TE Connectivity AMP Connectors 62298-2 Equivalent & Substitute Parts

Part Overview

The TE Connectivity AMP Connectors 62298-2 is a 0.187" (4.75mm) Quick Connect Male Screw, Rivet, Stud Connector classified as a non-insulated terminal within the Faston series. This component is designed for board and chassis mounting applications requiring secure electrical connections through screw, rivet, or stud termination methods. The part is currently listed as obsolete, necessitating identification of active equivalent alternatives to maintain supply chain continuity and support ongoing production requirements.

Substiute Parts

62298-2

TE Connectivity AMP ConnectorsIn Stock: 98562298-2 Datasheet

Current PartRFQ

60920-5

TE Connectivity AMP ConnectorsIn Stock: 585460920-5 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the 62298-2 terminal is determined by strict alignment of critical electrical and mechanical parameters. The following parameters must match or be compatible for a substitute part to function within the same application:

Critical Matching Parameters:

• Tab Width: 0.187" (4.75mm) - determines connector interface compatibility
• Gender: Male - establishes mating orientation
• Termination Method: Screw, Rivet, Stud - ensures compatible attachment mechanisms
• Mounting Type: Board, Chassis - confirms installation compatibility
• Features: 2 Tabs - maintains structural and electrical configuration
• Insulation: Non-Insulated - preserves electrical characteristics
• Overall Length: 1.276" (32.40mm) - ensures spatial fit within assemblies

Allowable Variation Parameters:

• Tab Thickness: Variation permitted within mechanical tolerance ranges
• Contact Material: Substitution allowed between compatible conductive materials
• Contact Finish: Tin finish maintained across alternatives

The substitute part 60920-5 satisfies all critical matching parameters while presenting variation in tab thickness (0.020" versus 0.032") and contact material (brass versus steel), both of which fall within acceptable substitution criteria for this terminal category.

Parameter Comparison

Engineering Selection Recommendations

Primary Substitute: TE Connectivity AMP Connectors 60920-5

The 60920-5 terminal is the qualified substitute for the obsolete 62298-2. Selection of this alternative is based on the following engineering criteria:

Product Status Alignment: The 60920-5 maintains active product status within the TE Connectivity AMP Connectors portfolio, ensuring continued availability and supply chain support. The 62298-2 obsolete status necessitates transition to an active equivalent.

Compliance Certification: Both parts maintain equivalent regulatory compliance. The 62298-2 carries ROHS3 Compliant certification, while the 60920-5 carries RoHS Compliant certification. Both parts are classified under ECCN EAR99 and share identical HTSUS code 8536.90.4000, confirming regulatory alignment.

Electrical and Mechanical Compatibility: The substitute part maintains all critical interface parameters including tab width (0.187"), gender (male), termination method (screw, rivet, stud), mounting type (board, chassis), and overall length (1.276"). The two-tab configuration and non-insulated design are preserved.

Material and Dimensional Variations: The 60920-5 presents a reduced tab thickness (0.020" versus 0.032") and brass contact material (versus steel). These variations fall within acceptable substitution parameters for Faston series quick-connect terminals and do not compromise functional compatibility.

Inventory Availability: The 60920-5 demonstrates robust inventory availability (5,774 pieces in stock) compared to the 62298-2 (905 pieces), supporting immediate procurement and production continuity.

Frequently Asked Questions (FAQ)

Q: Can the 60920-5 directly replace the 62298-2 in existing assemblies?

A: The 60920-5 is functionally compatible with the 62298-2 across all critical interface parameters. Both terminals share identical tab width (0.187"), gender (male), termination method (screw, rivet, stud), mounting type (board, chassis), and overall length (1.276"). The substitute maintains the two-tab configuration and non-insulated design required for the application.

Q: What is the significance of the tab thickness difference between these parts?

A: The 62298-2 features 0.032" (0.81mm) tab thickness, while the 60920-5 features 0.020" (0.51mm) tab thickness. This variation is within acceptable mechanical tolerance ranges for Faston series quick-connect terminals and does not affect connector interface compatibility or electrical performance.

Q: How does the contact material difference impact substitution?

A: The 62298-2 uses steel contact material, while the 60920-5 uses brass contact material. Both materials are compatible with tin finish plating and maintain equivalent electrical conductivity and corrosion resistance characteristics required for board and chassis mounting applications.

Q: Are there compliance or regulatory differences between these parts?

A: Both parts maintain equivalent regulatory compliance. The 62298-2 carries ROHS3 Compliant certification, while the 60920-5 carries RoHS Compliant certification. Both parts share identical ECCN (EAR99) and HTSUS code (8536.90.4000) classifications. Moisture Sensitivity Level (MSL) is identical at 1 (Unlimited) for both parts.

Q: What packaging options are available for the substitute part?

A: The 60920-5 is supplied in bulk packaging, providing flexibility for production requirements. The original 62298-2 packaging specification was not defined in the component documentation.

Q: Why is the 60920-5 recommended over the 62298-2?

A: The 62298-2 is classified as obsolete, indicating discontinued production and limited future availability. The 60920-5 maintains active product status within the TE Connectivity AMP Connectors portfolio, ensuring continued supply chain support and long-term component availability for production and maintenance applications.
