TE Connectivity 207608-3 Rectangular Connector Equivalent & Substitute Parts

Part Overview

The TE Connectivity 207608-3 is a 3-position header connector from the Metrimate series, designed for board-to-cable/wire applications with through-hole, right-angle mounting. This connector features gold-plated mating contacts, tin-lead post finish, and operates across a temperature range of -55°C to 130°C with a current rating of 7.5A at 600V.

The 207608-3 carries an obsolete product status. Identifying equivalent and substitute parts is necessary to ensure design continuity, maintain supply chain reliability, and support ongoing production and maintenance requirements for systems utilizing this connector.

Substiute Parts

207608-3

TE Connectivity AMP ConnectorsIn Stock: 657207608-3 Datasheet

Current PartRFQ

207608-7

TE Connectivity AMP ConnectorsIn Stock: 1226207608-7 Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the 207608-3 is determined by strict equivalence across the following critical parameters:

Mandatory Matching Parameters:

• Connector type (Header)
• Number of positions (3)
• Pitch - mating (0.197" / 5.00mm)
• Mounting type (Through hole, right angle)
• Contact type (Female socket)
• Current rating (7.5A)
• Voltage rating (600V)
• Operating temperature range (-55°C ~ 130°C)
• Contact finish - mating (Gold)
• Insulation material (Thermoplastic)
• Flammability rating (UL94 V-0)

The substitute part 207608-7 meets all mandatory matching parameters. Differences exist only in packaging format and post-contact finish composition, which do not affect electrical or mechanical compatibility in the mating interface.

Parameter Comparison

Engineering Selection Recommendations

Primary Recommendation: 207608-7

The 207608-7 is the direct substitute for the 207608-3. Both connectors share identical electrical and mechanical specifications across all mating interface parameters. The 207608-7 is the active production variant within the Metrimate series.

Compliance Considerations:

The 207608-7 carries RoHS Compliant status, whereas the 207608-3 is marked as "Not applicable." This distinction reflects the 207608-7's compliance with Restriction of Hazardous Substances regulations. The post-contact finish differs between the two parts: the 207608-3 uses tin-lead, while the 207608-7 uses tin. This change aligns with RoHS compliance requirements and does not affect mating interface performance.

Product Status Impact:

The 207608-3 is obsolete, while the 207608-7 is active. For new designs, ongoing production, and long-term supply chain planning, the 207608-7 is the appropriate selection. The 207608-7 maintains full backward compatibility with existing mating connectors and cable assemblies designed for the 207608-3.

Frequently Asked Questions (FAQ)

Q: Can the 207608-7 directly replace the 207608-3 in existing applications?

A: Yes. The 207608-7 is electrically and mechanically equivalent to the 207608-3 across all mating interface parameters. Both connectors feature identical pitch, contact configuration, current and voltage ratings, and operating temperature range. The 207608-7 is compatible with existing mating connectors and cable assemblies.

Q: What is the difference between the tin-lead post finish on the 207608-3 and the tin post finish on the 207608-7?

A: The post finish is the plating applied to the solder tail of the connector. Both finishes support soldering to PCBs. The tin finish on the 207608-7 reflects RoHS compliance requirements and does not affect electrical performance or mating interface compatibility.

Q: Why is the 207608-3 marked as obsolete?

A: The 207608-3 has been superseded by the 207608-7 in the active product line. The 207608-7 offers the same functionality with RoHS compliance and active manufacturing support.

Q: Does packaging format affect connector compatibility?

A: No. The 207608-3 and 207608-7 differ in packaging (the 207608-7 is supplied in trays), but packaging does not affect the connector's electrical or mechanical performance. Packaging differences relate only to order quantities, storage, and handling logistics.

Q: Are there any temperature or current limitations when substituting the 207608-7 for the 207608-3?

A: No. Both connectors operate across the identical temperature range of -55°C to 130°C and support the same 7.5A current rating at 600V. There are no derating or operational limitations introduced by the substitution.

Q: What is the contact material for both connectors?

A: Both the 207608-3 and 207608-7 use phosphor bronze as the contact material with gold plating on the mating surface. This ensures consistent contact resistance and reliability across both parts.
