TE Connectivity AMP Connectors 284065-6 Terminal Block Header Equivalent & Substitute Parts

Part Overview

The TE Connectivity AMP Connectors 284065-6 is a 12-position terminal block header designed for vertical through-hole mounting with 0.200" (5.08mm) pitch spacing. This component features male pins with four-side shrouding and is part of the Buchanan series. The part maintains active product status and is widely used in industrial control, power distribution, and signal routing applications where reliable solder-terminated connections are required.

Substitute parts are identified when equivalent electrical performance, mechanical compatibility, and physical dimensions align with the original specification, enabling direct replacement in circuit designs without functional compromise.

Substiute Parts

284065-6

TE Connectivity AMP ConnectorsIn Stock: 1026284065-6 Datasheet

Current PartRFQ

1845374

Phoenix ContactIn Stock: 7431845374 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the TE Connectivity 284065-6 is determined by strict alignment of the following critical parameters:

Electrical Compatibility:

• Voltage rating: 300 V (UL standard)
• Current rating: 12 A (UL standard)
• Contact mating finish: Tin

Mechanical Compatibility:

• Number of positions: 12
• Pitch spacing: 0.200" (5.08mm)
• Header orientation: Vertical
• Mounting type: Through hole
• Termination style: Solder
• Type configuration: Male pins with four-side shrouding

Environmental & Compliance:

• Material flammability rating: UL94 V-0
• RoHS compliance status: Compliant
• Moisture sensitivity level: 1 (Unlimited)

The Phoenix Contact 1845374 satisfies all critical substitution criteria, maintaining identical electrical performance under UL standards, matching mechanical configuration, and providing equivalent environmental protection ratings.

Parameter Comparison

Engineering Selection Recommendations

Primary Selection: TE Connectivity 284065-6

The TE Connectivity 284065-6 maintains active product status with 997 units in current inventory. This component is RoHS compliant, carries UL94 V-0 flammability certification, and operates across the -40°C to 110°C temperature range. The Buchanan series designation provides established design history and supply chain continuity.

Equivalent Substitute: Phoenix Contact 1845374

The Phoenix Contact 1845374 provides full electrical and mechanical equivalence under UL standards. This component is also active, RoHS compliant, and carries identical UL94 V-0 certification. Current inventory of 659 units supports availability. The COMBICON MDSTBVA series designation indicates Phoenix Contact's industrial-grade terminal block platform.

Physical Dimension Considerations:

Minor variations exist in contact tail length (0.138" versus 0.154") and housing material composition (PA66 nylon versus PBT). These variations remain within acceptable tolerance for standard through-hole PCB mounting applications. Insulation height differences (0.869" versus 0.870") are negligible for mechanical clearance purposes.

Both components satisfy identical electrical performance requirements, compliance certifications, and functional specifications for direct substitution in circuit designs.

Frequently Asked Questions (FAQ)

Q: Can the Phoenix Contact 1845374 directly replace the TE Connectivity 284065-6 in existing designs?

A: Yes. Both components share identical electrical ratings (300 V UL, 12 A UL), mechanical configuration (12-position, 5.08mm pitch, vertical through-hole), and compliance certifications (RoHS, UL94 V-0). The components are functionally equivalent for circuit applications.

Q: What is the significance of the 0.200" (5.08mm) pitch specification?

A: Pitch defines the center-to-center spacing between adjacent contact positions. The 0.200" (5.08mm) pitch is a standard industrial spacing that determines PCB footprint compatibility. Both substitute parts maintain this identical pitch, ensuring PCB layout compatibility without modification.

Q: How do the housing materials differ between these components?

A: The TE Connectivity 284065-6 uses Polyamide (PA66) nylon, while the Phoenix Contact 1845374 uses Polybutylene Terephthalate (PBT). Both materials achieve UL94 V-0 flammability certification and provide equivalent environmental protection. Material selection does not affect electrical performance or mechanical compatibility.

Q: What does the four-side shrouding feature provide?

A: Four-side shrouding surrounds the male pin array on all sides, providing mechanical protection against accidental contact and improved polarization guidance during mating operations. Both substitute parts include this identical shrouding configuration.

Q: Are there any temperature operating range differences?

A: The TE Connectivity 284065-6 specifies -40°C to 110°C operating temperature. The Phoenix Contact 1845374 does not provide explicit operating temperature data in the available parameters. For applications requiring confirmed temperature specifications, the TE Connectivity component provides documented performance across the full industrial temperature range.

Q: What does RoHS Compliant status indicate?

A: RoHS compliance confirms that both components meet Restriction of Hazardous Substances regulations, restricting lead, cadmium, mercury, and other hazardous materials. Both substitute parts carry identical RoHS compliant status, suitable for applications requiring environmental compliance.

Q: How do the contact tail lengths affect PCB soldering?

A: Contact tail length (0.138" for TE Connectivity versus 0.154" for Phoenix Contact) determines solder joint depth on PCB pads. The 0.016" difference is within standard PCB manufacturing tolerances and does not affect solder joint quality or mechanical reliability for standard through-hole assembly processes.

Q: What is Moisture Sensitivity Level (MSL) 1?

A: MSL 1 indicates unlimited shelf life without moisture control requirements. Both components carry MSL 1 status, eliminating the need for desiccant packaging or bake-out procedures prior to assembly.
