3M 62-SN Terminal Butt Splice Equivalent & Substitute Parts

Part Overview

The 3M 62-SN is an active-status terminal butt splice connector designed for inline wire splicing applications. This fully insulated crimp terminal accommodates 14-16 AWG wire gauges with individual openings for dual wire entries. The component is RoHS Compliant and carries MSL 1 (Unlimited) moisture sensitivity rating, making it suitable for general industrial and commercial electrical assemblies. Substitute parts are identified based on matching electrical specifications, mechanical compatibility, and functional equivalence within the terminal connector category.

Substiute Parts

62-SN

3MIn Stock: 120162-SN Datasheet

Current PartRFQ

BSN14-C

Panduit CorpIn Stock: 911BSN14-C Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitute parts for the 3M 62-SN are qualified based on the following critical parameters that determine functional interchangeability:

• Terminal Type: Butt Splice, Inline, Individual Openings
• Wire Gauge Range: 14-16 AWG
• Number of Wire Entries: 2
• Termination Method: Crimp
• Insulation Classification: Fully Insulated
• Color: Blue

The Panduit Corp BSN14-C meets all specified electrical and mechanical parameters required for direct substitution in applications requiring 14-16 AWG butt splice connectors with crimp termination and full insulation.

Parameter Comparison

Engineering Selection Recommendations

Both the 3M 62-SN and Panduit BSN14-C are active-status components with matching electrical and mechanical specifications. The 3M 62-SN carries RoHS Compliant certification with MSL 1 (Unlimited) rating. The Panduit BSN14-C carries ROHS3 Compliant certification and includes REACH Unaffected status. Both components share identical ECCN and HTSUS classifications, confirming regulatory alignment for export and tariff purposes. Selection between these parts should be based on supply availability, lead time requirements, and organizational procurement preferences, as both meet the specified functional and compliance criteria for 14-16 AWG butt splice applications.

Frequently Asked Questions (FAQ)

Q: Can the Panduit BSN14-C replace the 3M 62-SN in existing designs?

A: Yes. Both parts are functionally equivalent for 14-16 AWG butt splice applications. They share identical terminal type, wire gauge, number of wire entries, termination method, insulation classification, and color specification.

Q: What wire gauges are supported by these butt splice terminals?

A: Both the 3M 62-SN and Panduit BSN14-C support 14-16 AWG wire gauges. Verify wire gauge compatibility before installation.

Q: Are these terminals suitable for moisture-sensitive environments?

A: The 3M 62-SN carries MSL 1 (Unlimited) rating, indicating no moisture sensitivity restrictions. The Panduit BSN14-C lists MSL as Not Applicable. Both are suitable for general industrial applications without moisture-related constraints.

Q: What is the difference between RoHS Compliant and ROHS3 Compliant?

A: Both certifications indicate compliance with Restriction of Hazardous Substances directives. ROHS3 represents the current iteration of the standard. Both parts meet hazardous substance restrictions for their respective certification levels.

Q: Are these terminals available in bulk packaging?

A: Yes. Both the 3M 62-SN and Panduit BSN14-C are supplied in bulk packaging format.

Q: What termination method do these terminals require?

A: Both terminals use crimp termination. Ensure appropriate crimping tools and techniques are used for proper installation.
