TE Connectivity AMP Connectors 499374-5 Equivalent & Substitute Parts

Part Overview

The TE Connectivity AMP Connectors 499374-5 is a rectangular connector header designed for through-hole mounting applications. This shrouded 24-position connector operates at 0.100" (2.54mm) pitch and supports board-to-cable/wire interconnections with solder termination. The connector is classified as Active product status and features latch lock/eject hook fastening with keying slot and mounting flange.

Substitute parts are identified when equivalent electrical and mechanical parameters align with the original specification, enabling direct functional replacement in circuit board designs without redesign requirements.

Substiute Parts

499374-5

TE Connectivity AMP ConnectorsIn Stock: 1035499374-5 Datasheet

Current PartRFQ

5499374-5

TE Connectivity AMP ConnectorsIn Stock: 12395499374-5 Datasheet

DirectRFQ

N3627-6202RB

3MIn Stock: 919N3627-6202RB Datasheet

SimilarRFQ

N3627-6203RB

3MIn Stock: 902N3627-6203RB Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for rectangular connector headers is determined by alignment of critical electrical and mechanical parameters. The following parameters establish substitution validity:

Primary Substitution Criteria:

• Connector type (Header)
• Contact type (Male Pin)
• Number of positions (24)
• Number of rows (2)
• Pitch - mating (0.100" / 2.54mm)
• Row spacing - mating (0.100" / 2.54mm)
• Mounting type (Through Hole)
• Termination method (Solder)
• Shrouding configuration (Shrouded - 4 Wall)
• Fastening type (Latch Lock/Eject Hooks, Short)
• Contact shape (Square)
• Material flammability rating (UL94 V-0)
• Insulation color (Black)
• Features (Keying Slot, Mounting Flange)

Secondary Compatibility Parameters:

• Operating temperature range (minimum -55°C to maximum 105°C acceptable)
• Current rating (minimum 1A per contact acceptable)
• Contact finish - mating (Gold or Gold-Palladium acceptable)
• Contact finish thickness - mating (30.0µin / 0.76µm acceptable)

Dimensional Tolerance Parameters:

• Contact length - mating (0.240" / 6.10mm)
• Contact length - post (0.155" / 3.94mm acceptable with minor variation)
• Overall contact length (within 0.684" / 17.37mm range)
• Insulation height (within specified range)

Parts meeting all primary criteria and secondary compatibility parameters are classified as direct substitutes.

Parameter Comparison

Engineering Selection Recommendations

5499374-5 (TE Connectivity AMP Connectors)

This part is a direct substitute for 499374-5. Both parts share identical electrical and mechanical specifications, including connector type, position count, pitch, mounting configuration, and fastening mechanism. The primary distinction is packaging format (Tray versus unspecified) and compliance status. Part 5499374-5 achieves ROHS3 compliance and REACH unaffected status, whereas the original 499374-5 is RoHS non-compliant and REACH affected. Selection of 5499374-5 is appropriate for applications requiring regulatory compliance with modern environmental standards.

N3627-6203RB (3M 3000 Series)

This part qualifies as a substitute based on matching primary substitution criteria. The connector maintains identical position count, pitch, row spacing, mounting type, termination method, shrouding, fastening type, contact shape, and flammability rating. Dimensional alignment includes matching contact length for mating (0.240" / 6.10mm) and post (0.155" / 3.94mm), with overall contact length within acceptable tolerance (0.695" / 17.65mm versus 0.684" / 17.37mm). The 3M part provides higher current rating (1.75A versus 1A per contact) and RoHS compliance. Operating temperature range is -55°C to 105°C, which covers the upper specification of the original part. Voltage rating is not specified for this part. Contact finish post thickness is increased to 200.0µin (5.08µm) compared to 100.0µin (2.54µm) on the original.

N3627-6202RB (3M 3000 Series)

This part meets primary substitution criteria with identical position count, pitch, row spacing, mounting type, termination, shrouding, fastening type, contact shape, and flammability rating. However, contact length for post differs significantly at 0.112" (2.84mm) compared to 0.155" (3.94mm) on the original part. Overall contact length is 0.652" (16.56mm) versus 0.684" (17.37mm), representing a dimensional deviation. Insulation height is 0.680" (17.27mm) compared to 0.549" (13.94mm). These dimensional differences may affect board-level fit and mating interface compatibility. Current rating is 1.75A per contact, exceeding the original specification. RoHS compliance and REACH unaffected status are achieved. This part is suitable only when dimensional variations are accommodated by circuit board design.
