Amphenol ICC 69190-504 Equivalent & Substitute Parts

Part Overview

The Amphenol ICC 69190-504 is a vertical through-hole rectangular connector header with 4 positions at 0.100" (2.54mm) pitch, designed for board-to-board applications. This connector is part of the BERGSTIK® II series and features male pins with gold-plated mating contacts and phosphor bronze construction. The part is currently obsolete, making equivalent substitutes necessary for new designs and ongoing production support.

Key Parameters

Parameter	Value
Manufacturer Part Number	69190-504
Manufacturer	Amphenol ICC (FCI)
Series	BERGSTIK® II
Product Status	Obsolete
Connector Type	Header
Contact Type	Male Pin
Pitch - Mating	0.100" (2.54mm)
Number of Positions	4
Number of Rows	1
Mounting Type	Through Hole
Termination	Press-Fit, Solder
Contact Length - Mating	0.230" (5.84mm)
Contact Length - Post	0.120" (3.05mm)
Overall Contact Length	0.450" (11.43mm)
Insulation Height	0.100" (2.54mm)
Contact Shape	Square
Contact Finish - Mating	Gold or Gold, GXT™
Contact Material	Phosphor Bronze
Operating Temperature	-65°C ~ 130°C
Material Flammability Rating	UL94 V-0
Insulation Color	Black
Current Rating	3A
RoHS Status	RoHS non-compliant
Moisture Sensitivity Level	1 (Unlimited)

Substitute Part Grouping Explanation

Substitution for the 69190-504 is determined by strict alignment of the following critical parameters:

Pitch - Mating: 0.100" (2.54mm) — exact match required
Number of Positions: 4 — exact match required
Number of Rows: 1 — exact match required
Connector Type: Header — exact match required
Contact Type: Male Pin — exact match required
Mounting Type: Through Hole — exact match required
Termination: Solder-compatible — required for PCB assembly
Contact Shape: Square — exact match required
Material Flammability Rating: UL94 V-0 — exact match required
Current Rating: 3A — minimum requirement
Operating Temperature Range: Must encompass or exceed -65°C ~ 130°C

Substitute parts are grouped by manufacturer and product line. All listed substitutes meet the electrical and mechanical compatibility requirements for direct replacement in applications originally designed for the 69190-504.

Parameter Comparison

Parameter	69190-504 (Main)	0423752488 (Molex)	2304-6111-TB (3M)	5-146274-4 (TE)	HTSW-104-07-G-S (Samtec)	PEC04SAAR (Sullins)
Pitch - Mating	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)
Number of Positions	4	4	4	4	4	4
Number of Rows	1	1	1	1	1	1
Connector Type	Header	Header, Breakaway	Header	Header, Breakaway	Header	Header, Breakaway
Contact Type	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin
Mounting Type	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole
Termination	Press-Fit, Solder	Solder	Solder	Solder	Solder	Kinked Pin, Solder
Contact Length - Mating	0.230" (5.84mm)	0.232" (5.90mm)	0.230" (5.84mm)	0.318" (8.08mm)	0.230" (5.84mm)	0.230" (5.84mm)
Contact Length - Post	0.120" (3.05mm)	0.153" (3.89mm)	0.120" (3.05mm)	0.125" (3.18mm)	0.100" (2.54mm)	0.120" (3.05mm)
Overall Contact Length	0.450" (11.43mm)	0.475" (12.07mm)	0.450" (11.43mm)	0.533" (14.65mm)	0.430" (10.92mm)	0.450" (11.43mm)
Insulation Height	0.100" (2.54mm)	0.090" (2.29mm)	0.100" (2.54mm)	0.090" (2.29mm)	0.100" (2.54mm)	0.100" (2.54mm)
Contact Shape	Square	Square	Square	Square	Square	Square
Contact Finish - Mating	Gold or Gold, GXT™	Gold	Gold	Tin	Gold	Tin
Contact Material	Phosphor Bronze	Not specified	Copper Alloy	Copper Alloy	Phosphor Bronze	Phosphor Bronze
Operating Temperature	-65°C ~ 130°C	Not specified	-55°C ~ 105°C	-65°C ~ 105°C	-55°C ~ 125°C	-65°C ~ 125°C
Material Flammability Rating	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0
Insulation Color	Black	Black	Black	Black	Natural	Black
Current Rating	3A	Not specified	3A	3A	Varies by Wire Gauge	3A
RoHS Status	RoHS non-compliant	ROHS3 Compliant	RoHS non-compliant	RoHS Compliant	ROHS3 Compliant	ROHS3 Compliant

Engineering Selection Recommendations

For RoHS3 Compliant Applications: Select from Molex 0423752488, TE Connectivity 5-146274-4, Samtec HTSW series (HTSW-104-07-G-S, HTSW-104-07-L-S, HTSW-104-07-S-S, HTSW-104-07-T-S, HTSW-104-07-FM-S), Samtec MTSW-104-07-F-S-200, or Sullins PEC04SAAR. These parts carry active product status and meet current regulatory compliance requirements.

For Legacy RoHS Non-Compliant Designs: The 3M 2304-6111-TB maintains RoHS non-compliant status matching the original 69190-504, suitable for applications where compliance status must remain unchanged.

For Extended Temperature Range: The Amphenol ICC 69190-504 operates to 130°C. Samtec HTSW series parts operate to 125°C and Sullins PEC04SAAR operates to 125°C, providing near-equivalent thermal performance. The 3M 2304-6111-TB is limited to 105°C and should not be selected for applications requiring the full -65°C ~ 130°C range.

For Gold-Plated Mating Contacts: Molex 0423752488, 3M 2304-6111-TB, and Samtec HTSW-104-07-G-S, HTSW-104-07-L-S, and HTSW-104-07-FM-S provide gold mating contact finishes. TE Connectivity 5-146274-4 and Samtec HTSW-104-07-T-S use tin mating finishes.

For Phosphor Bronze Contact Material: Samtec HTSW series and Sullins PEC04SAAR maintain phosphor bronze construction identical to the original part. Molex and TE Connectivity use unspecified or copper alloy materials.

Frequently Asked Questions (FAQ)

Q: Can I use a substitute part with a different contact length? A: Contact length variations exist among substitutes. The 69190-504 specifies 0.230" (5.84mm) mating contact length. TE Connectivity 5-146274-4 has 0.318" (8.08mm) mating contact length and Samtec HTSW series have 0.230" (5.84mm), matching the original. Verify mating depth compatibility with your connector receptacle before selection.

Q: What is the difference between the Samtec HTSW variants? A: HTSW-104-07-G-S, HTSW-104-07-L-S, HTSW-104-07-S-S, and HTSW-104-07-T-S differ in contact finish specifications. HTSW-104-07-G-S and HTSW-104-07-L-S provide gold mating finishes. HTSW-104-07-S-S provides gold mating with tin post finish. HTSW-104-07-T-S provides tin mating finish. All share identical pitch, position count, and mechanical dimensions.

Q: Is the 69190-504 truly obsolete? A: Yes, the 69190-504 carries obsolete product status. Active alternatives from Molex, 3M, TE Connectivity, Samtec, and Sullins are available with equivalent electrical and mechanical specifications.

Q: Do all substitutes meet UL94 V-0 flammability requirements? A: Yes, all listed substitute parts carry UL94 V-0 material flammability ratings, matching the original 69190-504.

Q: Which substitute offers the best RoHS compliance? A: Molex 0423752488, TE Connectivity 5-146274-4, Samtec HTSW series, Samtec MTSW-104-07-F-S-200, and Sullins PEC04SAAR all carry ROHS3 Compliant status. The 3M 2304-6111-TB remains RoHS non-compliant.

Q: Can I use these parts interchangeably in existing designs? A: Mechanical and electrical compatibility is established through matching pitch, position count, contact type, and current rating. Verify PCB footprint compatibility and mating receptacle depth requirements before substitution, as contact length and insulation height variations exist among alternatives.
