Amphenol ICC 67997-124 Rectangular Connector Header - Equivalent & Substitute Parts
Part Overview
The Amphenol ICC 67997-124 is a vertical rectangular connector header featuring 24 positions with 0.100" (2.54mm) pitch spacing. This through-hole component is part of the BERGSTIK® II series and is designed for board-to-board applications with solder termination and push-pull fastening. The part is currently obsolete, making equivalent and substitute parts necessary for ongoing design support and production requirements.
Substiute Parts
Key Parameters
| Parameter | Value |
|---|---|
| Manufacturer Part Number | 67997-124 |
| Manufacturer | Amphenol ICC (FCI) |
| Connector Type | Header |
| Contact Type | Male Pin |
| Number of Positions | 24 |
| Number of Rows | 2 |
| Pitch - Mating | 0.100" (2.54mm) |
| Row Spacing - Mating | 0.100" (2.54mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Fastening Type | Push-Pull |
| Operating Temperature | -65°C ~ 130°C |
| Current Rating | 3A |
| Material Flammability Rating | UL94 V-0 |
| Insulation Color | Black |
| Product Status | Obsolete |
Substitute Part Grouping Explanation
Substitution for the 67997-124 is determined by strict alignment of the following electrical and mechanical parameters:
- Connector Type & Style: Header, board-to-board configuration
- Contact Configuration: Male pin, 24 positions, 2 rows
- Pitch Specification: 0.100" (2.54mm) mating pitch and row spacing
- Mounting & Termination: Through-hole solder termination with push-pull fastening
- Electrical Performance: 3A current rating, UL94 V-0 flammability compliance
- Environmental Range: Operating temperature compatibility within -65°C to 130°C
Substitute parts are grouped into two categories: direct equivalents from Amphenol ICC with identical specifications, and cross-manufacturer alternatives from Molex, 3M, TE Connectivity, and Preci-Dip that maintain functional compatibility through matching core parameters.
Parameter Comparison
| Parameter | 67997-124 (Main) | 0010897241 (Molex) | 2324-6121-TG (3M) | 4-103186-0-12 (TE) | 450-10-224-00-001101 (Preci-Dip) | 450-80-224-00-001101 (Preci-Dip) |
|---|---|---|---|---|---|---|
| Connector Type | Header | Header, Breakaway | Header | Header, Breakaway | Header | Header |
| Contact Type | Male Pin | Male Pin | Male Pin | Male Pin | Male Pin | Male Pin |
| Number of Positions | 24 | 24 | 24 | 24 | 24 | 24 |
| Number of Rows | 2 | 2 | 2 | 2 | 2 | 2 |
| Pitch - Mating | 0.100" (2.54mm) | 0.100" (2.54mm) | 0.100" (2.54mm) | 0.100" (2.54mm) | 0.100" (2.54mm) | 0.100" (2.54mm) |
| Row Spacing - Mating | 0.100" (2.54mm) | 0.100" (2.54mm) | 0.100" (2.54mm) | 0.100" (2.54mm) | 0.100" (2.54mm) | 0.100" (2.54mm) |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Termination | Solder | Solder | Solder | Solder | Solder | Solder |
| Fastening Type | Push-Pull | Push-Pull | Push-Pull | Push-Pull | Push-Pull | Push-Pull |
| Current Rating (Amps) | 3A | — | 3A | 3A | 3A | 3A |
| Operating Temperature | -65°C ~ 130°C | — | -55°C ~ 105°C | -65°C ~ 105°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Material Flammability Rating | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 |
| Insulation Color | Black | Black | Black | Black | Black | Black |
| Product Status | Obsolete | Active | Active | Obsolete | Active | Active |
| RoHS Status | Non-compliant | ROHS3 Compliant | Non-compliant | Non-compliant | ROHS3 Compliant | ROHS3 Compliant |
Engineering Selection Recommendations
Active Product Alternatives: For new designs and ongoing production, Molex 0010897241, 3M 2324-6121-TG, and Preci-Dip 450-series variants (450-10-224-00-001101, 450-10-224-00-006101, 450-10-224-00-013101, 450-80-224-00-001101, 450-80-224-00-006101, 450-80-224-00-013101) are recommended as active product alternatives. These parts maintain full functional compatibility with the 67997-124 across all critical parameters.
RoHS Compliance Consideration: The original 67997-124 is RoHS non-compliant. Molex 0010897241 and all Preci-Dip 450-series variants are ROHS3 compliant, making them suitable for applications requiring regulatory compliance. The 3M 2324-6121-TG remains RoHS non-compliant.
Operating Temperature Range: The 67997-124 operates from -65°C to 130°C. The 3M 2324-6121-TG and TE Connectivity 4-103186-0-12 have reduced upper temperature limits (-55°C to 105°C), which may not be suitable for high-temperature applications. Molex 0010897241 and Preci-Dip variants operate to -55°C to 125°C, providing adequate coverage for most applications.
Product Status: TE Connectivity 4-103186-0-12 is obsolete. For long-term supply assurance, prioritize active products from Molex, 3M, and Preci-Dip.
Frequently Asked Questions (FAQ)
Q: Can the Molex 0010897241 be used as a direct replacement for the 67997-124?
A: Yes. Both parts share identical 24-position, 2-row configuration with 0.100" (2.54mm) pitch, through-hole solder termination, and push-pull fastening. The Molex part is active and ROHS3 compliant, making it a suitable substitute. Minor differences exist in contact length specifications and insulation material, but these do not affect functional compatibility in standard board-to-board applications.
Q: What is the difference between Preci-Dip 450-10 and 450-80 series variants?
A: The primary difference is contact finish. The 450-10 series features gold-plated contacts, while the 450-80 series features tin-plated contacts. Both series maintain identical pitch, position count, and electrical ratings. Selection depends on application requirements and solderability preferences.
Q: Are there differences in contact geometry among the substitute parts?
A: Yes. The 67997-124 features square contacts, while Preci-Dip 450-series variants feature circular contacts. Molex 0010897241 and 3M 2324-6121-TG maintain square contact geometry. Contact shape differences do not affect electrical performance or mating compatibility in standard applications.
Q: Which substitute part offers the best RoHS compliance and active product status?
A: Molex 0010897241 and all Preci-Dip 450-series variants are ROHS3 compliant and active products. These are recommended for new designs requiring regulatory compliance and long-term supply continuity.
Q: Does the 67997-124 have any cross-references to other Amphenol ICC parts?
A: The 67997-124 is part of the BERGSTIK® II series. The related part 67997-134HLF is a 34-position variant in the same series, but it is not a direct substitute due to the increased position count.
