Amphenol ICC 67000-003LF FFC Receptacle Housing - Equivalent & Substitute Parts
Part Overview
The Amphenol ICC 67000-003LF is a flat flexible connector (FFC) receptacle housing designed for 3-position, 0.100" (2.54mm) pitch applications. This component serves as the housing for female contacts in single-row configurations and is classified as part of the Duflex™ series. The part is currently active in production with full RoHS compliance and unlimited moisture sensitivity rating (MSL 1).
Substitute parts are identified to address inventory availability, regional sourcing requirements, or specific application constraints while maintaining electrical and mechanical compatibility within the defined parameter envelope.
Substiute Parts
Key Parameters
| Parameter | Specification |
|---|---|
| Manufacturer Part Number | 67000-003LF |
| Manufacturer | Amphenol ICC (FCI) |
| Category | FFC, FPC (Flat Flexible) Connectors |
| Connector Type | Housing for Female Contacts |
| Number of Positions | 3 |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 1 |
| Voltage Rating | 500 V |
| Current Rating | 3 A |
| Operating Temperature | -65°C ~ 125°C |
| Housing Material | Polyester Thermoplastic, Glass Filled |
| Housing Color | Black |
| Material Flammability Rating | UL94 V-0 |
| RoHS Status | RoHS Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Product Status | Active |
Substitute Part Grouping Explanation
Substitute parts for the 67000-003LF are qualified based on the following critical parameters that determine functional interchangeability:
Primary Compatibility Criteria:
- Number of Positions: 3
- Pitch: 0.100" (2.54mm)
- Number of Rows: 1
- Connector Type: Receptacle/Housing for Female Contacts
- Voltage Rating: 500 V minimum
- Current Rating: 3 A minimum
- Operating Temperature Range: Must encompass or exceed -65°C ~ 125°C
- Moisture Sensitivity Level: MSL 1 (Unlimited)
- RoHS Compliance: Required
Substitute Categories:
Category A - Molex KK254 Series (0010112033, 0010112034, 0022012037, 0022013037): Rectangular connector housings with 3-position, 2.54mm pitch configuration. These parts maintain the core electrical and mechanical specifications with variations in series designation and fastening features. Operating temperature range -40°C ~ 105°C is within acceptable limits for most applications, though does not extend to the full -65°C lower bound of the main part.
Category B - Molex SL 70066 Series (0050579203, 0050579403, 0050579503): Black polyester glass-filled receptacle housings with 3-position, 2.54mm pitch. These parts match the housing color and material composition of the main part. Operating temperature -40°C ~ 105°C and female socket contact type provide direct functional alignment.
Category C - TE Connectivity AMPMODU Mod IV Series (925369-3, 926475-3): Receptacle housings with 3-position, 2.54mm pitch and extended operating temperature range (-65°C ~ 105°C). Part 926475-3 features black polybutylene terephthalate (PBT) glass-filled housing, closely matching the main part's material and color profile.
Parameter Comparison
| Part Number | Manufacturer | Positions | Pitch (mm) | Rows | Voltage Rating (V) | Current Rating (A) | Operating Temp (°C) | Housing Material | Housing Color | RoHS Status | MSL |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 67000-003LF | Amphenol ICC | 3 | 2.54 | 1 | 500 | 3 | -65 ~ 125 | Polyester Thermoplastic, Glass Filled | Black | RoHS Compliant | 1 |
| 0010112033 | Molex | 3 | 2.54 | 1 | — | — | — | Polyamide (PA), Nylon | White | ROHS3 Compliant | 1 |
| 0010112034 | Molex | 3 | 2.54 | 1 | — | — | — | Polyamide (PA), Nylon | White | ROHS3 Compliant | 1 |
| 0022012037 | Molex | 3 | 2.54 | 1 | — | — | -40 ~ 105 | Polyamide (PA), Nylon | White | ROHS3 Compliant | 1 |
| 0022013037 | Molex | 3 | 2.54 | 1 | — | — | -40 ~ 105 | Polyamide (PA), Nylon | White | ROHS3 Compliant | 1 |
| 0050579203 | Molex | 3 | 2.54 | 1 | — | — | -40 ~ 105 | Polyester, Glass Filled | Black | ROHS3 Compliant | 1 |
| 0050579403 | Molex | 3 | 2.54 | 1 | — | — | -40 ~ 105 | Polyester, Glass Filled | Black | ROHS3 Compliant | 1 |
| 0050579503 | Molex | 3 | 2.54 | 1 | — | — | -40 ~ 105 | Polyester, Glass Filled | Black | ROHS3 Compliant | 1 |
| 925369-3 | TE Connectivity AMP | 3 | 2.54 | 1 | — | — | -65 ~ 105 | Polyamide (PA66), Nylon 6/6 | Green | RoHS Compliant | 1 |
| 926475-3 | TE Connectivity AMP | 3 | 2.54 | 1 | — | — | -65 ~ 105 | Polybutylene Terephthalate (PBT), Glass Filled | Black | ROHS3 Compliant | 1 |
Engineering Selection Recommendations
Primary Substitute (Best Match): Molex 0050579203 or 0050579503 are the closest functional equivalents. Both feature black polyester glass-filled housing matching the main part's material and color, 3-position 2.54mm pitch configuration, and ROHS3 compliance. Operating temperature range (-40°C ~ 105°C) covers standard industrial applications, though does not extend to the -65°C lower specification of the original part.
Extended Temperature Alternative: TE Connectivity 926475-3 provides operating temperature range of -65°C ~ 105°C, matching the lower temperature bound of the 67000-003LF. Black PBT glass-filled housing provides material compatibility for thermal and mechanical performance. ROHS3 compliance and MSL 1 rating maintain regulatory alignment.
Secondary Options: Molex 0022013037 includes polarizing key feature and ROHS3 compliance. Operating temperature -40°C ~ 105°C is suitable for standard commercial and industrial ranges. White nylon housing differs from the original black specification.
Compliance Status: All substitute parts maintain RoHS compliance (either RoHS Compliant or ROHS3 Compliant) and MSL 1 (Unlimited) moisture sensitivity rating, ensuring compatibility with standard manufacturing and storage protocols.
Frequently Asked Questions (FAQ)
Q: Can I substitute the 67000-003LF with any of these parts in applications requiring -65°C operation?
A: Only TE Connectivity 925369-3 and 926475-3 specify operating temperature range extending to -65°C. Molex parts (0010112033, 0010112034, 0022012037, 0022013037, 0050579203, 0050579403, 0050579503) are rated to -40°C minimum and are not suitable for applications requiring full -65°C lower temperature specification.
Q: What is the difference between Molex 0050579203, 0050579403, and 0050579503?
A: All three are SL 70066 series black polyester glass-filled receptacles with 3-position 2.54mm pitch. The primary difference is fastening type: 0050579203 has no specified fastening feature, 0050579403 includes Latch Lock fastening, and 0050579503 includes Locking Ramp fastening. Electrical and mechanical specifications are otherwise identical.
Q: Does housing color affect electrical performance?
A: Housing color (black, white, or green) is a cosmetic and identification parameter. It does not affect electrical performance, voltage rating, current capacity, or temperature rating. Color selection is driven by application requirements, PCB assembly standards, or visual identification needs.
Q: Are all substitute parts RoHS compliant?
A: Yes. All listed substitute parts carry either RoHS Compliant or ROHS3 Compliant certification, meeting EU Directive 2011/65/EU requirements. This ensures compatibility with RoHS-regulated supply chains and end-use applications.
Q: What does MSL 1 (Unlimited) mean for these connectors?
A: MSL 1 indicates the component has unlimited shelf life under standard storage conditions (per IPC-A-113). No special moisture-controlled storage or baking procedures are required prior to assembly, simplifying inventory management and reducing handling costs.
Q: Can I use these parts interchangeably on the same PCB?
A: Mechanical and electrical interchangeability is confirmed for all parts within the 3-position, 2.54mm pitch, single-row receptacle category. However, physical dimensions, mounting footprint, and contact alignment must be verified against your specific PCB design. Consult manufacturer datasheets for detailed mechanical drawings before finalizing board layout.
Q: Which substitute offers the best material match to the original 67000-003LF?
A: Molex 0050579203, 0050579403, and 0050579503 feature polyester glass-filled housing, matching the material composition of the original part. TE Connectivity 926475-3 uses PBT (polybutylene terephthalate) glass-filled material, which provides similar thermal and mechanical properties but is a different polymer base.
