Square	Circular	Circular	Circular	Circular	Circular	Circular
Contact Finish – Mating	Gold or Gold, GXT™	Gold	Gold	Gold	Gold	Gold	Gold	Gold	Gold	Tin	Tin
Contact Material	Phosphor Bronze	Copper Alloy	Copper Alloy	Copper Alloy	Copper Alloy	Brass Alloy	Brass	Brass Alloy	Brass	Brass	Brass
Operating Temperature	-65°C ~ 130°C	-55°C ~ 85°C	-65°C ~ 105°C	-65°C ~ 105°C	-65°C ~ 105°C	Not specified	-55°C ~ 125°C	Not specified	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C
Current Rating	3A	3A per Contact	3A	3A	3A	Not specified	3A	Not specified	3A	3A	3A
Product Status	Obsolete	Active	Obsolete	Active	Obsolete	Active	Active	Active	Active	Active	Active
RoHS Status	RoHS non-compliant	ROHS3 Compliant	RoHS non-compliant	RoHS non-compliant	RoHS non-compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant

Engineering Selection Recommendations

For New Designs – Active Status Parts with RoHS3 Compliance:

The following parts are recommended for new product development due to active product status and RoHS3 compliance:

008261063210854 (KYOCERA AVX 8261 Series): Active status with ROHS3 compliance. Operating temperature range of -55°C to 85°C is suitable for standard industrial applications. Note: lower temperature ceiling than original part.
146090-3 (TE Connectivity AMPMODU Mod II): Active status with UL94 V-0 flammability rating. Maintains -65°C to 105°C operating range, closer to original specifications. RoHS non-compliant status requires regulatory assessment.
450-10-206-00-001101 (Preci-Dip 450 Series): Active status with ROHS3 compliance and UL94 V-0 rating. Operating temperature -55°C to 125°C. Circular contact geometry is functionally equivalent. Gold-plated finish.
450-10-206-00-013101 (Preci-Dip 450 Series): Active status with ROHS3 compliance and UL94 V-0 rating. Operating temperature -55°C to 125°C. Shorter contact length variant. Gold-plated finish.
450-80-206-00-001101 (Preci-Dip 450 Series): Active status with ROHS3 compliance and UL94 V-0 rating. Tin-plated finish alternative to gold. Operating temperature -55°C to 125°C.
450-80-206-00-013101 (Preci-Dip 450 Series): Active status with ROHS3 compliance and UL94 V-0 rating. Tin-plated finish. Shorter contact length variant. Operating temperature -55°C to 125°C.

For Legacy System Maintenance – Obsolete Status Parts:

104350-3 (TE Connectivity AMPMODU Mod II): Obsolete status. Maintains electrical and mechanical compatibility. UL94 V-0 rating. Operating temperature -65°C to 105°C.
146256-3 (TE Connectivity AMPMODU Mod II): Obsolete status. LCP insulation material variant. UL94 V-0 rating. Operating temperature -65°C to 105°C.

Temperature Consideration: The original 69192-106 operates to 130°C. Substitute parts with lower temperature ceilings (85°C to 125°C) are suitable for applications not exceeding their rated limits. Applications requiring the full -65°C to 130°C range should be evaluated against actual operating conditions.

RoHS Compliance: Mill-Max and Preci-Dip 450 series parts offer ROHS3 compliance, supporting modern regulatory requirements. TE Connectivity and KYOCERA AVX alternatives are RoHS non-compliant and require compliance assessment for target markets.

Frequently Asked Questions (FAQ)

Q: Can I substitute the 69192-106 with any of these parts directly?

A: Direct substitution is possible for all listed parts. All maintain the critical parameters: 6-position, 2-row configuration with 0.100" (2.54mm) pitch, male pin contacts, through-hole mounting, and push-pull fastening. Physical footprint and mating interface are identical.

Q: What is the difference between square and circular contact shapes?

A: Both square (69192-106, KYOCERA AVX, TE Connectivity parts) and circular (Mill-Max, Preci-Dip 450 series) contacts are mechanically and electrically compatible within the 0.100" (2.54mm) pitch standard. Contact shape does not affect mating performance or current-carrying capacity at 3A rating.

Q: Why do some parts have lower operating temperature ranges?

A: The original 69192-106 operates from -65°C to 130°C. Substitute parts vary: KYOCERA AVX 008261063210854 is rated to 85°C, TE Connectivity parts to 105°C, and Preci-Dip 450 series to 125°C. Selection depends on actual application temperature requirements. Applications not exceeding 105°C or 125°C can use these substitutes without thermal limitation.

Q: What is the significance of RoHS compliance?

A: RoHS3 compliance (Mill-Max and Preci-Dip 450 series) indicates restriction of hazardous substances per EU Directive 2011/65/EU. RoHS non-compliant parts (original and TE Connectivity alternatives) may face regulatory restrictions in certain markets. New designs should prioritize ROHS3-compliant alternatives.

Q: Are gold-plated and tin-plated contacts interchangeable?

A: Yes. Both gold (450-10 series) and tin (450-80 series) finishes provide adequate electrical conductivity and corrosion resistance for 3A applications. Selection is based on cost, environmental exposure, and specific application requirements. Gold offers superior corrosion resistance; tin is cost-effective for standard environments.

Q: What packaging options are available?

A: Packaging varies by manufacturer: Bag (KYOCERA AVX), Bulk (TE Connectivity, Preci-Dip), and Tube (Mill-Max). Packaging does not affect electrical or mechanical performance and is selected based on procurement and assembly requirements.

Q: Can I use these parts in high-temperature applications exceeding 125°C?

A: No. The highest-rated substitute parts (Preci-Dip 450 series) are rated to 125°C maximum. Applications requiring operation above 125°C require alternative connector families not listed here. The original 69192-106 at 130°C maximum is marginally higher and should be sourced directly if this specification is critical.

Q: What is the difference between Press-Fit and Solder termination?

A: Both termination types are functionally equivalent for through-hole mounting. Solder termination (all listed parts) requires wave or reflow soldering. Press-Fit termination (TE Connectivity 104350-3) uses mechanical insertion without soldering. Selection depends on assembly process capability.
