Phoenix Contact 2909521 General Purpose Relay SPDT 10A 230V - Equivalent & Substitute Parts

Part Overview

The Phoenix Contact 2909521 is a general purpose relay with Single Pole Double Throw (SPDT) contact configuration, rated for 10A at 230VAC/DC coil voltage. This DIN rail-mounted relay is designed for industrial control applications requiring reliable switching of AC and DC loads. The part is currently active in production with 796 units in stock. Substitute parts may be required due to inventory constraints, regional availability, or specific project procurement requirements while maintaining identical electrical and mechanical performance.

Substiute Parts

2909521

Phoenix ContactIn Stock: 9012909521 Datasheet

Current PartRFQ

2967675

Phoenix ContactIn Stock: 10262967675 Datasheet

Parametric EquivalentRFQ

Key Parameters

Substitute Part Grouping Explanation

The Phoenix Contact 2967675 qualifies as a parametric equivalent to the 2909521 based on the following critical substitution criteria:

Electrical Parameters (Identical):

• Coil voltage: 230VAC/DC
• Contact form: SPDT (1 Form C)
• Contact rating: 10 A
• Switching voltage: 250VAC, 250VDC - Max
• Coil current: 4.5 mA
• Coil type: Non Latching
• Operate time: 7 ms
• Release time: 10 ms
• Contact material: Silver Nickel (AgNi)

Mechanical Parameters (Identical):

• Mounting type: DIN Rail
• Termination style: Screw Terminal
• Operating temperature range: -40°C ~ 55°C

Compliance (Identical):

• RoHS Compliant
• ECCN: EAR99
• HTSUS: 8536.49.0075

Both parts belong to the Phoenix Contact PLC-RSC series and maintain active product status, confirming full functional and physical interchangeability.

Parameter Comparison

Engineering Selection Recommendations

Both the Phoenix Contact 2909521 and 2967675 are active production parts with RoHS compliance and identical electrical and mechanical specifications. Selection between these parts should be based on inventory availability and procurement lead times. The 2967675 currently maintains higher stock levels (997 units) compared to the 2909521 (796 units), making it suitable for applications requiring immediate availability. Both parts carry the same regulatory classification (ECCN: EAR99, HTSUS: 8536.49.0075) and are suitable for industrial control applications within the specified operating temperature range of -40°C to 55°C.

Frequently Asked Questions (FAQ)

Q: Can the Phoenix Contact 2967675 be used as a direct replacement for the 2909521?

A: Yes. Both parts are identical in all critical electrical parameters (coil voltage, contact rating, switching voltage, timing characteristics), mechanical configuration (DIN rail mounting, screw terminals), and compliance certifications (RoHS). Direct substitution is supported without circuit modification.

Q: Are there any differences in the relay's switching performance between these two part numbers?

A: No. Both relays have identical operate time (7 ms) and release time (10 ms), ensuring equivalent switching performance in control circuits.

Q: What is the significance of the different base product numbers (29095 vs. 29676)?

A: The base product numbers indicate different manufacturing batches or revisions within the PLC-RSC series. However, all specified electrical and mechanical parameters remain identical, confirming full interchangeability.

Q: Are both parts suitable for 230VAC and 230VDC applications?

A: Yes. Both relays are rated for 230VAC/DC coil voltage and support switching of loads up to 250VAC or 250VDC maximum, making them suitable for both AC and DC control circuits.

Q: What is the maximum load current these relays can switch?

A: Both relays are rated for 10A contact current at the specified switching voltages (250VAC, 250VDC - Max).

Q: Are these relays suitable for outdoor or harsh environment applications?

A: Both relays operate within the temperature range of -40°C to 55°C. Specific environmental protection requirements (moisture, vibration, chemical exposure) should be evaluated based on the application's environmental classification and the relay's seal rating specifications.
