Phoenix Contact 2805041 BNC Coaxial Connector Adapter

Part Overview

The Phoenix Contact 2805041 is a coaxial connector adapter designed for RF applications requiring 50-ohm impedance matching. This adapter provides jack-to-jack connectivity between two BNC female sockets, enabling signal transmission in RF systems up to 4 GHz. The part is classified as obsolete, necessitating identification of active substitute components to maintain system compatibility and ensure continued availability for new designs and field replacements.

Substiute Parts

2805041

Phoenix ContactIn Stock: 10752805041 Datasheet

Current PartRFQ

2805038

Phoenix ContactIn Stock: 7562805038 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the Phoenix Contact 2805041 is determined by the following critical parameters that must remain constant:

• Adapter Configuration: Jack-to-jack topology with female-to-female center gender
• Connector Series: BNC to BNC same-series conversion
• Electrical Impedance: 50 ohms for RF signal integrity
• Frequency Range: Maximum 4 GHz operational capability
• Mechanical Interface: Bayonet lock fastening and DIN rail mounting
• Environmental Protection: IP20 ingress protection rating
• Regulatory Compliance: RoHS compliance status

The substitute part 2805041 maintains all critical electrical and mechanical parameters required for direct functional replacement. The primary distinction lies in product status transition from obsolete to active availability.

Parameter Comparison

Engineering Selection Recommendations

The Phoenix Contact 2805038 serves as the direct functional substitute for the obsolete 2805041. Both components maintain identical electrical specifications (50-ohm impedance, 4 GHz maximum frequency) and mechanical interfaces (BNC jack-to-jack, bayonet fastening, DIN rail mounting). The 2805038 is currently in active production status, ensuring supply chain continuity and long-term availability.

The 2805038 carries ROHS3 compliance, representing an enhanced regulatory posture compared to the RoHS Compliant designation of the 2805041. Both components maintain MSL 1 rating, indicating unlimited shelf life under standard storage conditions. Current inventory of 708 units for the 2805038 supports immediate procurement requirements.
