TE Connectivity AMP Connectors 215079-6 Equivalent & Substitute Parts

Part Overview

The TE Connectivity AMP Connectors 215079-6 is a 6 Position Receptacle Connector designed for 0.100" (2.54mm) Through Hole applications. This rectangular connector operates within the Micro-MaTch series and is classified as an active product. The connector features forked contact geometry, tin plating on mating surfaces, and is suitable for board-to-board or cable interconnection in automotive and general purpose applications. Identifying equivalent and substitute parts is necessary to ensure design flexibility, manage supply chain continuity, and maintain compatibility across production batches and procurement cycles.

Substiute Parts

215079-6

TE Connectivity AMP ConnectorsIn Stock: 14999215079-6 Datasheet

Current PartRFQ

7-215079-6

TE Connectivity AMP ConnectorsIn Stock: 23537-215079-6 Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of rectangular connectors is determined by strict equivalence across mechanical and electrical parameters. The primary substitution criteria for the 215079-6 are:

Critical Matching Parameters:

• Connector type (Receptacle)
• Number of positions (6)
• Pitch specification (0.100" / 2.54mm)
• Row configuration (2 rows with 0.100" spacing)
• Mounting method (Through Hole)
• Termination style (Kinked Pin, Solder)
• Contact finish (Tin plating)
• Operating temperature range (-40°C ~ 105°C)
• Voltage rating (100VDC)
• Flammability compliance (UL94 V-0)

The substitute part 7-215079-6 maintains identical specifications across all critical parameters, confirming direct substitution capability within the Micro-MaTch series.

Parameter Comparison

Engineering Selection Recommendations

Both the 215079-6 and 7-215079-6 are active products manufactured by TE Connectivity AMP Connectors within the Micro-MaTch series. The parts are functionally equivalent across all specified mechanical and electrical parameters. Both connectors maintain UL94 V-0 flammability compliance and RoHS compliance status, meeting regulatory requirements for automotive and general purpose applications.

The 215079-6 maintains ROHS3 Compliant status, while the 7-215079-6 is designated as RoHS Compliant. Both designations confirm adherence to Restriction of Hazardous Substances directives. The inventory availability differs between the two parts, with the 215079-6 showing 14,895 pieces in stock and the 7-215079-6 showing 2,300 pieces in stock.

Selection between these parts should be based on procurement requirements, supply chain availability, and inventory management objectives. Both parts are suitable for direct substitution in applications requiring 6-position, 0.100" pitch receptacle connectors with through-hole solder termination.

Frequently Asked Questions (FAQ)

Q: Can the 7-215079-6 be used as a direct replacement for the 215079-6?

A: Yes. The 7-215079-6 is a direct substitute for the 215079-6. Both connectors share identical specifications for connector type, position count, pitch, row configuration, mounting method, termination style, contact finish, operating temperature range, and voltage rating. All mechanical and electrical parameters match exactly.

Q: Are there differences in compliance certifications between these parts?

A: Both parts meet RoHS compliance requirements. The 215079-6 is designated ROHS3 Compliant, while the 7-215079-6 is designated RoHS Compliant. Both designations confirm compliance with Restriction of Hazardous Substances directives and are acceptable for equivalent applications.

Q: What is the significance of the part number prefix "7-" in the 7-215079-6?

A: The "7-" prefix indicates a variant designation within the TE Connectivity AMP Connectors product line. This prefix does not alter the functional specifications or electrical characteristics of the connector. Both the 215079-6 and 7-215079-6 share the same base product number (215079) and are part of the same Micro-MaTch series.

Q: Are the packaging specifications identical for both parts?

A: Yes. Both the 215079-6 and 7-215079-6 are supplied in Cut Tape (CT) packaging, which is standard for this connector category.

Q: What are the critical parameters that determine substitution eligibility?

A: Substitution eligibility is determined by matching the following parameters: connector type (Receptacle), number of positions (6), pitch specification (0.100" / 2.54mm), row configuration (2 rows with 0.100" spacing), mounting method (Through Hole), termination style (Kinked Pin, Solder), contact finish (Tin), operating temperature range (-40°C ~ 105°C), and voltage rating (100VDC). Both parts meet all these criteria.

Q: Can these connectors be used in automotive applications?

A: Yes. Both the 215079-6 and 7-215079-6 are rated for automotive applications, as specified in their application designations. They also support general purpose applications.

Q: What is the moisture sensitivity level for these connectors?

A: Both connectors have a Moisture Sensitivity Level (MSL) of 1 (Unlimited), indicating no moisture sensitivity restrictions for storage or handling.
