TE Connectivity AMP Connectors 536513-4 Equivalent & Substitute Parts

Part Overview

The TE Connectivity AMP Connectors 536513-4 is a 192-position Futurebus header connector with male pins designed for through-hole PCB mounting. This backplane connector is part of the Z-PACK series and features a 0.079" (2.00mm) pitch configuration across 4 rows with gold-plated contacts. The connector is rated for 30V operation across an extended temperature range of -55°C to 125°C and carries a UL94 V-0 flammability rating. The part is currently active in production with 1153 units in stock. Equivalent and substitute parts are identified to provide procurement flexibility, accommodate supply chain variations, and address specific compliance requirements such as RoHS status.

Substiute Parts

536513-4

TE Connectivity AMP ConnectorsIn Stock: 1197536513-4 Datasheet

Current PartRFQ

5536513-4

TE Connectivity AMP ConnectorsIn Stock: 9225536513-4 Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the TE Connectivity 536513-4 is determined by strict equivalence across all critical electrical and mechanical parameters. The substitute part 5536513-4 maintains identical specifications for connector type, style, position count, pitch, row configuration, mounting method, termination type, contact finish, voltage rating, operating temperature range, and flammability rating. Both parts are classified as Futurebus backplane connectors with 192 positions at 2.00mm pitch, through-hole solder termination, and gold-plated contacts rated for 30V operation.

The primary distinction between the main part and its substitute is packaging format and regulatory compliance status. The 536513-4 is supplied in standard packaging with RoHS non-compliant status, while the 5536513-4 is packaged in tube format and carries ROHS3 compliance certification. Both parts share identical electrical performance characteristics and mechanical compatibility, making them functionally interchangeable within the same PCB assembly design.

Parameter Comparison

Engineering Selection Recommendations

Selection between the 536513-4 and 5536513-4 is determined by regulatory and compliance requirements applicable to the end application.

536513-4 Selection Criteria: This part is appropriate for applications where RoHS compliance is not mandated or where legacy system designs do not require ROHS3 certification. The standard packaging format supports conventional procurement workflows. This part maintains active production status with higher inventory availability at 1153 units.

5536513-4 Selection Criteria: This part is required for applications subject to RoHS3 compliance mandates, including European Union directives and equivalent international regulations. The tube packaging format provides alternative handling and storage options. This part carries ROHS3 compliant certification and maintains active production status with 823 units in inventory.

Both parts are electrically and mechanically identical across all functional parameters. The selection decision is based solely on compliance certification requirements and packaging format preferences, not on performance or reliability characteristics.

Frequently Asked Questions (FAQ)

Q: Are the 536513-4 and 5536513-4 electrically interchangeable?

A: Yes. Both parts are identical in electrical specifications, including voltage rating (30V), operating temperature range (-55°C to 125°C), contact finish (gold), and all other electrical parameters. They can be used interchangeably in circuit designs without modification.

Q: What is the primary difference between these two parts?

A: The primary differences are packaging format and RoHS compliance status. The 536513-4 uses standard packaging and is RoHS non-compliant. The 5536513-4 uses tube packaging and carries ROHS3 compliance certification. All mechanical and electrical specifications are identical.

Q: Can I substitute 5536513-4 for 536513-4 in an existing design?

A: Yes, the 5536513-4 is a direct substitute for 536513-4. The parts are mechanically and electrically identical. Substitution is appropriate when RoHS3 compliance is required or when tube packaging is preferred.

Q: Can I substitute 536513-4 for 5536513-4 in an existing design?

A: Substitution of 536513-4 for 5536513-4 is only appropriate if RoHS3 compliance is not required by the application or regulatory environment. The parts are mechanically and electrically identical, but compliance certification differs.

Q: What does the packaging difference mean for procurement?

A: The 536513-4 is supplied in standard packaging, while the 5536513-4 is supplied in tube packaging. Tube packaging may affect handling, storage, and automated assembly processes. Verify packaging compatibility with your assembly and logistics requirements.

Q: Are both parts currently available?

A: Yes, both parts are active in production. The 536513-4 has 1153 units in inventory, and the 5536513-4 has 823 units in inventory.

Q: What does UL94 V-0 flammability rating mean?

A: UL94 V-0 is a material flammability classification indicating that the connector base material meets the highest flame-resistance standard. Both parts carry this certification.

Q: What is Moisture Sensitivity Level 1?

A: MSL 1 (Unlimited) indicates that the connector has unlimited shelf life and does not require special moisture-controlled storage or handling procedures. Both parts carry this classification.
