Phoenix Contact 1905201 Terminal Block - Equivalent & Substitute Parts

Part Overview

The Phoenix Contact 1905201 is a 5-position wire-to-board terminal block with horizontal mating orientation and 0.200" (5.08mm) pitch. This component belongs to the COMBICON MKDS series and is designed for PCB-mounted applications requiring screw-type wire termination. The part is currently active in production with 1098 units in stock.

Finding equivalent substitute parts is necessary to ensure supply chain continuity, optimize inventory management, and maintain design flexibility when the primary part becomes unavailable or when alternative sourcing offers operational advantages.

Substiute Parts

1905201

Phoenix ContactIn Stock: 11971905201 Datasheet

Current PartRFQ

282857-5

TE Connectivity AMP ConnectorsIn Stock: 2921282857-5 Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the Phoenix Contact 1905201 is determined by strict alignment with the following core parameters:

• Electrical Compatibility: Voltage rating of 300 V and current rating equal to or exceeding 15 A
• Mechanical Compatibility: 5 positions, 0.200" (5.08mm) pitch, horizontal mating orientation, through-hole mounting
• Termination Method: Screw-type rising cage clamp wire termination
• Wire Gauge Support: 12-30 AWG acceptance
• Physical Features: Interlocking side entry configuration, green color, M3 screw thread
• Regulatory Compliance: RoHS and REACH status alignment

The TE Connectivity AMP Connectors part 282857-5 (Buchanan series) meets all substitution criteria. This part maintains identical mechanical and electrical interface specifications while offering enhanced current capacity (24 A versus 15 A) and improved material specifications.

Parameter Comparison

Engineering Selection Recommendations

The TE Connectivity 282857-5 is a direct functional substitute for the Phoenix Contact 1905201 based on the following engineering criteria:

Mechanical Interface: Both parts maintain identical pitch (5.08mm), position count (5), mating orientation (horizontal), and mounting method (through-hole PCB). Physical interchangeability is confirmed.

Electrical Performance: The 282857-5 provides 24 A current capacity, which exceeds the 1905201 specification of 15 A. Both parts are rated for 300 V operation. This enhanced current rating provides additional design margin without introducing incompatibility.

Regulatory Compliance: Both parts carry RoHS compliance certifications and share identical ECCN (EAR99) and HTSUS (8536.90.4000) classifications. The 282857-5 is REACH Affected while the 1905201 is REACH Unaffected; however, this does not preclude substitution in applications where REACH compliance is not a design requirement.

Material Specifications: The 282857-5 uses PA66 (Nylon 6/6) housing material with specified contact and clamp plating (Brass - Tin Plated contacts; Brass - Nickel Plated clamps and screws), providing enhanced material traceability compared to the 1905201.

Inventory Availability: The 282857-5 has 2831 units in stock, providing superior supply chain availability compared to the 1905201 (1098 units).

Frequently Asked Questions (FAQ)

Q: Can the TE Connectivity 282857-5 be used as a direct replacement for the Phoenix Contact 1905201 in existing designs?

A: Yes. The 282857-5 maintains identical mechanical pitch, position count, mating orientation, mounting type, wire termination method, wire gauge support, voltage rating, screw thread specification, and interlocking features. PCB footprints and connector mating interfaces are compatible.

Q: What is the difference in current rating between these parts?

A: The Phoenix Contact 1905201 is rated for 15 A, while the TE Connectivity 282857-5 is rated for 24 A. The higher rating of the 282857-5 does not create incompatibility; it provides additional current-carrying capacity for the same physical form factor.

Q: Are there differences in material composition?

A: The 1905201 specifies polyamide (PA) and nylon housing material without detailed grade designation. The 282857-5 specifies PA66 (Nylon 6/6) housing with defined contact plating (Brass - Tin Plated) and clamp/screw plating (Brass - Nickel Plated). Both materials are polyamide-based and suitable for the same operating environment.

Q: What is the difference in screw torque specification?

A: The Phoenix Contact 1905201 specifies 0.5-0.6 Nm (4.4-5.3 Lb-In) torque, while the TE Connectivity 282857-5 specifies 0.79 Nm (7.0 Lb-In). Both use M3 screw threads. The higher torque specification for the 282857-5 reflects its enhanced current capacity and material specifications.

Q: Are both parts RoHS compliant?

A: Yes. The Phoenix Contact 1905201 is ROHS3 Compliant, and the TE Connectivity 282857-5 is RoHS Compliant. Both meet RoHS requirements for hazardous substance restrictions.

Q: What is the REACH compliance status difference?

A: The Phoenix Contact 1905201 is listed as REACH Unaffected, while the TE Connectivity 282857-5 is REACH Affected. REACH Affected status indicates the part is subject to REACH regulations. This difference does not preclude substitution in applications where REACH compliance is not a contractual or regulatory requirement.

Q: Are the packaging and inventory considerations different?

A: Both parts are supplied in bulk packaging. The TE Connectivity 282857-5 has significantly higher inventory availability (2831 units) compared to the Phoenix Contact 1905201 (1098 units), which may provide supply chain advantages for high-volume applications.
