172-009-212-021 D-Sub 9-Position Receptacle Connector Equivalent & Substitute Parts

Part Overview

The NorComp Inc. 172-009-212-021 is a 9-position D-Sub receptacle connector with female sockets, designed for panel mount through-hole solder termination applications. This connector features a DE/E shell size (Size 1) configuration with 2 rows of contacts and is constructed with steel tin-plated shell material and gold-flashed contacts. With 748 units currently in stock, this part remains available as a new original component.

The 172-009-212-021 is classified as an active product within the D-Sub connector category. Equivalent and substitute parts are identified based on matching electrical and mechanical parameters including connector type, position count, shell size, mounting configuration, termination method, and material specifications. Substitute selection ensures functional compatibility while accommodating variations in flange design, contact finish, and current rating within acceptable operational ranges.

Key Parameters

Parameter	Value
Manufacturer Part Number	172-009-212-021
Manufacturer	NorComp Inc.
Connector Style	D-Sub
Connector Type	Receptacle, Female Sockets
Number of Positions	9
Number of Rows	2
Shell Size, Connector Layout	1 (DE, E)
Mounting Type	Panel Mount, Through Hole
Termination	Solder
Shell Material, Finish	Steel, Tin Plated
Contact Finish	Gold
Contact Finish Thickness	Flash
Material Flammability Rating	UL94 V-0
Current Rating (Amps)	5A
Operating Temperature	-50°C ~ 100°C
RoHS Status	ROHS3 Compliant
Series	172

Substitute Part Grouping Explanation

Substitute parts for the 172-009-212-021 are grouped based on strict alignment with core electrical and mechanical parameters. The primary substitution criteria are:

Critical Parameters (Must Match):

Connector type: Receptacle with female sockets
Position count: 9 positions
Shell size and layout: Size 1 (DE, E)
Mounting configuration: Through-hole solder termination
Connector style: D-Sub

Secondary Parameters (Allow Controlled Variation):

Flange feature design (board side vs. housing/shell mounting)
Contact finish (gold vs. unfinished)
Shell material finish (tin-plated vs. steel)
Current rating (5A to 7.5A range acceptable)
Operating temperature range (-50°C to -55°C minimum; 100°C to 125°C maximum)
Contact form (machined vs. stamped)
Dielectric material composition (PBT polyester vs. PCT polyester variants)

Substitutes are identified from NorComp Inc. (direct manufacturer variants) and HARTING (cross-manufacturer equivalents), with one Mercury United Electronics option. All substitute parts maintain ROHS3 compliance and UL94 V-0 flammability rating.

Parameter Comparison

Parameter	172-009-212-021 (Main)	172-009-212R021	09661116501	09661116502	09661117501	09661117502	09661516512	09661556511	09661556512	09670094755	628-009-220-014
Manufacturer	NorComp Inc.	NorComp Inc.	HARTING	HARTING	HARTING	HARTING	HARTING	HARTING	HARTING	HARTING	Mercury United Electronics, Inc.
Connector Type	Receptacle, Female Sockets	Receptacle, Female Sockets	Receptacle, Female Sockets	Receptacle, Female Sockets	Receptacle, Female Sockets	Receptacle, Female Sockets	Receptacle, Female Sockets	Receptacle, Female Sockets	Receptacle, Female Sockets	Receptacle, Female Sockets	Receptacle, Female Sockets
Number of Positions	9	9	9	9	9	9	9	9	9	9	9
Shell Size, Connector Layout	1 (DE, E)	1 (DE, E)	1 (DE, E)	1 (DE, E)	1 (DE, E)	1 (DE, E)	1 (DE, E)	1 (DE, E)	1 (DE, E)	1 (DE, E)	1 (DE, E)
Mounting Type	Panel Mount, Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole
Termination	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder
Shell Material, Finish	Steel, Tin Plated	Steel, Tin Plated	Steel	Steel	Steel	Steel	Steel	Steel	Steel	Steel	Steel, Nickel Plated
Contact Finish	Gold	Gold	—	—	—	—	—	Gold	Gold	—	Gold
Contact Finish Thickness	Flash	Flash	—	—	—	—	—	—	—	—	Flash
Material Flammability Rating	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0
Current Rating (Amps)	5A	5A	6.5A	6.5A	6.5A	6.5A	6.5A	6.5A	6.5A	7.5A	5A
Operating Temperature	-50°C ~ 100°C	-50°C ~ 100°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 85°C
RoHS Status	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant
Product Status	Active	Obsolete	Active	Active	Active	Active	Active	Active	Active	Active	Active

Engineering Selection Recommendations

Direct NorComp Equivalent: The 172-009-212R021 is a direct manufacturer equivalent from NorComp Inc., differing only in packaging (tray vs. standard) and product status (obsolete). This part maintains identical electrical and mechanical specifications including 5A current rating, -50°C to 100°C operating range, and gold-flashed contact finish. Selection of this part is appropriate for applications requiring exact specification matching, though inventory status should be confirmed due to obsolete classification.

HARTING Cross-Manufacturer Substitutes (Active Status): HARTING D-Sub receptacles 09661116501, 09661116502, 09661117501, 09661117502, 09661516512, and 09661556512 provide active-status alternatives with enhanced current ratings (6.5A to 7.5A) and extended operating temperature ranges (-55°C to 125°C). These parts maintain the critical 9-position, Size 1 (DE, E) configuration with solder termination. Flange feature variations (M3 vs. 4-40 threaded) and contact form differences (stamped vs. machined) do not affect functional compatibility. Parts 09661556511 and 09661556512 include board lock features and gold contact finish, providing additional mechanical retention and corrosion resistance.

Mercury United Electronics Alternative: The 628-009-220-014 from Mercury United Electronics, Inc. offers a shielded variant with board guide features and nickel-plated shell finish. This part maintains 5A current rating and gold-flashed contact finish but operates within a reduced temperature range (-55°C to 85°C). Selection is appropriate for applications requiring shielding and board-level guidance.

Product Status Consideration: All HARTING and Mercury United Electronics parts maintain active product status, ensuring continued availability and supply chain stability. The NorComp 172-009-212R021 is classified as obsolete and should be selected only when exact NorComp specification compliance is mandated.

Frequently Asked Questions (FAQ)

Q: Can I substitute a HARTING part for the NorComp 172-009-212-021?

A: Yes. HARTING D-Sub receptacles 09661116501, 09661116502, 09661117501, 09661117502, 09661516512, 09661556511, and 09661556512 are functionally equivalent. All maintain the 9-position, Size 1 (DE, E) receptacle configuration with solder termination. Differences in current rating (6.5A vs. 5A), operating temperature range (-55°C to 125°C vs. -50°C to 100°C), and contact finish do not prevent substitution in standard applications. Flange design variations (M3 vs. 4-40 threaded) must be evaluated against your specific mounting requirements.

Q: What is the difference between the 09661117501 and 09661117502?

A: Both parts are HARTING 9-position D-Sub receptacles with identical electrical specifications (6.5A current rating, -55°C to 125°C operating range). The primary difference is flange feature: 09661117501 uses M3 housing/shell mounting, while 09661117502 uses 4-40 threaded board-side mounting. Selection depends on your panel or PCB mounting interface.

Q: Why do some substitute parts have higher current ratings?

A: HARTING parts (09661116501, 09661116502, 09661117501, 09661117502, 09661516512, 09661556511, 09661556512) are rated for 6.5A or 7.5A, compared to the main part's 5A rating. Higher current ratings indicate enhanced contact design and material composition. These parts remain fully compatible with applications designed for 5A operation, as they exceed the minimum requirement.

Q: Is the 628-009-220-014 shielded variant compatible?

A: The 628-009-220-014 is functionally compatible as a 9-position D-Sub receptacle with solder termination. It includes shielding and board guide features not present in the main part. However, its operating temperature range is limited to -55°C to 85°C (vs. -50°C to 100°C for the main part). Selection requires confirmation that your application does not exceed 85°C maximum operating temperature.

Q: What does "board lock" feature mean on parts 09661516512 and 09661556512?

A: Board lock is a mechanical retention feature that provides additional mechanical stability by locking the connector to the PCB or panel. This feature does not affect electrical compatibility but enhances mechanical robustness in high-vibration or high-stress environments. Parts without board lock (09661116501, 09661116502, 09661117501, 09661117502) remain fully compatible for standard applications.

Q: Are all substitute parts ROHS3 compliant?

A: Yes. All listed substitute parts, including the main part 172-009-212-021, maintain ROHS3 compliance and UL94 V-0 flammability rating. This ensures regulatory compliance across all substitution options.

Q: What packaging options are available?

A: Substitute parts are available in bulk and tray packaging. The main part 172-009-212-021 is available in standard packaging (748 units in stock). The NorComp 172-009-212R021 is supplied in tray packaging. HARTING parts are available in both bulk and tray configurations. Mercury United Electronics 628-009-220-014 is supplied in bulk packaging. Packaging selection does not affect connector performance.
