TE Connectivity 1-925370-5 Equivalent & Substitute Parts

Part Overview

The TE Connectivity 1-925370-5 is a 30-position rectangular connector receptacle housing with 0.100" (2.54mm) pitch, designed for free-hanging in-line mounting applications. This AMPMODU Mod IV series component features female socket contacts with crimp termination and operates across -65°C to 105°C. The part is Active status and RoHS3 compliant. Substitute parts are identified when equivalent electrical and mechanical parameters align with the main part specifications, enabling direct functional replacement in applications where connector housing compatibility is required.

Key Parameters

Parameter	Specification
Connector Type	Receptacle
Contact Type	Female Socket
Number of Positions	30
Pitch	0.100" (2.54mm)
Number of Rows	2
Row Spacing	0.100" (2.54mm)
Mounting Type	Free Hanging (In-Line)
Contact Termination	Crimp
Insulation Material	Polyamide (PA66), Nylon 6/6, Glass Filled
Operating Temperature Range	-65°C ~ 105°C
Moisture Sensitivity Level	1 (Unlimited)
RoHS Status	ROHS3 Compliant

Substitute Part Grouping Explanation

Substitute parts for the TE Connectivity 1-925370-5 are qualified based on the following critical parameters that determine functional equivalence:

Core Electrical and Mechanical Criteria:

Connector Type: Receptacle
Contact Type: Female Socket
Number of Positions: 30
Pitch: 0.100" (2.54mm)
Number of Rows: 2
Row Spacing: 0.100" (2.54mm)
Mounting Type: Free Hanging (In-Line)
Contact Termination: Crimp
Moisture Sensitivity Level: 1 (Unlimited)

All identified substitute parts meet these core parameters. Variations in color, insulation material composition, operating temperature range, and manufacturer series do not prevent functional substitution when the above criteria are satisfied. The substitute parts listed are Amphenol ICC (FCI) 69176-030LF, Molex 0022552303, and Amphenol ICC (FCI) 65239-015LF.

Parameter Comparison

Parameter	TE Connectivity 1-925370-5	Amphenol ICC 69176-030LF	Molex 0022552303	Amphenol ICC 65239-015LF
Manufacturer	TE Connectivity AMP Connectors	Amphenol ICC (FCI)	Molex	Amphenol ICC (FCI)
Category	Rectangular Connectors	Rectangular Connectors	Rectangular Connectors	Rectangular Connectors
Connector Type	Receptacle	Receptacle	Receptacle	Receptacle
Contact Type	Female Socket	Female Socket	Female Socket	Female Socket
Number of Positions	30	30	30	30
Pitch	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)
Number of Rows	2	2	2	2
Row Spacing	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)
Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)	Free Hanging (In-Line)	Free Hanging (In-Line)
Contact Termination	Crimp	Crimp	Crimp	Crimp
Color	Green	Black	Black	Blue
Insulation Material	Polyamide (PA66), Nylon 6/6, Glass Filled	Polyphenylene, Modified	Polyester, Glass Filled	Thermoplastic, Glass Filled
Operating Temperature Range	-65°C ~ 105°C	-40°C ~ 105°C	-40°C ~ 105°C	-65°C ~ 125°C
Moisture Sensitivity Level	1 (Unlimited)	1 (Unlimited)	1 (Unlimited)	1 (Unlimited)
Product Status	Active	Active	Active	Active
RoHS Status	ROHS3 Compliant	RoHS Compliant	ROHS3 Compliant	RoHS Compliant
ECCN	EAR99	EAR99	EAR99	EAR99

Engineering Selection Recommendations

All substitute parts listed maintain Active product status, ensuring continued availability and manufacturer support. The TE Connectivity 1-925370-5 and Molex 0022552303 both carry ROHS3 compliance, while Amphenol ICC parts carry RoHS compliance. All parts are classified as EAR99 for export control purposes.

Amphenol ICC 69176-030LF operates within a reduced lower temperature limit of -40°C compared to the main part's -65°C minimum. This part includes a polarizing key feature not present in the main part. Selection is appropriate for applications not requiring extended low-temperature operation below -40°C.

Molex 0022552303 operates within a reduced lower temperature limit of -40°C. This part carries ROHS3 compliance matching the main part and REACH Unaffected status. Selection is appropriate for applications not requiring extended low-temperature operation below -40°C.

Amphenol ICC 65239-015LF maintains the full -65°C lower temperature limit of the main part and extends the upper operating temperature to 125°C. This part carries REACH Affected status. Selection is appropriate for applications requiring extended high-temperature operation up to 125°C or when low-temperature operation to -65°C is required.

Frequently Asked Questions (FAQ)

Q: What determines if a rectangular connector housing can substitute for the TE Connectivity 1-925370-5?

A: Functional substitution requires matching the following parameters: 30-position receptacle with female socket contacts, 0.100" (2.54mm) pitch, 2-row configuration with 0.100" row spacing, free-hanging in-line mounting, crimp termination, and MSL 1 rating. All listed substitutes meet these criteria.

Q: Can I use Amphenol ICC 69176-030LF in applications requiring -65°C operation?

A: No. The Amphenol ICC 69176-030LF operates from -40°C to 105°C, with a minimum temperature limit 25°C higher than the main part. Applications requiring operation at -65°C must use the TE Connectivity 1-925370-5 or Amphenol ICC 65239-015LF.

Q: Does the color difference between substitute parts affect electrical compatibility?

A: No. Color is a visual identifier only and does not affect electrical or mechanical compatibility. The TE Connectivity 1-925370-5 (green), Amphenol ICC 69176-030LF (black), Molex 0022552303 (black), and Amphenol ICC 65239-015LF (blue) are functionally equivalent in terms of electrical performance and mechanical fit.

Q: What is the significance of the polarizing key feature in Amphenol ICC 69176-030LF?

A: The polarizing key is a mechanical feature that prevents incorrect mating orientation. The main part does not include this feature. If the application design does not require polarization, this difference does not prevent substitution. If polarization is required by the application, the polarizing key feature must be accommodated in the connector design.

Q: Are all substitute parts RoHS compliant?

A: Yes. All substitute parts carry RoHS compliance. The TE Connectivity 1-925370-5 and Molex 0022552303 are ROHS3 compliant. Amphenol ICC parts are RoHS compliant. All meet regulatory requirements for hazardous substance restrictions.

Q: Which substitute part should I select for high-temperature applications?

A: The Amphenol ICC 65239-015LF operates to 125°C, providing 20°C higher maximum temperature than the main part and other substitutes. This part is appropriate for applications requiring extended high-temperature operation.

Q: Do the different insulation materials affect mechanical compatibility?

A: No. All substitute parts use glass-filled thermoplastic or polyamide materials suitable for the same mechanical and environmental requirements. The specific insulation material composition does not prevent functional substitution when all core parameters match.

Q: What is the REACH status difference between substitute parts?

A: The Molex 0022552303 is REACH Unaffected, while Amphenol ICC parts are REACH Affected. The TE Connectivity 1-925370-5 has undefined REACH status. REACH Affected status indicates the part contains substances of concern under REACH regulations. Selection based on REACH status depends on application location and regulatory requirements.

Q: Can I mix and match connector housings from different manufacturers in the same assembly?

A: Yes, provided all housings meet the core electrical and mechanical parameters. All listed parts are mechanically and electrically compatible with each other due to matching pitch, position count, row configuration, and termination type.
