Bourns 3360C-1-502LF Equivalent & Substitute Parts

Part Overview

The Bourns 3360C-1-502LF is a 5k Ohm 1/4W linear panel mount potentiometer with conductive plastic resistive material and PC pin termination. This component is actively manufactured and widely used in audio and control applications requiring precise resistance adjustment. Substitute parts are identified when equivalent electrical specifications and mechanical compatibility allow direct replacement in circuit designs, reducing supply chain dependencies and enabling component sourcing flexibility.

Key Parameters

Parameter	Value
Resistance	5k Ohm
Power Rating	0.25W (1/4W)
Taper	Linear
Number of Gangs	1
Resistive Material	Conductive Plastic
Termination Style	PC Pins
Mounting Type	Panel Mount
Adjustment Type	Side Adjustment
Temperature Coefficient	±1000ppm/°C
Tolerance	±20%
Bushing Thread	1/4-32
RoHS Status	ROHS3 Compliant

Substitute Part Grouping Explanation

The Bourns 3310C-001-502L qualifies as a substitute for the 3360C-1-502LF based on the following critical parameters:

Electrical equivalence is established through matching resistance value (5k Ohm), power rating (0.25W), tolerance (±20%), temperature coefficient (±1000ppm/°C), taper (Linear), number of gangs (1), and resistive material (Conductive Plastic).

Mechanical compatibility is confirmed through identical termination style (PC Pins), adjustment type (Side Adjustment), bushing thread (1/4-32), and mounting type (Panel Mount). Both components feature slotted actuators with identical actuator length (0.500" / 12.70mm).

Regulatory compliance is maintained, with both parts meeting ROHS3 requirements and sharing the same ECCN (EAR99) and HTSUS classification (8533.40.8070).

Parameter Comparison

Parameter	3360C-1-502LF (Main)	3310C-001-502L (Substitute)	Compatibility
Resistance	5k Ohm	5k Ohm	Equivalent
Power Rating	0.25W	0.25W	Equivalent
Tolerance	±20%	±20%	Equivalent
Taper	Linear	Linear	Equivalent
Number of Gangs	1	1	Equivalent
Resistive Material	Conductive Plastic	Conductive Plastic	Equivalent
Termination Style	PC Pins	PC Pins	Equivalent
Adjustment Type	Side Adjustment	Side Adjustment	Equivalent
Temperature Coefficient	±1000ppm/°C	±1000ppm/°C	Equivalent
Bushing Thread	1/4-32	1/4-32	Equivalent
Mounting Type	Panel Mount	Panel Mount	Equivalent
Actuator Type	Slotted	Slotted	Equivalent
Actuator Length	0.500" (12.70mm)	0.500" (12.70mm)	Equivalent
Rotation	310°	300°	Minor Difference
Actuator Diameter	0.093" (2.36mm)	0.125" (3.18mm)	Minor Difference
Body Size	Square - 0.264" x 0.252" (6.70mm x 6.40mm)	Square - 0.375" x 0.375" (9.53mm x 9.53mm)	Minor Difference
RoHS Status	ROHS3 Compliant	ROHS3 Compliant	Equivalent
Product Status	Active	Active	Equivalent

Engineering Selection Recommendations

Both the 3360C-1-502LF and 3310C-001-502L are actively manufactured products with ROHS3 compliance and identical regulatory classifications. Selection between these components should be based on mechanical fit requirements within the application enclosure.

The 3360C-1-502LF features a compact body footprint (6.70mm x 6.40mm) with a smaller actuator diameter (2.36mm) and 310° rotation range. This configuration is suitable for space-constrained applications.

The 3310C-001-502L provides a larger body footprint (9.53mm x 9.53mm) with a larger actuator diameter (3.18mm) and 300° rotation range. The sealed feature designation indicates enhanced environmental protection. This configuration is suitable for applications requiring robust mechanical handling or enhanced moisture resistance.

Both parts maintain identical electrical performance and regulatory compliance, making substitution viable when mechanical constraints permit the dimensional differences.

Frequently Asked Questions (FAQ)

Q: Can the 3310C-001-502L directly replace the 3360C-1-502LF in existing designs?

A: Direct electrical substitution is possible due to matching resistance, power rating, tolerance, taper, and termination specifications. However, mechanical fit must be verified. The 3310C-001-502L has a larger body (9.53mm vs 6.70mm) and larger actuator diameter (3.18mm vs 2.36mm), requiring confirmation that panel cutouts and mechanical clearances accommodate these dimensions.

Q: What are the key differences between these two potentiometers?

A: The primary differences are mechanical: body size, actuator diameter, and rotation range. The 3310C-001-502L is larger with a 300° rotation versus the 3360C-1-502LF's 310° rotation. The 3310C-001-502L includes a sealed feature. All electrical parameters remain identical.

Q: Are both parts RoHS compliant?

A: Yes, both the 3360C-1-502LF and 3310C-001-502L are ROHS3 compliant and share identical ECCN (EAR99) and HTSUS classifications.

Q: What is the difference in packaging between these parts?

A: The 3360C-1-502LF is supplied in Tray packaging, while the 3310C-001-502L is supplied in Bulk packaging. This affects handling and storage but does not impact component functionality.

Q: Does the rotation angle difference (310° vs 300°) affect circuit performance?

A: The 10° difference in mechanical rotation range does not affect electrical performance or resistance accuracy. Selection depends on application requirements for adjustment range and mechanical design constraints.
