Phoenix Contact 1824434 Terminal Block Receptacle - Equivalent & Substitute Parts

Part Overview

The Phoenix Contact 1824434 is a 10-position terminal block receptacle with female sockets, designed for 0.200" (5.08mm) pitch board mount applications. This component features screw termination, supporting wire gauges from 12-30 AWG (0.2-2.5mm²) with IEC ratings of 12A at 630V and UL ratings of 10A at 300V. The part is classified as obsolete, making identification of active equivalent models essential for procurement and design continuity.

Substiute Parts

1824434

Phoenix ContactIn Stock: 12211824434 Datasheet

Current PartRFQ

1824201

Phoenix ContactIn Stock: 8071824201 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the Phoenix Contact 1824434 is determined by strict equivalence across the following critical parameters:

• 10-position configuration with 0.200" (5.08mm) pitch spacing
• Receptacle type with female socket contacts
• Screw termination method with M3 fasteners
• Board mount orientation
• Electrical ratings: 12A IEC / 10A UL minimum current capacity
• Voltage ratings: 630V IEC / 300V UL minimum
• Wire gauge compatibility: 12-30 AWG (0.2-2.5mm²)
• Housing material: Polyamide (PA) with UL94 V-0 flammability rating
• Tin contact mating finish

The Phoenix Contact 1824201 meets all substitution criteria as an active product within the same COMBICON MSTBU series, maintaining identical electrical, mechanical, and material specifications while offering enhanced features and current product status.

Parameter Comparison

Engineering Selection Recommendations

The Phoenix Contact 1824201 is a direct functional equivalent to the 1824434 with identical electrical and mechanical specifications. The primary distinction is product status: the 1824434 is obsolete while the 1824201 is active, ensuring ongoing availability and supply chain continuity.

The 1824201 provides enhanced features including retention latches, which improve mechanical stability during mating operations without affecting electrical performance or physical compatibility. Both parts maintain equivalent RoHS compliance (RoHS Compliant vs. ROHS3 Compliant), with the 1824201 meeting the more recent ROHS3 standard. The 1824201 also includes REACH Unaffected status documentation.

For new designs or component replacement in existing applications, the 1824201 is the appropriate selection due to its active product status and enhanced feature set while maintaining full backward compatibility with the 1824434 specification.

Frequently Asked Questions (FAQ)

Q: Can the 1824201 be used as a direct replacement for the 1824434 in existing designs?

A: Yes. The 1824201 maintains identical electrical ratings (12A IEC / 10A UL), voltage specifications (630V IEC / 300V UL), pitch (5.08mm), wire gauge compatibility (12-30 AWG), screw termination parameters, and physical dimensions. Board-level compatibility is maintained.

Q: What is the difference between the 1824434 and 1824201?

A: The primary differences are product status (obsolete vs. active) and features. The 1824201 includes retention latches for enhanced mechanical stability. Both parts are electrically and mechanically equivalent with identical current and voltage ratings.

Q: Are there packaging differences between these parts?

A: The 1824434 is listed with unspecified packaging, while the 1824201 is supplied in bulk packaging. This does not affect component functionality or electrical performance.

Q: Do both parts meet the same compliance standards?

A: Both parts are RoHS compliant and meet UL94 V-0 flammability requirements. The 1824201 carries ROHS3 Compliant status and includes REACH Unaffected documentation, representing current regulatory compliance standards.

Q: What wire gauges are supported by the 1824201?

A: The 1824201 supports 12-30 AWG (0.2-2.5mm²), identical to the 1824434.

Q: Is the screw torque specification the same for both parts?

A: Yes. Both the 1824434 and 1824201 require M3 screw torque of 0.5-0.6 Nm (4.4-5.3 Lb-In).
