3M 3564-2001 Equivalent & Substitute Parts

Part Overview

The 3M 3564-2001 is a 50-position plug connector with free hanging (in-line) mounting and IDC termination. This connector features center strip contacts, bail lock, and shielding, with gold-plated contacts. The part is classified as obsolete, making identification of functionally equivalent alternatives necessary for ongoing system support and procurement planning.

Substiute Parts

3564-2001

3MIn Stock: 7893564-2001 Datasheet

Current PartRFQ

554953-1

TE Connectivity AMP ConnectorsIn Stock: 1220554953-1 Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the 3564-2001 is determined by strict equivalence across the following critical parameters:

• Number of Positions: 50
• Number of Rows: 2
• Connector Type: Plug
• Mounting Type: Free Hanging (In-Line)
• Termination Method: IDC
• Connector Style: Center Strip Contacts
• Features: Bail Lock, Shielded
• Contact Finish: Gold
• Contact Finish Thickness: 30.0µin (0.76µm)

The TE Connectivity AMP Connectors part 554953-1 meets all these criteria and is classified as an active product, providing functional equivalence for applications currently using the 3564-2001.

Parameter Comparison

Engineering Selection Recommendations

The TE Connectivity 554953-1 is the designated manufacturer-recommended substitute for the 3564-2001. Both connectors are electrically and mechanically equivalent across all specified parameters. The 554953-1 offers the advantage of active product status, ensuring continued availability and supply chain support. Additionally, the 554953-1 carries ROHS3 compliance and REACH unaffected status, meeting current regulatory requirements for new designs and procurement cycles.

Frequently Asked Questions (FAQ)

Q: Are the 3M 3564-2001 and TE Connectivity 554953-1 mechanically interchangeable?

A: Yes. Both connectors share identical specifications for number of positions (50), row configuration (2), mounting type (free hanging in-line), connector style (center strip contacts), and feature set (bail lock, shielded). Mechanical compatibility is confirmed.

Q: What is the primary reason to transition from the 3564-2001 to the 554953-1?

A: The 3564-2001 is classified as obsolete. The 554953-1 is an active product with confirmed ongoing availability, making it the appropriate choice for new procurement and long-term system support.

Q: Do the contact specifications differ between these two connectors?

A: No. Both connectors feature gold-plated contacts with identical finish thickness of 30.0µin (0.76µm) and the same moisture sensitivity level (MSL 1, Unlimited).

Q: What packaging is available for the substitute part?

A: The TE Connectivity 554953-1 is supplied in bag packaging.

Q: Are there compliance differences between the original and substitute part?

A: The 554953-1 includes ROHS3 compliance and REACH unaffected status. These certifications support regulatory requirements for current manufacturing and procurement standards.
