Phoenix Contact 2909509 General Purpose Relay DPDT 24VDC

Part Overview

The Phoenix Contact 2909509 is a general purpose relay with DPDT (Double Pole Double Throw) contact configuration, designed for DIN rail mounting applications. This relay operates on a 24VDC coil voltage and is rated for 6A switching current at up to 250VAC or 250VDC. The part is currently active in production with full RoHS3 compliance and REACH compliance status. Alternative equivalent parts may be required due to inventory availability, supply chain considerations, or specific application requirements within the same electrical and mechanical parameter range.

Substiute Parts

2909509

Phoenix ContactIn Stock: 8642909509 Datasheet

Current PartRFQ

2967060

Phoenix ContactIn Stock: 12282967060 Datasheet

Parametric EquivalentRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the Phoenix Contact 2909509 is determined by strict equivalence across the following critical parameters:

• Coil voltage: 24VDC
• Contact configuration: DPDT (2 Form C)
• Contact current rating: 6 A
• Switching voltage capability: 250VAC, 250VDC maximum
• Mounting type: DIN Rail
• Coil type: Non Latching
• Termination style: Screw Terminal
• Operating temperature range: -40°C to 60°C
• Contact material: Silver Nickel (AgNi)

The substitute part Phoenix Contact 2967060 meets all these criteria and belongs to the same PLC-RSC series, maintaining full electrical and mechanical compatibility within the specified parameter envelope.

Parameter Comparison

Engineering Selection Recommendations

Both the Phoenix Contact 2909509 and 2967060 are active production parts with identical RoHS3 and REACH compliance certifications. Selection between these parts should be based on inventory availability and supply chain requirements, as they are fully equivalent across all specified electrical and mechanical parameters. Both parts maintain the same performance characteristics, contact ratings, and operational specifications required for DIN rail-mounted DPDT relay applications operating at 24VDC.

Frequently Asked Questions (FAQ)

Q: Can Phoenix Contact 2967060 be used as a direct replacement for 2909509?

A: Yes. Both parts are identical across all critical electrical and mechanical parameters, including coil voltage, contact configuration, current rating, switching voltage, mounting type, and operating temperature range. They belong to the same PLC-RSC series and share identical feature sets.

Q: Are there any differences in compliance or certifications between these parts?

A: No. Both parts carry identical RoHS3 and REACH compliance status, ensuring equivalent regulatory compliance for applications requiring these certifications.

Q: What determines whether a relay can substitute for the 2909509?

A: A substitute relay must match all of the following parameters: 24VDC coil voltage, DPDT contact configuration, 6A contact rating, 250VAC/250VDC switching voltage capability, DIN rail mounting, non-latching coil type, screw terminal termination, -40°C to 60°C operating temperature range, and Silver Nickel contact material.

Q: Are the packaging and inventory considerations different between these parts?

A: Both parts are supplied in bulk packaging. Inventory levels differ (2909509: 806 pcs; 2967060: 1188 pcs), which may influence availability and lead time for procurement decisions.
