Amphenol ICC 65863-371 Equivalent & Substitute Parts

Part Overview

The Amphenol ICC 65863-371 is an active rectangular connector header designed for through-hole mounting applications. This shrouded 10-position connector with 2.54mm pitch serves board-to-cable/wire interconnection requirements in electronic assemblies. The part is manufactured in the Quickie™ series and features solder termination with latch lock/eject hook fastening. Finding equivalent substitute parts may be necessary due to inventory constraints, supply chain considerations, or specific application requirements that align with alternative connector designs meeting identical electrical and mechanical specifications.

Substiute Parts

65863-371

Amphenol ICC (FCI)In Stock: 93465863-371 Datasheet

Current PartRFQ

102321-1

TE Connectivity AMP ConnectorsIn Stock: 1074102321-1 Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitute parts for the Amphenol ICC 65863-371 are identified based on strict electrical and mechanical parameter alignment. The primary substitution criteria include:

• Connector type (Header)
• Contact type (Male Pin)
• Position count (10 positions in 2 rows)
• Mating pitch (0.100" / 2.54mm)
• Row spacing (0.100" / 2.54mm)
• Mounting method (Through Hole)
• Shrouding configuration (Shrouded - 4 Wall)
• Termination method (Solder)
• Fastening mechanism (Latch Lock/Eject Hooks)
• Contact shape (Square)
• Mating contact finish (Gold or equivalent)
• Flammability rating (UL94 V-0)

The TE Connectivity AMP Connectors 102321-1 meets all critical substitution parameters and is classified as a manufacturer-recommended equivalent.

Parameter Comparison

Engineering Selection Recommendations

Both the Amphenol ICC 65863-371 and TE Connectivity 102321-1 are active products with identical core electrical and mechanical specifications. Selection between these parts should be based on:

• Inventory availability and lead time requirements
• Compliance certifications applicable to the end application
• Specific operating environment parameters (temperature, voltage, current) if the application requires the electrical ratings provided by the TE Connectivity substitute
• PCB layout constraints, as the TE Connectivity 102321-1 includes a mounting flange feature not present in the Amphenol ICC part
• Contact finish requirements; the TE Connectivity part specifies Gold-Palladium as an alternative to pure gold

Both parts carry identical RoHS non-compliance status and ECCN/HTSUS classifications, ensuring regulatory consistency in supply chain applications.

Frequently Asked Questions (FAQ)

Q: Can the TE Connectivity 102321-1 be used as a direct replacement for the Amphenol ICC 65863-371?

A: Yes. Both connectors share identical mating pitch (2.54mm), position count (10 positions, 2 rows), mounting type (through hole), shrouding configuration (4-wall shrouded), termination method (solder), and fastening mechanism (latch lock/eject hooks). The core electrical and mechanical interfaces are equivalent.

Q: What are the differences between these two connector models?

A: The primary differences are: (1) The TE Connectivity part specifies operating temperature range (-65°C to 105°C) and electrical ratings (1A per contact, 250VAC), while the Amphenol ICC part does not provide these specifications; (2) The TE Connectivity part includes a mounting flange feature; (3) Contact finish specifications differ slightly (Gold-Palladium vs. GXT™ gold); (4) Insulation color differs (Black vs. Blue); (5) Contact length dimensions vary slightly between the two designs.

Q: Are there any compatibility concerns with PCB footprints?

A: The mating pitch and row spacing are identical (0.100" / 2.54mm), ensuring PCB footprint compatibility. However, the TE Connectivity 102321-1 includes a mounting flange that may affect board layout. Verify mounting hole placement and clearance requirements for your specific PCB design.

Q: Do both parts meet the same compliance standards?

A: Both parts carry UL94 V-0 flammability ratings, identical RoHS non-compliance status, and the same ECCN (EAR99) and HTSUS (8536.69.4040) classifications. Both are classified as MSL 1 (Unlimited moisture sensitivity level).

Q: Which part should be selected for high-temperature applications?

A: The TE Connectivity 102321-1 provides an explicit operating temperature range of -65°C to 105°C. If your application requires temperature specifications, this part is the appropriate choice. The Amphenol ICC 65863-371 does not specify operating temperature limits.
