30P4.6-JMCS-G-TF(N) Equivalent & Substitute Parts

Part Overview

The 30P4.6-JMCS-G-TF(N) is a 30-position rectangular connector plug manufactured by JST Sales America Inc., designed for surface mount applications with outer shroud contacts and gold plating. This component is classified as obsolete, making identification of functionally equivalent alternatives essential for ongoing production support, design updates, and inventory management. Substitute parts must maintain identical electrical and mechanical specifications to ensure direct compatibility without circuit redesign or board layout modifications.

Substiute Parts

30P3.5-JMCS-G-TF(N)

JST Sales America Inc.In Stock: 91130P3.5-JMCS-G-TF(N) Datasheet

Current PartRFQ

145046030635868+

KYOCERA AVXIn Stock: 2879145046030635868+ Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the 30P4.6-JMCS-G-TF(N) is determined by strict equivalence across the following parameters:

• Connector Configuration: 30 positions, 2 rows, 0.020" (0.50mm) pitch
• Form Factor: Plug with outer shroud contacts
• Mounting Technology: Surface mount (SMD)
• Contact Material: Gold plating
• Mated Height: 4.6mm stacking height
• Environmental Compliance: RoHS compliance and MSL rating

The substitute part 145046030635868+ from KYOCERA AVX meets all these criteria, providing functional and mechanical interchangeability for the obsolete JST component.

Parameter Comparison

Engineering Selection Recommendations

The 145046030635868+ from KYOCERA AVX is the qualified substitute for the obsolete 30P4.6-JMCS-G-TF(N). Selection is based on:

• Functional Equivalence: Identical electrical and mechanical specifications across all critical parameters
• Active Product Status: The substitute is currently in active production, ensuring long-term availability and supply chain stability
• Regulatory Compliance: Both components meet RoHS requirements; the substitute carries ROHS3 compliance with REACH Unaffected status, providing enhanced regulatory coverage
• Inventory Availability: 2,779 units in stock provide immediate procurement capability
• Manufacturing Features: The substitute includes pick-and-place and solder retention features, supporting modern assembly processes
