TE Connectivity AMP Connectors 646956-1 Equivalent & Substitute Parts

Part Overview

The TE Connectivity AMP Connectors 646956-1 is a 6-position backplane connector header with male blades, designed for board edge mounting with through-hole, right-angle termination. This connector is part of the UPM (Universal Power Modules) series and is classified as a blade power connector with press-fit termination. The part is currently active in production with 957 pieces available in new original stock.

Identification of equivalent and substitute parts becomes necessary when the primary part number is unavailable, when compliance requirements change, or when design revisions require updated component specifications. Substitute parts must maintain electrical and mechanical compatibility while meeting the same functional requirements.

Substiute Parts

646956-1

TE Connectivity AMP ConnectorsIn Stock: 1064646956-1 Datasheet

Current PartRFQ

5646956-1

TE Connectivity AMP ConnectorsIn Stock: 10365646956-1 Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution between the main part 646956-1 and the equivalent part 5646956-1 is based on strict alignment of the following critical parameters:

Electrical Compatibility Parameters:

• Connector type: Header, Male Blades
• Number of positions: 6
• Connector style: Blade Power
• Voltage rating: 250V
• Operating temperature range: -55°C ~ 125°C
• Contact finish: Gold or Gold-Palladium
• Material flammability rating: UL94 V-0

Mechanical Compatibility Parameters:

• Mounting type: Board Edge, Through Hole, Right Angle
• Termination type: Press-Fit
• Contact layout: 6 Power
• Color: Gray
• Moisture sensitivity level: 1 (Unlimited)

Series Designation:

• Both parts belong to the UPM (Universal Power Modules) series

The substitute part 5646956-1 maintains full electrical and mechanical compatibility with the main part 646956-1 across all specified parameters. Both parts are manufactured by TE Connectivity AMP Connectors and are classified as active products.

Parameter Comparison

Engineering Selection Recommendations

Primary Selection Criteria:

The substitute part 5646956-1 is electrically and mechanically equivalent to the main part 646956-1 across all specified connector parameters. Both parts maintain identical electrical ratings, mechanical mounting configurations, and thermal operating ranges.

Compliance Considerations:

The substitute part 5646956-1 offers improved regulatory compliance status compared to the main part 646956-1. The substitute part is ROHS3 compliant and REACH unaffected, whereas the main part is RoHS non-compliant and REACH affected. For applications subject to RoHS3 or REACH regulatory requirements, the substitute part 5646956-1 is the appropriate selection.

Current Rating:

The main part 646956-1 specifies a current rating of 10A. The substitute part 5646956-1 does not provide a specified current rating in the available documentation. For applications where the 10A current rating is a critical design parameter, the main part 646956-1 should be selected if this specification is required.

Inventory Availability:

Both parts are active products with current stock availability. The main part 646956-1 has 957 pieces in stock, while the substitute part 5646956-1 has 941 pieces in stock.

Frequently Asked Questions (FAQ)

Q: Can 5646956-1 be used as a direct replacement for 646956-1 in existing designs?

A: Yes. The substitute part 5646956-1 maintains full electrical and mechanical compatibility with 646956-1. Both parts share identical connector type, position count, mounting configuration, voltage rating, temperature range, and contact finish specifications. The parts are interchangeable from a functional standpoint.

Q: What is the primary difference between these two part numbers?

A: The primary differences are regulatory compliance status and current rating specification. The substitute part 5646956-1 is ROHS3 compliant and REACH unaffected, while the main part 646956-1 is RoHS non-compliant and REACH affected. The main part specifies a 10A current rating, while the substitute part does not provide this specification in available documentation.

Q: Should I select 5646956-1 if my application requires RoHS3 compliance?

A: Yes. If your application or end market requires RoHS3 compliance, the substitute part 5646956-1 is the appropriate selection. This part carries ROHS3 compliant status, whereas the main part 646956-1 is RoHS non-compliant.

Q: Are both parts available in the same packaging format?

A: Yes. Both the main part 646956-1 and substitute part 5646956-1 are packaged in tubes, maintaining identical packaging specifications.

Q: What is the operating temperature range for both parts?

A: Both parts operate across the identical temperature range of -55°C to 125°C, ensuring thermal compatibility in equivalent applications.

Q: Do both parts have the same moisture sensitivity level?

A: Yes. Both parts carry a Moisture Sensitivity Level (MSL) of 1 (Unlimited), indicating no moisture sensitivity restrictions for either part.

Q: Are both parts manufactured by the same company?

A: Yes. Both the main part 646956-1 and substitute part 5646956-1 are manufactured by TE Connectivity AMP Connectors and belong to the UPM (Universal Power Modules) series.

Q: What is the voltage rating for these connectors?

A: Both parts are rated for 250V, providing identical voltage specifications for equivalent applications.

Q: Can these parts be used in backplane applications?

A: Yes. Both parts are classified as backplane connectors and are designed for board edge mounting with through-hole, right-angle termination in backplane applications.
