TE Connectivity 4-146257-6 Equivalent & Substitute Parts

Part Overview

The TE Connectivity 4-146257-6 is a rectangular connector header manufactured under the AMPMODU Mod II series. This through-hole vertical mount connector features 14 positions arranged in 2 rows with 0.100" (2.54mm) pitch spacing. The part is classified as obsolete, necessitating identification of active equivalent and substitute components for ongoing design requirements and production continuity.

Key Parameters

Parameter	Value
Manufacturer Part Number	4-146257-6
Manufacturer	TE Connectivity AMP Connectors
Category	Rectangular Connectors
Series	AMPMODU Mod II
Product Status	Obsolete
Connector Type	Header, Breakaway
Contact Type	Male Pin
Number of Positions	14
Number of Rows	2
Pitch - Mating	0.100" (2.54mm)
Row Spacing - Mating	0.100" (2.54mm)
Mounting Type	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Finish - Post	Tin-Lead
Insulation Material	Liquid Crystal Polymer (LCP)
Operating Temperature	-65°C ~ 105°C
Current Rating	3A
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Moisture Sensitivity Level	1 (Unlimited)

Substitute Part Grouping Explanation

Substitution of the obsolete 4-146257-6 is determined by strict equivalence across the following critical parameters:

Primary Matching Criteria:

Number of Positions: 14
Number of Rows: 2
Pitch - Mating: 0.100" (2.54mm)
Row Spacing - Mating: 0.100" (2.54mm)
Connector Type: Header, Breakaway
Contact Type: Male Pin
Mounting Type: Through Hole
Termination: Solder
Fastening Type: Push-Pull
Insulation Material: Liquid Crystal Polymer (LCP)
Material Flammability Rating: UL94 V-0

Secondary Compatibility Parameters:

Contact Finish - Mating: Gold or Tin (both acceptable)
Contact Finish - Post: Tin or Tin-Lead (both acceptable)
Operating Temperature Range: -65°C ~ 105°C or unspecified
RoHS Compliance: RoHS3 Compliant or RoHS Compliant
Moisture Sensitivity Level: 1 (Unlimited)

Substitute parts are grouped into two categories: the direct manufacturer upgrade from TE Connectivity (5-146257-7) and functionally equivalent alternatives from Molex (C-Grid 70280 and C-Grid 70287 series). All substitutes maintain identical mating pitch, position count, and row configuration. Variations in contact length dimensions and post termination methods are noted where they differ from the original specification.

Parameter Comparison

Parameter	4-146257-6	5-146257-7	0010897140	0010897141	0010897142	0702800595	0702800635	0702800675	0702871005	0702871103	0702871201
Manufacturer	TE Connectivity	TE Connectivity	Molex	Molex	Molex	Molex	Molex	Molex	Molex	Molex	Molex
Series	AMPMODU Mod II	AMPMODU Mod II	C-Grid 70280	C-Grid 70280	C-Grid 70280	C-Grid 70280	C-Grid 70280	C-Grid 70280	C-Grid 70287	C-Grid 70287	C-Grid 70287
Product Status	Obsolete	Active	Active	Active	Active	Active	Active	Active	Active	Active	Active
Number of Positions	14	14	14	14	14	14	14	14	14	14	14
Number of Rows	2	2	2	2	2	2	2	2	2	2	2
Pitch - Mating	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)
Row Spacing - Mating	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)
Mounting Type	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole
Termination	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Kinked Pin, Solder	Kinked Pin, Solder	Kinked Pin, Solder
Fastening Type	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull
Contact Type	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin
Contact Length - Mating	0.230" (5.84mm)	0.230" (5.84mm)	0.240" (6.10mm)	0.240" (6.10mm)	0.240" (6.10mm)	0.240" (6.10mm)	0.240" (6.10mm)	0.240" (6.10mm)	0.240" (6.10mm)	0.240" (6.10mm)	0.240" (6.10mm)
Contact Length - Post	0.120" (3.05mm)	0.120" (3.05mm)	0.107" (2.71mm)	0.107" (2.71mm)	0.107" (2.71mm)	0.175" (4.45mm)	0.175" (4.45mm)	0.175" (4.45mm)	0.125" (3.18mm)	0.125" (3.18mm)	0.125" (3.18mm)
Overall Contact Length	0.440" (11.18mm)	0.440" (11.18mm)	0.437" (11.10mm)	0.437" (11.10mm)	0.437" (11.10mm)	0.505" (12.83mm)	0.505" (12.83mm)	0.505" (12.83mm)	0.455" (11.56mm)	0.455" (11.56mm)	0.455" (11.56mm)
Insulation Height	0.090" (2.29mm)	0.090" (2.29mm)	0.090" (2.29mm)	0.090" (2.29mm)	0.090" (2.29mm)	0.090" (2.29mm)	0.090" (2.29mm)	0.090" (2.29mm)	0.090" (2.29mm)	0.090" (2.29mm)	0.090" (2.29mm)
Contact Shape	Square	Square	Square	Square	Square	Square	Square	Square	Square	Square	Square
Contact Finish - Mating	Gold	Gold	Gold	Tin	Gold	Tin	Gold	Gold	Tin	Gold	Gold
Contact Finish Thickness - Mating	30.0µin (0.76µm)	30.0µin (0.76µm)	30.0µin (0.76µm)	150.0µin (3.81µm)	15.0µin (0.38µm)	150.0µin (3.81µm)	15.0µin (0.38µm)	30.0µin (0.76µm)	150.0µin (3.81µm)	15.0µin (0.38µm)	30.0µin (0.76µm)
Contact Finish - Post	Tin-Lead	Tin	Tin	Tin	Tin	Tin	Tin	Tin	Tin	Tin	Tin
Contact Material	Copper Alloy	Copper Alloy	Copper Alloy	Copper Alloy	Copper Alloy	Copper Alloy	Copper Alloy	Copper Alloy	Copper Alloy	Copper Alloy	Copper Alloy
Insulation Material	Liquid Crystal Polymer (LCP)	Liquid Crystal Polymer (LCP)	Liquid Crystal Polymer (LCP), Glass Filled	Liquid Crystal Polymer (LCP), Glass Filled	Liquid Crystal Polymer (LCP), Glass Filled	Liquid Crystal Polymer (LCP), Glass Filled	Liquid Crystal Polymer (LCP), Glass Filled	Liquid Crystal Polymer (LCP), Glass Filled	Liquid Crystal Polymer (LCP), Glass Filled	Liquid Crystal Polymer (LCP), Glass Filled	Liquid Crystal Polymer (LCP), Glass Filled
Material Flammability Rating	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0
Insulation Color	Black	Black	Black	Black	Black	Black	Black	Black	Black	Black	Black
Current Rating	3A	3A	Not specified	Not specified	Not specified	Not specified	Not specified	Not specified	Not specified	Not specified	Not specified
Operating Temperature	-65°C ~ 105°C	-65°C ~ 105°C	Not specified	Not specified	Not specified	Not specified	Not specified	Not specified	Not specified	Not specified	Not specified
RoHS Status	RoHS Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant
Moisture Sensitivity Level	1 (Unlimited)	1 (Unlimited)	1 (Unlimited)	1 (Unlimited)	1 (Unlimited)	1 (Unlimited)	1 (Unlimited)	1 (Unlimited)	1 (Unlimited)	1 (Unlimited)	1 (Unlimited)

Engineering Selection Recommendations

Primary Recommendation: TE Connectivity 5-146257-7

The 5-146257-7 is the direct active equivalent from the original manufacturer TE Connectivity. This part maintains identical electrical and mechanical specifications to the obsolete 4-146257-6, including contact length dimensions, pitch spacing, and row configuration. The primary difference is the contact finish on the post, which changes from Tin-Lead to Tin. This change aligns with RoHS3 compliance requirements and represents standard industry practice for lead-free manufacturing. The 5-146257-7 is classified as Active with 5155 units in stock, ensuring supply continuity.

Secondary Recommendations: Molex C-Grid 70280 Series

The Molex C-Grid 70280 series (part numbers 0010897140, 0010897141, 0010897142, 0702800595, 0702800635, 0702800675) provides functionally equivalent alternatives. These parts maintain identical mating pitch, position count, row spacing, and fastening characteristics. Variations exist in contact length dimensions and contact finish specifications. The 0010897140 and 0010897142 variants with gold mating finish provide closest alignment to the original specification. All C-Grid 70280 parts are ROHS3 Compliant with MSL 1 rating and are classified as Active.

Tertiary Recommendations: Molex C-Grid 70287 Series

The Molex C-Grid 70287 series (part numbers 0702871005, 0702871103, 0702871201) offers substitution with kinked pin termination in addition to solder termination. These parts maintain identical mating pitch and position configuration but feature different contact post lengths (0.125" versus 0.120" in the original). The 0702871103 and 0702871201 variants with gold mating finish provide closest alignment to the original specification. All C-Grid 70287 parts are ROHS3 Compliant with MSL 1 rating and are classified as Active.

Compliance Considerations

All recommended substitutes are ROHS3 Compliant, meeting current regulatory requirements. The transition from Tin-Lead to Tin post finish in the 5-146257-7 reflects mandatory lead-free manufacturing standards. All substitute parts maintain UL94 V-0 flammability rating and Moisture Sensitivity Level 1 classification, ensuring compatibility with existing design requirements.

Frequently Asked Questions (FAQ)

Q: Can the 5-146257-7 directly replace the obsolete 4-146257-6 without PCB modifications?

A: Yes. The 5-146257-7 maintains identical mating pitch (0.100"), position count (14), row spacing (0.100"), and mounting type (through hole). Contact length dimensions are identical. The only material change is the post finish from Tin-Lead to Tin, which does not affect mechanical fit or electrical performance in standard solder joint applications.

Q: What is the difference between the TE Connectivity 5-146257-7 and the Molex C-Grid 70280 alternatives?

A: The 5-146257-7 is the direct manufacturer upgrade from TE Connectivity with identical contact length specifications. Molex C-Grid 70280 parts feature slightly longer mating contact length (0.240" versus 0.230") and shorter post length (0.107" versus 0.120"). These dimensional differences do not affect mating compatibility but may impact board layout considerations for post-side clearance.

Q: Are the Molex C-Grid 70287 parts with kinked pin termination compatible with standard PCB designs?

A: The C-Grid 70287 series maintains identical mating pitch and position configuration, ensuring mating compatibility. The kinked pin termination provides additional mechanical retention during soldering. Post length is 0.125", which differs from the original 0.120". This 0.005" difference is within typical PCB tolerance ranges but should be verified for applications with tight clearance requirements.

Q: What contact finish options are available among the substitutes?

A: The primary substitute (5-146257-7) and most Molex alternatives offer gold mating finish with tin post finish. Specific variants include: gold mating finish (0010897140, 0010897142, 0702800635, 0702800675, 0702871103, 0702871201) and tin mating finish (0010897141, 0702800595, 0702871005). Gold mating finish provides superior corrosion resistance and is recommended for applications requiring extended shelf life or harsh environmental exposure.

Q: Are all substitute parts RoHS compliant?

A: Yes. All recommended substitutes are ROHS3 Compliant. The original 4-146257-6 is RoHS Compliant. The transition to ROHS3 Compliant parts reflects current regulatory standards and eliminates lead from post finishes, aligning with mandatory lead-free manufacturing requirements.

Q: What is the Moisture Sensitivity Level (MSL) for all substitute parts?

A: All substitute parts, including the original 4-146257-6, are classified as MSL 1 (Unlimited). This classification indicates no moisture sensitivity restrictions and no special storage or handling requirements prior to soldering.

Q: Can I mix different substitute part numbers in the same assembly?

A: All recommended substitutes maintain identical mating pitch, position count, and row spacing, allowing mechanical interchangeability. However, mixing parts with different contact finish specifications or post lengths within the same assembly is not recommended. Maintain consistency within a single design to ensure uniform electrical and mechanical performance.

Q: What is the current rating for the Molex substitute parts?

A: The Molex C-Grid 70280 and C-Grid 70287 series do not specify current rating in the provided documentation. The original TE Connectivity 4-146257-6 and 5-146257-7 are rated at 3A per contact. For applications requiring current rating verification, contact the manufacturer directly or consult detailed product datasheets.

Q: Are there any operating temperature differences between the original and substitute parts?

A: The original TE Connectivity 4-146257-6 and 5-146257-7 specify operating temperature range of -65°C to 105°C. The Molex C-Grid 70280 and C-Grid 70287 series do not specify operating temperature in the provided documentation. For temperature-critical applications, verify Molex specifications with the manufacturer or use the TE Connectivity 5-146257-7 to maintain documented temperature performance.
